The HMC1099LP5DE is a gallium nitride (GaN), broadband power amplifier delivering >10 W with up to 69% PAE across an instantaneous bandwidth of 0.01 GHz to 1.1 GHz, and with a ±0.5 dB typical gain flatness.The HMC1099LP5DE is ideal for pulsed or continuous wave (CW) applications, such as wireless infrastructure, radars, public mobile radios, and general-purpose amplification.The HMC1099LP5DE amplifier is externally tuned using low cost, surface-mount components and is available in a compact LFCSP package.Multifunction pin names may be referenced by their relevant function only.ApplicationsExtended battery operation for public mobile radiosPower amplifier stage for wireless infrastructuresTest and measurement equipmentCommercial and military radarsGeneral-purpose transmitter amplification

The HMC1099PM5E is a gallium nitride (GaN), broadband power amplifier delivering >10 W with up to 69% PAE across an instantaneous bandwidth of 0.01 GHz to 1.1 GHz, and with a ±0.5 dB typical gain flatness.The HMC1099PM5E is ideal for pulsed or continuous wave (CW) applications, such as wireless infrastructure, radars, public mobile radios, and general-purpose amplification.The HMC1099PM5E amplifier is externally tuned using low cost, surface-mount components and is available in a compact LFCSP package.Multifunction pin names may be referenced by their relevant function only.ApplicationsExtended battery operation for public mobile radiosPower amplifier stage for wireless infrastructuresTest and measurement equipmentCommercial and military radarsGeneral-purpose transmitter amplification

The HMC1105 is a passive miniature frequency doubler MMIC. Suppression of undesired fundamental and higher order harmonics is up to 46 dB typical with respect to input signal level. The doubler utilizes the same GaAs Schottky diode/balun technology found in Hittite MMIC mixers. It features small size, requires no DC bias, and adds no measurable additive phase noise onto the multiplied signal.APPLICATIONSPoint-to-Point and VSAT RadiosV-Band CommunicationsTest InstrumentationRadarSpace

The HMC1106 is a double-balanced mixer, which can be used as an upconverter or a downconverter, with DC to 24 GHz at the IF port, 20 to 50 GHz at the LO port, and 15 to 36 GHz at the RF port. This passsive MMIC mixer is fabricated with GaAs Shottky diode technology. All bond pads and the die backside are Ti/Au metallized and the Shottky devices are fully passivated for reliable operation. All data shown herein is measured with the chip in a 50 Ohm environment and contacted with RF probes.APPLICATIONSMicrowave Point-to-Point RadiosSATCOMTest Equipment & SensorsMilitary End-UseAutomotive Radar

The HMC1110 is a ×6 active broadband frequency multiplier chip utilizing GaAs pHEMT technology. When driven by a +4 dBm signal, the multiplier provides +13 dBm typical output power from 71 to 86 GHz. The 5Fo and 7Fo harmonic isolations with respect to the output signal level are +25 dBc and +40dBc respectively. The HMC1110 is ideal for use in LO multiplier chains for Pt-to-Pt & VSAT Radios yielding reduced parts count by integrating input and output amplifiers vs. traditional approach which uses discrete components. All data is taken with the chip connected via two 0.025mm (1 mil) wire bonds of minimal length 0.31 mm (12 mils).APPLICATIONSPoint-to-Point & VSAT RadiosTest InstrumentationMilitary & SpaceSensors

The HMC1113LP5E is a compact GaAs MMIC I/Q downconverter in a leadless 5 x 5 mm low stress injection molded plastic surface mount package. This device provides a small signal conversion gain of 12 dB with a noise figure of 1.8 dB and 25 dBc of image rejection. The HMC1113LP5E utilizes an LNA followed by an image reject mixer which is driven by an LO buffer amplifier. The image reject mixer eliminates the need for a filter following the LNA, and removes thermal noise at the image frequency. I/Q mixer outputs are provided and an external 90° hybrid is needed to select the required sideband. The HMC1113LP5E is a much smaller alternative to hybrid style image reject mixer downconverter assemblies, and it eliminates the need for wire bonding by allowing the use of surface mount manufacturing techniques.ApplicationsPoint-to-Point & Point-to-Multi-Point RadioMilitary Radar, EW & ELINTSatellite CommunicationsMaritime & Mobile Radios

The HMC1114LP5DE is a gallium nitride (GaN), broadband power amplifier, delivering 10 W with more than 50% power added efficiency (PAE) across a bandwidth of 2.7 GHz to 3.8 GHz. The HMC1114LP5DE provides ±0.5 dB gain flatness.The HMC1114LP5DE is ideal for pulsed or continuous wave (CW) applications such as wireless infrastructure, radar, public mobile radio, and general-purpose amplification.The HMC1114LP5DE is housed in a compact LFCSP_CAV package.ApplicationsExtended battery operation for public mobile radiosPower amplifier stage for wireless infrastructureTest and measurement equipmentCommercial and military radarsGeneral-purpose transmitter amplification

TThe HMC1114PM5E is a gallium nitride (GaN), broadband power amplifier delivering >10 W (up to 42 dBm) typical with up to 55% power added efficiency (PAE) across an instantaneous bandwidth range of 2.7 GHz to 3.8 GHz, at an input power (PIN) of 18 dBm. The gain flatness is <1 dB typical at small signal levels.The HMC1114PM5E is ideal for pulsed or continuous wave (CW) applications, such as wireless infrastructure, radars, public mobile radios, and general-purpose amplification.ApplicationsExtended battery operation for public mobile radiosPower amplifier stage for wireless infrastructureTest and measurement equipmentCommercial and military radarsGeneral-purpose transmitter amplification
