DC AXIAL FAN, 24 V, SQUARE, 40 MM, 20 MM, BALL BEARING
| Part | Features | Bearing Type | Voltage - Rated | Width | Termination Leads Count | Termination Type | Termination | Fan Type | Size / Dimension Length | Size / Dimension Shape | Size / Dimension Height | Ingress Protection Description | Ingress Protection IP Rating | Power (Watts) | Noise | Operating Temperature (Max) | Operating Temperature (Min) | Weight | Static Pressure | RPM | Air Flow | Material - Blade | Voltage Range (Min) | Voltage Range (Max) | Material - Frame | Current Rating | Lifetime |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NMB TECHNOLOGIES | Auto Restart | Ball | 24 VAC | 20 mm | 2 leads | Wire Leads | 2 Wire Leads | Tubeaxial | 40 mm | Square | 40 mm | ||||||||||||||||
 NMB TECHNOLOGIES | Auto Restart | Ball | 24 VAC | 20 mm | 2 leads | Wire Leads | 2 Wire Leads | Tubeaxial | 40 mm | Square | 40 mm | Dust Tight High Temp Water Jets Waterproof | IP69K | 2.16 W | 42 dB | 158 °F | 14 °F | 0.088 lb | 0.57 in H2O | 11000 RPM | 12.4 CFM | Plastic | 14 VDC | 26.4 VDC | Plastic | 0.09 A | 100000 Hrs |
 NMB TECHNOLOGIES | Auto Restart | Ball | 5 VAC | 20 mm | 2 leads | Wire Leads | 2 Wire Leads | Tubeaxial | 40 mm | Square | 40 mm | ||||||||||||||||
 NMB TECHNOLOGIES | Auto Restart Speed Sensor (Tach) | Ball | 5 VAC | 20 mm | 3 | Wire Leads | 3 Wire Leads | Tubeaxial | 40 mm | Square | 40 mm | 158 °F | 14 °F | Plastic | Plastic | 40000 Hrs | |||||||||||
NMB TECHNOLOGIES | Auto Restart | Ball | 24 VAC | 20 mm | 2 leads | Wire Leads | 2 Wire Leads | Tubeaxial | 40 mm | Square | 40 mm | 158 °F | 14 °F | Plastic | Plastic | 40000 Hrs | |||||||||||
NMB TECHNOLOGIES | Auto Restart Locked Rotor Sensor | Ball | 24 VAC | 20 mm | 3 | Wire Leads | 3 Wire Leads | Tubeaxial | 40 mm | Square | 40 mm | 158 °F | 14 °F | Plastic | Plastic | 40000 Hrs | |||||||||||
NMB TECHNOLOGIES | Auto Restart | Ball | 12 VAC | 20 mm | 2 leads | Wire Leads | 2 Wire Leads | Tubeaxial | 40 mm | Square | 40 mm | Dust Tight High Temp Water Jets Waterproof | IP69K | 1.56 W | 42 dB | 158 °F | 14 °F | 0.088 lb | 0.57 in H2O | 11000 RPM | 12.4 CFM | Plastic | 9 V | 13.2 VDC | Plastic | 0.13 A | 100000 Hrs |
NMB TECHNOLOGIES | Ball | 12 VAC | 20 mm | 2 leads | Wire Leads | 2 Wire Leads | Tubeaxial | 40 mm | Square | 40 mm | 158 °F | 14 °F | 0.088 lb | Plastic | 7 V | 13.2 VDC | Plastic | 40000 Hrs | |||||||||
 NMB TECHNOLOGIES | Auto Restart Locked Rotor Sensor | Ball | 24 VAC | 20 mm | 3 | Wire Leads | 3 Wire Leads | Tubeaxial | 40 mm | Square | 40 mm | 158 °F | 14 °F | Plastic | Plastic | 40000 Hrs | |||||||||||
 NMB TECHNOLOGIES | Auto Restart Locked Rotor Sensor | Ball | 5 VAC | 20 mm | 3 | Wire Leads | 3 Wire Leads | Tubeaxial | 40 mm | Square | 40 mm |
