Nichicon is a world-leading manufacturer of aluminum electrolytic capacitors with over 70 years of expertise, producing non-solid and solid electrolytic capacitors, conductive polymer hybrid capacitors, and specialty audio-grade capacitors for automotive, IoT, and industrial applications.
Parts that are not part of a series
Company background and product focus
Nichicon has built a 70+ year legacy of producing high-quality aluminum electrolytic capacitors, establishing themselves as a global leader in capacitor technology. Their expertise spans both non-solid aluminum electrolytic capacitors using electrolyte solution and solid aluminum electrolytic capacitors using conductive polymer.
The company's product portfolio includes chip aluminum electrolytic capacitors for high-density PCB surface mounting, large can capacitors for infrastructure applications like UPS and telecom base stations, and specialty audio-grade capacitors including the LKG series with gold-plated terminals for high-fidelity sound reproduction.
© 2026 Zenode. All rights reserved.
Product families from Nichicon
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
| Aluminum Electrolytic Capacitors | 1 | Active | ||
| Aluminum - Polymer Capacitors | 2 | Active | ||
| Capacitors | 2 | Active | ||
| Aluminum - Polymer Capacitors | 4 | Active | ||
| Aluminum - Polymer Capacitors | 13 | Active | ||
| Capacitors | 2 | Active | ||
| Aluminum - Polymer Capacitors | 3 | Active | ||
| Electric Double Layer Capacitors (EDLC), Supercapacitors | 3 | Active | ||
| Electric Double Layer Capacitors (EDLC), Supercapacitors | 3 | Active | ||
| Capacitors | 2 | Active |
Parts from Nichicon that are not part of a series
| Part Information | Pricing (lowest) | Capacitance | Termination | Dielectric Material | Lead Spacing | Operating Temperature (Max) | Operating Temperature (Min) | Size / Dimension Length | Size / Dimension Width | Height - Seated (Max) | Package / Case | Mounting Type | Applications | Voltage Rating - AC | Tolerance (Positive) | Tolerance (Negative) | Features | Size / Dimension Diameter | Voltage Rating - DC | Tolerance | Function | Contents | Utilized IC / Part | Embedded | Type | Ripple Current | Voltage - Rated | Surface Mount Land Width | Surface Mount Land Length | ESR (Equivalent Series Resistance) | Lifetime |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Nichicon CAP FILM 4UF -5% +10% 400VAC RAD | Sign in to see pricing | 4 µF | PC Pins | Metallized, Polypropylene (PP) | 1.346 in | 85 °C | -25 °C | 1.457 in | 0.846 in | 1.417 in | Radial | Through Hole | Motor Run | 400 Vpk | 10 % | 5 % | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
Nichicon CAP FILM 60UF 200V CHASSIS | Sign in to see pricing | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 Nichicon CAP FILM 420UF 10% 1.1KVDC RAD | Sign in to see pricing | 420 µF | Female, Threaded | Polypropylene (PP) | 1.252 in | 85 °C | -40 °C | — | — | 5 in | Can, Radial | Chassis, Stud Mount | DC Filtering, DC Link | — | — | — | Long Life | 3.346 in | 1.1 kVDC | 10 % | — | — | — | — | — | — | — | — | — | — | — |
 Nichicon CAP FILM 260UF 10% 1.3KVDC RAD | Sign in to see pricing | 260 µF | Female, Threaded | Polypropylene (PP) | 1.252 in | 85 °C | -40 °C | — | — | 5 in | Can, Radial | Chassis, Stud Mount | DC Filtering, DC Link | — | — | — | Long Life | 3.346 in | 1300 V | 10 % | — | — | — | — | — | — | — | — | — | — | — |
Nichicon CAP FILM 180UF 10% 1.5KVDC RAD | Sign in to see pricing | 180 µF | Female, Threaded | Polypropylene (PP) | 1.252 in | 85 °C | -40 °C | — | — | 5 in | Can, Radial | Chassis, Stud Mount | DC Filtering, DC Link | — | — | — | Long Life | 3.346 in | 1500 V | 10 % | — | — | — | — | — | — | — | — | — | — | — |
Nichicon CAP FILM 700UF 10% 750VDC RADIAL | Sign in to see pricing | 700 µF | Female, Threaded | Polypropylene (PP) | 1.252 in | 85 °C | -40 °C | — | — | 5 in | Can, Radial | Chassis, Stud Mount | DC Filtering, DC Link | — | — | — | Long Life | 3.346 in | 750 V | 10 % | — | — | — | — | — | — | — | — | — | — | — |
 Nichicon EVAL BOARD FOR SLB BATTERIES | Sign in to see pricing | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | Energy Harvesting and Storage | Board | SLB | No | Power Management | — | — | — | — | — | — |
Nichicon CAPACITOR | Sign in to see pricing | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 Nichicon 25V 220F HYBRID POLYMER CHIP CHI | Sign in to see pricing | 220 µF | — | — | — | 135 °C | -55 °C | — | — | 0.413 in | Can - SMD, Radial | Surface Mount | Automotive | — | — | — | — | 0.315 in | — | 20 % | — | — | — | — | Hybrid | 4.3 A, 645 mA | 25 VAC | 0.327 in | 0.327 in | 18 mOhm | 4000 Hrs |
Nichicon 25V 220F HYBRID POLYMER CHIP CHI | Sign in to see pricing | 220 µF | — | — | — | 135 °C | -55 °C | — | — | 0.425 in | Can - SMD, Radial | Surface Mount | General Purpose | — | — | — | — | 0.315 in | — | 20 % | — | — | — | — | Hybrid | 4.3 A, 645 mA | 25 VAC | 0.327 in | 0.327 in | 18 mOhm | 4000 Hrs |
