AM150HB Series
Manufacturer: aimtec
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
DC DC CONVERTER 15V 150W
| Part | Features | Standard Number | Current - Output (Max) | Power (Watts) | Efficiency | Voltage - Output 1 | Package Name | Type | Size / Dimension Width | Size / Dimension Height | Size / Dimension Length | Applications | Number of Outputs | Voltage - Input (Min) | Voltage - Isolation | Mounting Type | Operating Temperature (Min) | Operating Temperature (Max) | Package / Case | Voltage - Input (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 aimtec | Adjustable Output Remote On/Off | 50155 | 10 A | 150 W | 89 % | 15 V | Half Brick | Isolated Module | 2.28 in | 0.54 in | 2.4 in | Railway | 1 | 43 V | 3 kV | Through Hole | -40 °C | 105 °C | Half Brick | 160 VDC |
 aimtec | Adjustable Output Heatsink Remote On/Off Remote Sense | 3.12 A | 150 W | 88 % | 48 V | Half Brick | Isolated Module | 2 in | 1.25 in | 2.44 in | Industrial Railway | 1 | 43 V | 3 kV | Through Hole | -40 °C | 105 °C | Half Brick | 160 VDC | |
 aimtec | Adjustable Output Remote On/Off | 50155 | 6.25 A | 150 W | 91 % | 24 V | Half Brick | Isolated Module | 2.28 in | 0.54 in | 2.4 in | Railway | 1 | 43 V | 3 kV | Through Hole | -40 °C | 105 °C | Half Brick | 160 VDC |
aimtec | Adjustable Output Remote On/Off | 50155 | 24 A | 120 W | 88 % | 5 V | Half Brick | Isolated Module | 2.28 in | 0.54 in | 2.4 in | Railway | 1 | 43 V | 3 kV | Through Hole | -40 °C | 105 °C | Half Brick | 160 VDC |
