AM10E Series

Manufacturer: aimtec

Catalog

DC DC CONVERTER 5V 10W

Part	Operating Temperature [Min]	Operating Temperature [Max]	Number of Outputs	Current - Output (Max) [Max]	Type	Applications	Voltage - Input (Min) [Min]	Voltage - Isolation	Mounting Type	Voltage - Input (Max) [Max]	Voltage - Output 1	Power (Watts)	Approval Agency	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Package / Case	Voltage - Output 2	Voltage - Output 1 [Min]	Voltage - Output 1 [Max]	Efficiency	Current - Output (Max) [Max]	Features	Current - Output (Max)	Standard Number	Size / Dimension	Current - Output (Max)	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]
aimtec AM10EW-4805SH30-NZ	-40 °C	85 °C	1	2 A	Isolated Module	ITE (Commercial)	18 V	3000 V	Through Hole	75 V	5 V	10 W	CE cURus	2.03 "	51.5 mm	1.04 "	26.5 mm	0.47 "	12 mm	6-DIP Module 5 Leads
aimtec AM10EW-2412DH30-NZ	-40 C	85 °C	2	416 mA	Isolated Module	ITE (Commercial)	9 V	3000 V	Through Hole	36 V		10 W	CE cURus UL	2.03 "	51.5 mm	1.04 "	26.5 mm	0.47 "	12 mm		-12 V	-12 V	12 V	86 %	416 mA	Remote On/Off
aimtec AM10EW-2405SH30-NZ	-40 C	85 °C	1	2 A	Isolated Module	ITE (Commercial)	9 V	3000 V	Through Hole	36 V	5 V	10 W	CE cURus UL	2.03 "	51.5 mm	1.04 "	26.5 mm	0.47 "	12 mm	6-DIP Module 5 Leads						Remote On/Off
aimtec AM10EW-4805DH30-NZ	-40 C	85 °C	2		Isolated Module	ITE (Commercial)	18 V	3000 V	Through Hole	75 V		10 W	CE cURus UL	2.03 "	51.5 mm	1.04 "	26.5 mm	0.47 "	12 mm		-5 V	-5 V	5 V			Remote On/Off	1 A
aimtec AM10E-1207DZ	-40 C	85 °C	2		Isolated Module	ITE (Commercial)	9 V	1.5 kV	Through Hole	18 V		10 W	CE cULus cURus EN IEC UL								-7.2 V	-7.2 V	7.2 V	83 %			690 mA	62368-1	0.4 in 10.2 mm 25.4 mm 50.8 mm	690 mA
aimtec AM10EW-11012SH22-NZ	-40 °C	85 °C	1	833 mA	Isolated Module	ITE (Commercial)	40 V	2250 VDC	Through Hole	160 V	12 V	10 W	CE cURus		50.8 mm		25.4 mm		11.8 mm	4-DIP Module				84 %							2 in	1 "	0.46 in
aimtec AM10E-2415DZ	-40 C	85 °C	2		Isolated Module	ITE (Commercial)	18 V	1.5 kV	Through Hole	36 V	15 V	10 W	CE CE cURus cULus cURus EN IEC UL							5-DIP Module	-15 V			84 %			333 mA	62368-1	0.4 in 10.2 mm 25.4 mm 50.8 mm
aimtec AM10E-2424SZ	-40 C	85 °C	1	416 mA	Isolated Module	ITE (Commercial)	18 V	1.5 kV	Through Hole	36 V	24 V	10 W	CE CE cURus cULus cURus EN IEC UL							5-DIP Module 4 Leads				86 %				62368-1	0.4 in 10.2 mm 25.4 mm 50.8 mm
aimtec AM10EW-4812SH30-NZ-ST	-40 °C	71 °C	1	833 mA	Enclosed	ITE (Commercial)	18 V	3000 V	Chassis Mount	75 V	12 V	10 W	CE cURus		76 mm		31.5 mm		21.2 mm					86 %				60950-1			2.99 in	1.24 in	0.84 in
