P-DUKE Technology is a Taiwan-based manufacturer specializing in high-performance DC-DC converters and AC-DC power supplies for railway, medical, telecommunications, and industrial applications.
Parts that are not part of a series
Company background and product focus
P-DUKE Technology, founded in 1992, is a leading Taiwan-based manufacturer fully committed to the research, development, and production of high-performance power conversion products. With over 30 years of experience in the power conversion field, P-DUKE has become a recognized leader in the low-power conversion market.
The company specializes in developing the highest efficiency DC/DC converters, AC/DC power supplies, and customized power solutions for demanding applications including:
P-DUKE's manufacturing facilities are certified to ISO 9001 and ISO 13485 medical devices quality management systems. All medical products are IEC/EN 60601-1 approved and include ISO 14971 risk management documentation, ensuring the highest standards of quality and compliance.
© 2026 Zenode. All rights reserved.
Product families from P-DUKE Technology
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
| DC DC Converters | 1 | Active | ||
| DC DC Converters | 2 | Active | ||
| Power Supplies - Board Mount | 1 | Active | ||
| DC DC Converters | 2 | Active | ||
| DC DC Converters | 1 | Active | ||
| Power Supplies - Board Mount | 2 | Active | ||
| Power Supplies - Board Mount | 1 | Active | ||
| DC DC Converters | 1 | Active | ||
| DC DC Converters | 6 | Active | ||
| Power Supplies - Board Mount | 4 | Active |
Parts from P-DUKE Technology that are not part of a series
| Part Information | Pricing (lowest) | Type | Voltage - Input (Min) | Voltage - Input (Max) | Size / Dimension Height | Size / Dimension Width | Size / Dimension Length | Number of Outputs | Efficiency | Mounting Type | Applications | Power (Watts) | Voltage - Output 1 | Approval Agency | Package / Case | Current - Output (Max) | Operating Temperature (Min) | Operating Temperature (Max) | Package Leads | Package Name | Features | Voltage - Isolation | Voltage - Output 2 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 P-DUKE Technology DC DC CONVERTER -5V 5W | Sign in to see pricing | Non-Isolated PoL Module | -7 V | -32 V | 0.65 in | 0.3 in | 0.46 in | 1 | 91.5 % | Through Hole | ITE (Commercial) | 5 W | -5 V | CE | 3-SIP Module | 1 A | -40 °C | 85 °C | — | — | — | — | — |
 P-DUKE Technology DC DC CONVERTER -8V 8W | Sign in to see pricing | Non-Isolated PoL Module | -10.5 V | -32 V | 0.65 in | 0.3 in | 0.46 in | 1 | 94 % | Through Hole | ITE (Commercial) | 8 W | -8 V | CE | 3-SIP Module | 1 A | -40 °C | 85 °C | — | — | — | — | — |
P-DUKE Technology DC DC CONVERTER -15V 15W | Sign in to see pricing | Non-Isolated PoL Module | -18 V | -32 V | 0.65 in | 0.3 in | 0.46 in | 1 | 96 % | Through Hole | ITE (Commercial) | 15 W | -15 V | CE | 3-SIP Module | 1 A | -40 °C | 85 °C | — | — | — | — | — |
 P-DUKE Technology DC DC CONVERTER 5V 2W | Sign in to see pricing | Isolated Module | 9 V | 18 V | 0.44 in | 0.36 in | 0.86 in | 1 | 82 % | Through Hole | ITE (Commercial) | 2 w | 5 V | CE | — | 400 mA | -40 °C | 105 °C | 7 Leads | 8-SIP Module | Remote On/Off | 1.6 kV | — |
P-DUKE Technology DC DC CONVERTER 12V 2W | Sign in to see pricing | Isolated Module | 9 V | 18 V | 0.44 in | 0.36 in | 0.86 in | 1 | 85 % | Through Hole | ITE (Commercial) | 2 w | 12 V | CE | — | 167 mA | -40 °C | 105 °C | 7 Leads | 8-SIP Module | Remote On/Off | 1.6 kV | — |
P-DUKE Technology DC DC CONVERTER 24V 2W | Sign in to see pricing | Isolated Module | 9 V | 18 V | 0.44 in | 0.36 in | 0.86 in | 1 | 85 % | Through Hole | ITE (Commercial) | 2 w | 24 V | CE | — | 83 mA | -40 °C | 105 °C | 7 Leads | 8-SIP Module | Remote On/Off | 1.6 kV | — |
P-DUKE Technology DC DC CONVERTER +/-12V 2W | Sign in to see pricing | Isolated Module | 18 V | 36 V | 0.44 in | 0.36 in | 0.86 in | 2 | 85 % | Through Hole | ITE (Commercial) | 2 w | 12 V | CE | — | 83 mA | -40 °C | 105 °C | 7 Leads | 8-SIP Module | Remote On/Off | 1.6 kV | -12 V |
P-DUKE Technology DC DC CONVERTER 5V 2W | Sign in to see pricing | Isolated Module | 18 V | 36 V | 0.44 in | 0.36 in | 0.86 in | 1 | 83 % | Through Hole | ITE (Commercial) | 2 w | 5 V | CE | — | 400 mA | -40 °C | 105 °C | 7 Leads | 8-SIP Module | Remote On/Off | 1.6 kV | — |
P-DUKE Technology DC DC CONVERTER 5V 2W | Sign in to see pricing | Isolated Module | 9 V | 36 V | 0.44 in | 0.36 in | 0.86 in | 1 | 80 % | Through Hole | ITE (Commercial) | 2 w | 5 V | CE | — | 400 mA | -40 °C | 105 °C | 7 Leads | 8-SIP Module | Remote On/Off | 1.6 kV | — |
P-DUKE Technology DC DC CONVERTER 24V 2W | Sign in to see pricing | Isolated Module | 18 V | 36 V | 0.44 in | 0.36 in | 0.86 in | 1 | 85 % | Through Hole | ITE (Commercial) | 2 w | 24 V | CE | — | 83 mA | -40 °C | 105 °C | 7 Leads | 8-SIP Module | Remote On/Off | 1.6 kV | — |
