Product families from PN Junction Semiconductor
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
No series available
This manufacturer doesn't have any product series listed yet. Check back later or contact us if you're looking for specific parts.
Parts from PN Junction Semiconductor that are not part of a series
| Part Information | Pricing (lowest) | Current - Average Rectified (Io) | Technology | Current - Reverse Leakage | Package Name | Operating Temperature - Junction (Max) | Operating Temperature - Junction (Min) | Reverse Recovery Time (trr) | Speed - Fast Recovery (Minimum) | Speed | Speed - Recovery Current | Package / Case | Voltage - DC Reverse (Vr) (Max) | Voltage - Forward (Vf) (Max) | Capacitance | Qualification | Rds On (Max) | Drive Voltage (Max Rds On, Min Rds On) | Current - Continuous Drain (Id) | Power Dissipation (Max) | Drain to Source Voltage (Vdss) | Operating Temperature (Min) | Operating Temperature (Max) | Grade | Mounting Type | Vgs(th) (Max) | FET Type | Vgs (Max) Positive | Vgs (Max) Negative | Package Leads | Input Capacitance (Ciss) (Max) | Gate Charge (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 PN Junction Semiconductor DIODE SIL CARB 650V 21A TO220I-2 | Sign in to see pricing | 21 A | SiC (Silicon Carbide) Schottky | 36 µA | TO-220I-2 | 175 °C | -55 °C | 0 ns | 500 mA | No Recovery Time | 500 mA, 500 mA | TO-220I-2 | 650 V | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 PN Junction Semiconductor DIODE SIL CARB 650V 45A TO220-2 | Sign in to see pricing | 45 A | SiC (Silicon Carbide) Schottky | 100 µA | TO-220-2 | 175 °C | -55 °C | 0 ns | 500 mA | No Recovery Time | 500 mA, 500 mA | TO-220-2 | 650 V | 1.6 V | 904 pF | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 PN Junction Semiconductor SICFET N-CH 650V 68A TO247-3 | Sign in to see pricing | — | SiCFET (Silicon Carbide) | — | TO-247-3L | — | — | — | — | — | — | TO-247-3 | — | — | — | AEC-Q101 | 50 mOhm | 15 V | 68 A | 254 W | 650 V | -55 °C | 175 °C | Automotive | Through Hole | 2.4 V | N-Channel | 20 V | -8 V | — | — | — |
 PN Junction Semiconductor SICFET N-CH 650V 44A TO-263-7 | Sign in to see pricing | — | SiCFET (Silicon Carbide) | — | D2PAK, D2PAK-7 | — | — | — | — | — | — | — | — | — | — | AEC-Q101 | 79 mOhm | 15 V | 44 A | 159 W | 650 V | -55 °C | 175 °C | Automotive | Surface Mount | 2.2 V | N-Channel | 20 V | -8 V | 7 Leads | — | — |
 PN Junction Semiconductor SICFET N-CH 650V 46A TO220-3 | Sign in to see pricing | — | SiCFET (Silicon Carbide) | — | TO-220-2L | — | — | — | — | — | — | TO-220-2 | — | — | — | AEC-Q101 | 79 mOhm | 15 V | 46 A | 170 W | 650 V | -55 °C | 175 °C | Automotive | Through Hole | 2.2 V | N-Channel | 20 V | -8 V | — | — | — |
 PN Junction Semiconductor SICFET N-CH 650V 9A TO-247-3 | Sign in to see pricing | — | SiCFET (Silicon Carbide) | — | TO-247-3L | — | — | — | — | — | — | TO-247-3 | — | — | — | — | 500 mOhm | 15 V | 9 A, 9 A | 38 W | 650 V | -55 °C | 175 °C | — | Through Hole | 2.2 V | N-Channel | 20 V | -8 V | — | 338 pF, 338 pF | 904 nC |
 PN Junction Semiconductor SICFET N-CH 1200V 112A TO-247-4 | Sign in to see pricing | — | SiCFET (Silicon Carbide) | — | TO-247-4L | — | — | — | — | — | — | TO-247-4 | — | — | — | AEC-Q101 | 35 mOhm | 15 V | 112 A | 577 W | 1200 V | -55 °C | 175 °C | Automotive | Through Hole | 2.2 V | N-Channel | 19 V | -8 V | — | — | — |
 PN Junction Semiconductor SICFET N-CH 1200V 47A TO-247-3 | Sign in to see pricing | — | SiCFET (Silicon Carbide) | — | TO-247-3L | — | — | — | — | — | — | TO-247-3 | — | — | — | AEC-Q101 | 96 mOhm | 15 V | 47 A | 221 W | 1200 V | -55 °C | 175 °C | Automotive | Through Hole | 2.4 V | N-Channel | 21 V | -8 V | — | — | — |
 PN Junction Semiconductor SICFET N-CH 1200V 47A TO-247-4 | Sign in to see pricing | — | SiCFET (Silicon Carbide) | — | TO-247-4L | — | — | — | — | — | — | TO-247-4 | — | — | — | AEC-Q101 | 96 mOhm | 15 V | 47 A | 221 W | 1200 V | -55 °C | 175 °C | Automotive | Through Hole | 2.4 V | N-Channel | 21 V | -8 V | — | — | — |
 PN Junction Semiconductor SICFET N-CH 1200V 19A TO-247-3 | Sign in to see pricing | — | SiCFET (Silicon Carbide) | — | TO-247-3L | — | — | — | — | — | — | TO-247-3 | — | — | — | AEC-Q101 | 192 mOhm | 15 V | 19 A | 110 W | 1200 V | -55 °C | 175 °C | Automotive | Through Hole | 2.4 V | N-Channel | 21 V | -8 V | — | — | — |
