AM10C Series
Manufacturer: aimtec
Beta
⌘K
DC DC CONVERTER +/-12V 10W
| Part | Voltage - Input (Max) | Size / Dimension Length | Size / Dimension Width | Size / Dimension Height | Number of Outputs | Voltage - Input (Min) | Power (Watts) | Type | Approval Agency | Voltage - Output 2 | Voltage - Output 1 (Max) | Voltage - Output 1 (Min) | Current - Output (Max) | Mounting Type | Voltage - Isolation | Operating Temperature (Min) | Operating Temperature (Max) | Features | Efficiency | Applications | Voltage - Output 1 | Current - Output (Max) Options | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 aimtec | 75 V | 1 in | 1 in | 0.46 in | 2 | 18 V | 10 W | Isolated Module | CE cURus UL | -12 V | 12 V | -12 V | 410 mA | Through Hole | 1500 Vrns | -40 °C | 85 °C | Remote On/Off | 87 % | ITE (Commercial) | |||
aimtec | 36 V | 1 in | 1 in | 0.46 in | 1 | 9 V | 10 W | Isolated Module | CE cURus UL | 2 A | Through Hole | 1500 Vrns | -40 °C | 85 °C | Remote On/Off | 83 % | ITE (Commercial) | 5 V | |||||
aimtec | 36 V | 1 in | 1 in | 0.46 in | 1 | 9 V | 10 W | Isolated Module | CE cURus UL | 410 mA | Through Hole | 1500 Vrns | -40 °C | 85 °C | Remote On/Off | 88 % | ITE (Commercial) | 24 V | |||||
aimtec | 75 V | 1 in | 1 in | 0.46 in | 1 | 18 V | 10 W | Isolated Module | CE cURus UL | 660 mA | Through Hole | 1500 Vrns | -40 °C | 85 °C | Remote On/Off | 87 % | ITE (Commercial) | 15 V | |||||
aimtec | 36 V | 1 in | 1 in | 0.46 in | 2 | 9 V | 10 W | Isolated Module | CE cURus UL | -15 V | 15 V | -15 V | 330 mA | Through Hole | 1500 Vrns | -40 °C | 85 °C | Remote On/Off | 87 % | ITE (Commercial) | |||
aimtec | 36 V | 1 in | 1 in | 0.4 in | 1 | 18 V | 10 W | Isolated Module | 2 A | Through Hole | 1500 Vrns | -40 °C | 85 °C | Remote On/Off | 83 % | ITE (Commercial) | 5 V | ||||||
aimtec | 36 V | 1 in | 1 in | 0.46 in | 1 | 9 V | 10 W | Isolated Module | CE cURus UL | 830 mA | Through Hole | 1500 Vrns | -40 °C | 85 °C | Remote On/Off | 87 % | ITE (Commercial) | 12 V | |||||
 aimtec | 75 V | 1 in | 1 in | 0.46 in | 2 | 18 V | 10 W | Isolated Module | 12 V | 12 V | 5 V | Through Hole | 1500 Vrns | -40 °C | 85 °C | Remote On/Off | 84 % | ITE (Commercial) | 1A 417mA | 7-DIP Module | |||
 aimtec | 75 V | 1 in | 1 in | 0.46 in | 1 | 18 V | 10 W | Isolated Module | CE cURus UL | 410 mA | Through Hole | 1500 Vrns | -40 °C | 85 °C | Remote On/Off | 88 % | ITE (Commercial) | 24 V | |||||
aimtec | 75 V | 1 in | 1 in | 0.46 in | 1 | 18 V | 10 W | Isolated Module | CE cURus UL | 830 mA | Through Hole | 1500 Vrns | -40 °C | 85 °C | Remote On/Off | 87 % | ITE (Commercial) | 12 V |
