AM1/4S Series

Manufacturer: aimtec

Catalog

DC DC CONVERTER 3.3V 250MW

Part	Applications	Type	Voltage - Isolation	Voltage - Input (Max) [Max]	Power (Watts)	Approval Agency	Efficiency	Operating Temperature [Max]	Operating Temperature [Min]	Number of Outputs	Package / Case	Current - Output (Max) [Max]	Voltage - Input (Min) [Min]	Mounting Type	Voltage - Output 1	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]
aimtec AM1/4S-1203SH30Z	ITE (Commercial)	Isolated Module	3000 V	13.2 V	0.25 mW	CE	65 %	85 °C	-40 C	1	4-SIP Module	75.7 mA	10.8 V	Through Hole	3.3 V	9.7 mm	0.4 "	0.46 in	6 mm	11.7 mm	0.24 "
aimtec AM1/4S-1203SZ	ITE (Commercial)	Isolated Module	1000 V	13.2 V	0.25 W	CE	65 %	85 °C	-40 C	1	4-SIP Module	75.7 mA	10.8 V	Through Hole	3.3 V	9.7 mm	0.4 "	0.46 in	6 mm	11.7 mm	0.24 "
aimtec AM1/4S-2412SH30Z	ITE (Commercial)	Isolated Module	3000 V	26.4 V	0.25 W	CE	56 %	85 °C	-40 C	1	4-SIP Module		21.6 V	Through Hole	12 V	9.7 mm	0.4 "	0.46 in	6 mm	11.7 mm	0.24 "
aimtec AM1/4S-1207SZ	ITE (Commercial)	Isolated Module	1000 V	13.2 V	0.25 mW	CE	67 %	85 °C	-40 C	1	4-SIP Module	34.7 mA	10.8 V	Through Hole	7.2 V	9.7 mm	0.4 "	0.46 in	6 mm	11.7 mm	0.24 "
aimtec AM1/4S-2418SH30Z	ITE (Commercial)	Isolated Module	3000 V	26.4 V	0.25 mW	CE	57 %	85 °C	-40 C	1	4-SIP Module	13.8 mA	21.6 V	Through Hole	18 V	9.7 mm	0.4 "	0.46 in	6 mm	11.7 mm	0.24 "
aimtec AM1/4S-2403SZ	ITE (Commercial)	Isolated Module	1000 V	26.4 V	0.25 mW	CE	60 %	85 °C	-40 C	1	4-SIP Module	75.7 mA	21.6 V	Through Hole	3.3 V	9.7 mm	0.4 "	0.46 in	6 mm	11.7 mm	0.24 "
aimtec AM1/4S-1215SZ	ITE (Commercial)	Isolated Module	1000 V	13.2 V	0.25 mW	CE	67 %	85 °C	-40 C	1	4-SIP Module	16.6 mA	10.8 V	Through Hole	15 V	9.7 mm	0.4 "	0.46 in	6 mm	11.7 mm	0.24 "
aimtec AM1/4S-0515SZ	ITE (Commercial)	Isolated Module	1000 V	5.5 V	0.25 mW	CE	71 %	85 °C	-40 C	1	4-SIP Module	16.67 mA	4.5 V	Through Hole	15 V	9.7 mm	0.4 "	0.46 in	6 mm	11.7 mm	0.24 "
aimtec AM1/4S-0524SH30Z	ITE (Commercial)	Isolated Module	3000 V	5.5 V	0.25 mW	CE	77 %	85 °C	-40 C	1	4-SIP Module	10.41 mA	4.5 V	Through Hole	24 V	9.7 mm	0.4 "	0.46 in	6 mm	11.7 mm	0.24 "
aimtec AM1/4S-0507SH30Z	ITE (Commercial)	Isolated Module	3000 V	5.5 V	0.25 mW	CE	68 %	85 °C	-40 C	1	4-SIP Module	34.7 mA	4.5 V	Through Hole	7.2 V	9.7 mm	0.4 "	0.46 in	6 mm	11.7 mm	0.24 "
