RS1E Series

Nch 30V 60A Middle Power MOSFET

Catalog

Nch 30V 60A Middle Power MOSFET

Part	Drain to Source Voltage (Vdss)	Current - Continuous Drain (Id) @ 25°C	Power Dissipation (Max)	Rds On (Max) @ Id, Vgs	Mounting Type	Supplier Device Package	Vgs(th) (Max) @ Id	Vgs (Max)	Drive Voltage (Max Rds On, Min Rds On)	Technology	Package / Case	Input Capacitance (Ciss) (Max) @ Vds [Max]	FET Type	Gate Charge (Qg) (Max) @ Vgs	Operating Temperature	Input Capacitance (Ciss) (Max) @ Vds	Gate Charge (Qg) (Max) @ Vgs [Max]
Rohm Semiconductor RS1E130GNTB	30 V	13 A	3 W 22.2 W	11.7 mOhm	Surface Mount	8-HSOP	2.5 V	20 V	4.5 V 10 V	MOSFET (Metal Oxide)	8-PowerTDFN	420 pF	N-Channel	7.9 nC	150 °C
Rohm Semiconductor RS1E240GNTB	30 V	24 A 72 A	3 W 27 W	3.3 mOhm	Surface Mount	8-HSOP	2.5 V	20 V	4.5 V 10 V	MOSFET (Metal Oxide)	8-PowerTDFN		N-Channel	23 nC	150 °C	1500 pF
Rohm Semiconductor RS1E281BNTB1	30 V	28 A 80 A	3 W	2.3 mOhm	Surface Mount	8-HSOP	2.5 V	20 V	4.5 V 10 V	MOSFET (Metal Oxide)	8-PowerTDFN		N-Channel	94 nC	150 °C	5100 pF
Rohm Semiconductor RS1E180BNTB	30 V	60 A	3 W 25 W	4.9 mOhm	Surface Mount	CPT3	2.5 V	20 V	4.5 V 10 V	MOSFET (Metal Oxide)	DPAK (2 Leads + Tab) SC-63 TO-252-3		N-Channel		150 °C	2400 pF	46 nC
Rohm Semiconductor RS1E350BNTB	30 V	35 A 80 A	3 W 35 W	1.7 mOhm	Surface Mount	8-HSOP	2.5 V	20 V	4.5 V 10 V	MOSFET (Metal Oxide)	8-PowerTDFN	7900 pF	N-Channel		150 °C		185 nC
Rohm Semiconductor RS1E200BNTB	30 V	20 A 68 A	3 W 25 W	3.9 mOhm	Surface Mount	8-HSOP	2.5 V	20 V	4.5 V 10 V	MOSFET (Metal Oxide)	8-PowerTDFN		N-Channel	59 nC	150 °C	3100 pF
Rohm Semiconductor RS1E321GNTB1	30 V	32 A 80 A	3 W		Surface Mount	8-HSOP	2.5 V	20 V	4.5 V 10 V	MOSFET (Metal Oxide)	8-PowerTDFN	2850 pF	N-Channel	42.8 nC	150 °C
Rohm Semiconductor RS1E350BNTB1	30 V	35 A 80 A	3 W 35 W	1.7 mOhm	Surface Mount	8-HSOP	2.5 V	20 V	4.5 V 10 V	MOSFET (Metal Oxide)	8-PowerTDFN	7900 pF	N-Channel		150 °C		185 nC
Rohm Semiconductor RS1E240BNTB	30 V	24 A 40 A	3 W 30 W	3.2 mOhm	Surface Mount	8-HSOP	2.5 V	20 V	4.5 V 10 V	MOSFET (Metal Oxide)	8-PowerTDFN		N-Channel	70 nC	150 °C	3900 pF

Catalog

Nch 30V 60A Middle Power MOSFET

Description

Power MOSFETs are made as low ON-resistance devices by the micro-processing technologies useful for wide range of applications. Broad lineup covering compact types, high-power types and complex types to meet various needs in the market.
