Product families from aimtec
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
| DC DC Converters | 72 | Active | ||
| Power Supplies - Board Mount | 45 | Active | ||
| DC DC Converters | 7 | Active | ||
| DC DC Converters | 25 | Active | ||
| Power Supplies - External/Internal (Off-Board) | 9 | Active | ||
| DC DC Converters | 5 | Active | ||
| DC DC Converters | 12 | Active | ||
| Power Supplies - Board Mount | 19 | Active | ||
| DC DC Converters | 6 | Active | ||
| DC DC Converters | 4 | Active |
Parts from aimtec that are not part of a series
| Part Information | Pricing (lowest) | Voltage - Isolation | Voltage - Input (Min) | Voltage - Output 1 | Current - Output (Max) | Applications | Power (Watts) | Operating Temperature (Min) | Operating Temperature (Max) | Number of Outputs | Voltage - Input (Max) | Size / Dimension Width | Size / Dimension Height | Size / Dimension Length | Mounting Type | Efficiency | Approval Agency | Type | Package / Case | Package Leads | Package Name |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 aimtec DC DC CONVERTER 3.3V 500MW | Sign in to see pricing | 3 kV | 2.97 V | 3.3 V | 152 mA | ITE (Commercial) | 0.5 mW | -40 °C | 85 °C | 1 | 3.63 V | 0.24 in | 0.4 in | 0.46 in | Through Hole | 76 % | CE | Isolated Module | 4-SIP Module | — | — |
aimtec DC DC CONVERTER 5V 500MW | Sign in to see pricing | 1000 Vrms | 2.97 V | 5 V | 100 mA | ITE (Commercial) | 0.5 mW | -40 °C | 85 °C | 1 | 3.63 V | 0.24 in | 0.4 in | 0.46 in | Through Hole | 70 % | CE | Isolated Module | 4-SIP Module | — | — |
aimtec DC DC CONVERTER 9V 500MW | Sign in to see pricing | 1000 Vrms | 2.97 V | 9 V | 56 mA | ITE (Commercial) | 0.5 mW | -40 °C | 85 °C | 1 | 3.63 V | 0.24 in | 0.4 in | 0.46 in | Through Hole | 70 % | CE | Isolated Module | 4-SIP Module | — | — |
aimtec DC DC CONVERTER 12V 500MW | Sign in to see pricing | 3 kV | 2.97 V | 12 V | 42 mA | ITE (Commercial) | 0.5 mW | -40 °C | 85 °C | 1 | 3.63 V | 0.24 in | 0.4 in | 0.46 in | Through Hole | 72 % | CE | Isolated Module | 4-SIP Module | — | — |
aimtec DC DC CONVERTER 12V 500MW | Sign in to see pricing | 1000 Vrms | 2.97 V | 12 V | 42 mA | ITE (Commercial) | 0.5 mW | -40 °C | 85 °C | 1 | 3.63 V | 0.24 in | 0.4 in | 0.46 in | Through Hole | 72 % | CE | Isolated Module | 4-SIP Module | — | — |
aimtec DC DC CONVERTER 15V 500MW | Sign in to see pricing | 3 kV | 2.97 V | 15 V | 33 mA | ITE (Commercial) | 0.5 mW | -40 °C | 85 °C | 1 | 3.63 V | 0.24 in | 0.4 in | 0.46 in | Through Hole | 73 % | CE | Isolated Module | 4-SIP Module | — | — |
aimtec DC DC CONVERTER 9V 500MW | Sign in to see pricing | 3 kV | 4.5 V | 9 V | 56 mA | ITE (Commercial) | 0.5 mW | -40 °C | 85 °C | 1 | 5.5 V | 0.24 in | 0.4 in | 0.46 in | Through Hole | 78 % | CE | Isolated Module | 4-SIP Module | — | — |
 aimtec DC DC CONVERTER 5V 250MW | Sign in to see pricing | 3 kV | 4.5 V | 5 V | 50 mA | ITE (Commercial) | 0.25 mW | -40 °C | 105 °C | 1 | 5.5 V | 0.44 in | 0.28 in | 0.5 in | Surface Mount | 77 % | — | Isolated Module | — | 5 Leads | 8-SMD Module |
aimtec DC DC CONVERTER 5V 250MW | Sign in to see pricing | 1500 Vrns | 10.8 V | 5 V | 50 mA | ITE (Commercial) | 0.25 mW | -40 °C | 105 °C | 1 | 13.2 V | 0.44 in | 0.28 in | 0.5 in | Surface Mount | 75 % | — | Isolated Module | — | — | — |
aimtec DC DC CONVERTER 9V 250MW | Sign in to see pricing | 1500 Vrns | 10.8 V | 9 V | 28 mA | ITE (Commercial) | 250 mW | -40 °C | 100 °C | 1 | 13.2 V | 0.44 in | 0.28 in | 0.5 in | Surface Mount | 79 % | — | Isolated Module | — | 5 Leads | 8-SMD Module |
