NMB Technologies, a MinebeaMitsumi Group company, is a global leader in miniature ball bearings, cooling fans, DC motors, and precision components for automotive, medical, and industrial applications.
Parts that are not part of a series
Company background and product focus
NMB Technologies Corporation is the U.S. sales and marketing arm of MinebeaMitsumi, a global leader in miniature ball bearings, precision components, electromechanical components, and semiconductor components. Based in Novi, Michigan, NMB serves the largest OEMs in North America across diverse industries.
NMB's comprehensive product portfolio includes:
With MinebeaMitsumi's global manufacturing base spanning over 80 locations in 22 countries, NMB Technologies provides reliable supply and technical support to customers in automotive, medical, industrial, office equipment, personal computers, home entertainment, and consumer electronics industries.
© 2026 Zenode. All rights reserved.
Product families from NMB TECHNOLOGIES
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
| Fans | 8 | Active | ||
03010SSDC Fans DC Axial Fan, 30x30x10mm, 12VDC, 4.2CFM, Rib Mount, Sleeve Bearing, Lead Wires | Fans, Blowers, Thermal Management | 15 | Active | DC Fans DC Axial Fan, 30x30x10mm, 12VDC, 4.2CFM, Rib Mount, Sleeve Bearing, Lead Wires |
| DC Brushless Fans (BLDC) | 13 | Active | ||
| Fans, Blowers, Thermal Management | 2 | Active | ||
| Fans | 2 | Active | ||
04010SSDC Fans DC Axial Fan, 40x40x10mm, 12VDC, 4.9CFM, Rib Mount, Sleeve Bearing, Lead Wires | Fans | 18 | Active | DC Fans DC Axial Fan, 40x40x10mm, 12VDC, 4.9CFM, Rib Mount, Sleeve Bearing, Lead Wires |
| Fans, Blowers, Thermal Management | 18 | Active | ||
| DC Brushless Fans (BLDC) | 15 | Active | ||
| Fans, Blowers, Thermal Management | 12 | Active | ||
04028VADC Fans DC Axial Fan, 40x40x28mm, 24VDC, 12.4CFM, Rib Mount, Ball, Lead Wires, IP69K | Fans, Blowers, Thermal Management | 3 | Active | DC Fans DC Axial Fan, 40x40x28mm, 24VDC, 12.4CFM, Rib Mount, Ball, Lead Wires, IP69K |
Parts from NMB TECHNOLOGIES that are not part of a series
| Part Information | Pricing (lowest) | Material - Blade | Current Rating | Voltage Range (Max) | Voltage Range (Min) | Material - Frame | Lifetime | Power (Watts) | Fan Type | Bearing Type | Size / Dimension Length | Size / Dimension Shape | Size / Dimension Height | Static Pressure | Noise | Air Flow | Width | RPM | Termination Leads Count | Termination Type | Termination | Operating Temperature (Max) | Operating Temperature (Min) | Voltage - Rated | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NMB TECHNOLOGIES FAN AXIAL 25X10MM 5VDC WIRE | Sign in to see pricing | Plastic | 70 mA | 5.5 VDC | 4.5 VDC | Plastic | 30000 Hrs | 350 mW | Tubeaxial | Sleeve | 25 mm | Square | 25 mm | 0.046 in H2O | 22 dB | 1.1 CFM | 10 mm | 5500 RPM | 2 leads | Wire Leads | 2 Wire Leads | 158 °F | 14 °F | 5 VAC | Auto Restart |
NMB TECHNOLOGIES FAN AXIAL 25X10MM 5VDC WIRE | Sign in to see pricing | Plastic | 70 mA | 5.5 VDC | 4.5 VDC | Plastic | 30000 Hrs | 350 mW | Tubeaxial | Sleeve | 25 mm | Square | 25 mm | 0.046 in H2O | 22 dB | 1.1 CFM | 10 mm | 5500 RPM | 3 | Wire Leads | 3 Wire Leads | 158 °F | 14 °F | 5 VAC | Auto Restart, Locked Rotor Sensor |
NMB TECHNOLOGIES FAN AXIAL 25X10MM 5VDC WIRE | Sign in to see pricing | Plastic | 70 mA | 5.5 VDC | 4.5 VDC | Plastic | 30000 Hrs | 350 mW | Tubeaxial | Sleeve | 25 mm | Square | 25 mm | 0.046 in H2O | 22 dB | 1.1 CFM | 10 mm | 5500 RPM | 3 | Wire Leads | 3 Wire Leads | 158 °F | 14 °F | 5 VAC | Auto Restart, Speed Sensor (Tach) |
NMB TECHNOLOGIES FAN AXIAL 25X10MM 5VDC WIRE | Sign in to see pricing | Plastic | 0.08 A | 5.5 VDC | 4.5 VDC | Plastic | 30000 Hrs | 0.4 W | Tubeaxial | Sleeve | 25 mm | Square | 25 mm | 0.14 in H2O | 21.5 dB | 1.9 CFM | 10 mm | 9500 RPM | 3 | Wire Leads | 3 Wire Leads | 158 °F | 14 °F | 5 VAC | Auto Restart, Locked Rotor Sensor |
NMB TECHNOLOGIES DC AXIAL FAN, 5 V, SQUARE, 25 MM, 10 MM, SLEEVE BEARING, 2.65 CFM | Sign in to see pricing | — | — | — | — | — | — | 900 mW | Tubeaxial | Sleeve | 25 mm | Square | 25 mm | 0.27 in H2O | 28.5 dB | 2.7 CFM | 10 mm | 13000 RPM | 3 | Wire Leads | 3 Wire Leads | 158 °F | 14 °F | 5 VAC | Auto Restart, Locked Rotor Sensor |
 NMB TECHNOLOGIES DC AXIAL FAN, 12 V, SQUARE, 25 MM, 10 MM, SLEEVE BEARING, 1.52 CFM | Sign in to see pricing | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 2 leads | Wire Leads | 2 Wire Leads | — | — | 12 VAC | — |
NMB TECHNOLOGIES DC AXIAL FAN | Sign in to see pricing | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
NMB TECHNOLOGIES DC AXIAL FAN | Sign in to see pricing | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
NMB TECHNOLOGIES FAN AXIAL 25X10MM 12VDC WIRE | Sign in to see pricing | — | — | — | — | — | — | — | Tubeaxial | Sleeve | 25 mm | Square | 25 mm | — | — | — | 10 mm | — | 3 | Wire Leads | 3 Wire Leads | 158 °F | 14 °F | 12 VAC | Auto Restart, Speed Sensor (Tach) |
NMB TECHNOLOGIES FAN AXIAL 25X10MM 12VDC WIRE | Sign in to see pricing | Plastic | 40 mA | 13.8 VDC | 6 VDC | Plastic | 30000 Hrs | 0.48 W | Tubeaxial | Sleeve | 25 mm | Square | 25 mm | 0.14 in H2O | 21.5 dB | 1.9 CFM | 10 mm | 9500 RPM | 3 | Wire Leads | 3 Wire Leads | 158 °F | 14 °F | 12 VAC | Auto Restart, Locked Rotor Sensor |
