Product families from Portescap
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
| Motors, Actuators, Solenoids and Drivers | 1 | Active | ||
| Motors - AC, DC | 1 | Active | ||
| Motors - AC, DC | 1 | Active | ||
| Motors - AC, DC | 2 | Active | ||
| Motors, Actuators, Solenoids and Drivers | 2 | Active | ||
| Motors, Actuators, Solenoids and Drivers | 3 | Active | ||
| Motors, Actuators, Solenoids and Drivers | 1 | Active | ||
| Motors - AC, DC | 1 | Active | ||
| Motors - AC, DC | 2 | Active | ||
| Motors, Actuators, Solenoids and Drivers | 1 | Active |
Parts from Portescap that are not part of a series
| Part Information | Pricing (lowest) | Type | Diameter - Shaft | Size / Dimension Shape | Size / Dimension Diameter | Function | Length - Shaft and Bearing | Termination Style | Operating Temperature (Max) | Operating Temperature (Min) | RPM | Torque - Rated (mNm) | Torque - Rated (oz-in) | Motor Type | Power - Rated | Voltage - Rated | Mounting Hole Spacing | Torque - Max Momentary (oz-in) | Torque - Max Momentary (mNm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Portescap STANDARD MOTOR 11000 RPM 6V | Sign in to see pricing | DC Motor | 0.059 in | Round | 0.315 in | Standard | 0.197 in | Solder Tab | 85 °C | -30 °C | 11000 RPM | 0.63 mNm | 0.089 oz-in | Brushed | 500 mW | 6 VDC | — | — | — |
 Portescap 12G88 210E.1001 | Sign in to see pricing | DC Motor | 0.059 in | Round | 0.472 in | Standard | 0.276 in | Solder Tab | 85 °C | -30 °C | 10000 RPM | 3.1 mNm | 0.44 oz-in | Brushed | 2.4 W | 9 VAC | — | — | — |
 Portescap 13N88 107.1 | Sign in to see pricing | DC Motor | 0.059 in | Round | 0.511 in | Standard | 0.244 in | Solder Tab | 85 °C | -30 °C | 9000 RPM | 3.2 mNm | 0.46 oz-in | Brushed | 2.5 W | 24 VAC | — | — | — |
 Portescap 16C18 205.67 | Sign in to see pricing | DC Motor | 0.039 in | Round | 0.629 in | Standard | 0.394 in | Wire Leads | 85 °C | -30 °C | 10000 RPM | 0.98 mNm | 0.14 oz-in | Brushed | 0.8 W | 12 VAC | — | — | — |
Portescap 16C18 207.67 | Sign in to see pricing | DC Motor | 0.039 in | Round | 0.629 in | Standard | 0.394 in | Wire Leads | 85 °C | -30 °C | 10000 RPM | 1 mNm | 0.15 oz-in | Brushed | 0.7 W | 6 VDC | — | — | — |
 Portescap STANDARD MOTOR 10000 RPM 18V | Sign in to see pricing | DC Motor | 0.059 in | Round | 0.669 in | Standard | 0.295 in | Solder Tab | 85 °C | -30 °C | 10000 RPM | 4.89 mNm | 0.69 oz-in | Brushed | 3.2 W | 18 VAC | 0.394 in | — | — |
 Portescap STANDARD MOTOR 9000 RPM 24V | Sign in to see pricing | DC Motor | 0.197 in | Round | 1.378 in | Standard | 0.492 in | Quick Connect | 85 °C | -30 °C | 9000 RPM | 52 mNm | 7.36 oz-in | Brushed | — | 32 V | — | 15.435 oz-in | 109 mNm |
 Portescap 16DCP 26P1 107P.1 | Sign in to see pricing | DC Motor | 0.059 in | Round | 0.63 in | Standard | 0.295 in | Solder Tab | 85 °C | -30 °C | 10000 RPM | 2.57 mNm | 0.37 oz-in | Brushed | 1.4 W | 18 VAC | — | — | — |
Portescap 16DCP 26P1 205E.1 | Sign in to see pricing | DC Motor | 0.059 in | Round | 0.63 in | Standard | 0.295 in | Solder Tab | 85 °C | -30 °C | 10000 RPM | 2.49 mNm | 0.36 oz-in | Brushed | 1.3 W | 24 VAC | — | — | — |
Portescap 16DCP 26P1 205P.1 | Sign in to see pricing | DC Motor | 0.059 in | Round | 0.63 in | Standard | 0.295 in | Solder Tab | 85 °C | -30 °C | 10000 RPM | 2.63 mNm | 0.38 oz-in | Brushed | 1.4 W | 12 VAC | — | — | — |
