04010SS Series
DC Fans DC Axial Fan, 40x40x10mm, 12VDC, 4.9CFM, Rib Mount, Sleeve Bearing, Lead Wires
Manufacturer: NMB TECHNOLOGIES
Catalog
DC Fans DC Axial Fan, 40x40x10mm, 12VDC, 4.9CFM, Rib Mount, Sleeve Bearing, Lead Wires
Beta
⌘K
DC Fans DC Axial Fan, 40x40x10mm, 12VDC, 4.9CFM, Rib Mount, Sleeve Bearing, Lead Wires
DC Fans DC Axial Fan, 40x40x10mm, 12VDC, 4.9CFM, Rib Mount, Sleeve Bearing, Lead Wires
DC Fans DC Axial Fan, 40x40x10mm, 12VDC, 4.9CFM, Rib Mount, Sleeve Bearing, Lead Wires
| Part | RPM | Width | Fan Type | Voltage - Rated | Features | Operating Temperature (Max) | Operating Temperature (Min) | Noise | Static Pressure | Power (Watts) | Air Flow | Bearing Type | Termination Leads Count | Termination Type | Termination | Size / Dimension Length | Size / Dimension Shape | Size / Dimension Height | Voltage Range (Max) | Voltage Range (Min) | Material - Blade | Material - Frame | Current Rating | Lifetime | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NMB TECHNOLOGIES | 5500 RPM | 10 mm | Tubeaxial | 12 VAC | Auto Restart Speed Sensor (Tach) | 158 °F | 14 °F | 21 dB | 0.11 in H2O | 0.4 W | 4.9 CFM | Sleeve | 3 | Wire Leads | 3 Wire Leads | 40 mm | Square | 40 mm | 13.8 VDC | 10.2 VDC | Plastic | Plastic | 0.33 A | 30000 Hrs | |
 NMB TECHNOLOGIES | 7500 RPM | 10 mm | Tubeaxial | 12 VAC | Auto Restart Locked Rotor Sensor | 158 °F | 14 °F | 29 dB | 0.2 in H2O | 710 mW | 6.7 CFM | Sleeve | 3 | Wire Leads | 3 Wire Leads | 40 mm | Square | 40 mm | 13.8 VDC | 10.2 VDC | Plastic | Plastic | 60 mA | 30000 Hrs | |
 NMB TECHNOLOGIES | 7500 RPM | 10 mm | Tubeaxial | 12 VAC | Speed Sensor (Tach) | 158 °F | 14 °F | 29 dB | 0.19 in H2O | 700 mW | 6.7 CFM | Sleeve | 3 | Wire Leads | 3 Wire Leads | 40 mm | Square | 40 mm | 13.8 VDC | 10.2 VDC | Plastic | Plastic | 0.059 A | 0.035 lb | |
NMB TECHNOLOGIES | 10 mm | Tubeaxial | 5 VAC | Auto Restart Speed Sensor (Tach) | 158 °F | 14 °F | Sleeve | 3 | Wire Leads | 3 Wire Leads | 40 mm | Square | 40 mm | Plastic | Plastic | 30000 Hrs | |||||||||
 NMB TECHNOLOGIES | 6500 RPM | 10 mm | Tubeaxial | 5 VAC | Auto Restart | 158 °F | 14 °F | 24 dB | 0.15 in H2O | 650 mW | 5.6 CFM | Sleeve | 2 leads | Wire Leads | 2 Wire Leads | 40 mm | Square | 40 mm | 5.5 VDC | 4.5 VDC | Plastic | Plastic | 0.13 A | 30000 Hrs | |
NMB TECHNOLOGIES | 7500 RPM | 10 mm | Tubeaxial | 24 VAC | Speed Sensor (Tach) | 158 °F | 14 °F | 29 dB | 0.19 in H2O | 1.1 W | 6.7 CFM | Sleeve | 3 | Wire Leads | 3 Wire Leads | 40 mm | Square | 40 mm | 26.4 VDC | 20 VDC | Plastic | Plastic | 46 mA | 0.035 lb | |
NMB TECHNOLOGIES | 10 mm | Tubeaxial | 5 VAC | Auto Restart Locked Rotor Sensor | 158 °F | 14 °F | Sleeve | 3 | Wire Leads | 3 Wire Leads | 40 mm | Square | 40 mm | Plastic | Plastic | 30000 Hrs | |||||||||
 NMB TECHNOLOGIES | 7500 RPM | 10 mm | Tubeaxial | 5 VAC | Auto Restart | 158 °F | 14 °F | 29 dB | 0.2 in H2O | 850 mW | 6.7 CFM | Sleeve | 2 leads | Wire Leads | 2 Wire Leads | 40 mm | Square | 40 mm | 5.5 VDC | 4.5 VDC | Plastic | Plastic | 0.17 A | 30000 Hrs | |
NMB TECHNOLOGIES | 6500 RPM | 10 mm | Tubeaxial | 12 VAC | Auto Restart Locked Rotor Sensor | 158 °F | 14 °F | 24 dB | 0.15 in H2O | 600 mW | 5.7 CFM | Sleeve | 3 | Wire Leads | 3 Wire Leads | 40 mm | Square | 40 mm | 13.8 VDC | 10.2 VDC | Plastic | Plastic | 50 mA | 30000 Hrs | |
NMB TECHNOLOGIES | 6500 RPM | 10 mm | Tubeaxial | 12 VAC | Auto Restart Speed Sensor (Tach) | 158 °F | 14 °F | 24 dB | 0.15 in H2O | 600 mW | 5.7 CFM | Sleeve | 3 | Wire Leads | 3 Wire Leads | 40 mm | Square | 40 mm | 13.8 VDC | 10.2 VDC | Plastic | Plastic | 50 mA | 30000 Hrs |
