L99PM72GXPAdvanced Power Management System IC with embedded LIN and high speed CAN Transceiver supporting CAN Partial Networking | Power Management (PMIC) | 1 | Active | The L99PM72GXP is a power management system IC providing electronic control units with enhanced system power supply functionality including various standby modes as well as LIN and HS CAN physical communication layers. It contains two low drop voltage regulators to supply the system microcontroller and external peripheral loads such as sensors and provides enhanced system standby functionality with programmable local and remote wake up capability.
In addition, five high-side drivers, two low-side drivers and two operational amplifiers increase the system integration level.
The ST standard SPI Interface (3.0) allows control and diagnosis of the device and enables generic software development. |
L99PM72PXPAdvanced power management IC, with embedded LIN and HS CAN transceiver, supporting CAN Partial Networking | Power Management (PMIC) | 2 | Active | The L99PM72PXP is a power management system IC providing electronic control units with enhanced system power supply functionality including various standby modes as well as LIN and HS CAN physical communication layers. It contains two low drop voltage regulators to supply the system microcontroller and external peripheral loads such as sensors and provides enhanced system standby functionality with programmable local and remote wake up capability.
In addition, five high-side drivers, two low-side drivers and two operational amplifiers increase the system integration level.
The ST standard SPI Interface (3.0) allows control and diagnosis of the device and enables generic software development. |
L99SD01-EIntegrated solenoid driver for automotive applications | Power Management (PMIC) | 2 | Active | The L99SD01-E is a device intended for driving inductive loads.
The inputs are CMOS-compatible. The diagnostic outputs CLAMP_FLAG and FAULT provide an indication of demagnetization mode and fault conditions, respectively.
The integrated standard serial interface (I2C) allows to digitally set peak and hold current values and other injection parameters. It also provides detailed diagnostic information. The device should work with pre-programmed peak and hold current values when values are not set by external micro. All injection parameters can be changed during operating conditions and taken into account at the first injection rising edge after the end of communication. Diagnostic information is available in case of overcurrent, overtemperature, overvoltage and open-load. |
L99SM81Programmable Stepper Motor Driver for Automotive Applications with Micro-Stepping and Stall Detection | Motor Drivers, Controllers | 3 | Active | The EVAL-L99SM81VQ is an evaluation board designed to drive one bipolar stepper motor in micro-stepping mode together with coil voltage measurement for stall detection. The evaluation board consists in a motherboard and a daughterboard on which the L99SM81VQ6 is mounted. Both of the evaluation boards provide electronic control modules with enhanced power management power supply functionalities including one standby mode.
The motherboard, based on SPC56 microcontroller, provides the logic section for monitoring and driving the L99SM81VQ6 assembled on the daughterboard.
With the aim of making the board usage and settings simpler, ST provides dedicated user-friendly software with a Graphic User Interface (GUI). This enables the user to set L99SM81VQ6 parameters and at the same time to get real time information from the device, such as voltage measurements, main power supply voltage, fault flags, device junction temperature and much more. |
L99SM81VProgrammable Stepper Motor Driver for Automotive Applications with Micro-Stepping and Stall Detection | Power Management (PMIC) | 1 | Active | The L99SM81V is an automotive grade integrated driver for bipolar two-phase stepper motors capable of current controlled micro-stepping with programmable amplitude. The device features a 5 V voltage regulator to supply external sensors.
The integrated Serial Peripheral Interface (SPI) makes it possible to adjust device parameters, control all operating modes and read out diagnostic information. Digital I/Os are also optionally usable for more flexible and reliable application control. |
| Full Half-Bridge (H Bridge) Drivers | 3 | Active | The EVAL-L99UDL01 evaluation board is designed to demonstrate the centralized control of all the locks available in a car by means of the L99UDL01 device.
The board is composed by a motherboard and a daughterboard. The motherboard, which is based on the SPC560B54 microcontroller, provides the logic section for monitoring and driving the L99UDL01 device assembled on the daughterboard.
With the aim of facilitating the use and configuration of the board, STMicroelectronics provides a dedicated user-friendly software with a graphic user interface (GUI). This GUI enables the user to set the L99UDL01 control parameters and at the same time shows real time diagnostics information as current output and battery voltage monitoring. |
L99VR01Automotive Linear Voltage Regulator with Configurable Output Voltage having 200mA current capability | Integrated Circuits (ICs) | 2 | Active | L99VR01 is a low dropout linear voltage regulator designed for automotive applications available in SO-8 and in PowerSSO-12 packages. The LDO delivers up to 200 mA of load current and consumes as low as 1 μA of quiescent current when the regulator is disabled. The input is 40 V tolerant to withstand load dump, while the operating input voltage range is between 2.15 V and 28 V. The L99VR01 can be configured, through SELx pins, to generate a fixed selectable output voltage (0.8 V; 1.2 V; 1.5 V; 1.8 V; 2.5 V; 2.8 V; 3.3 V or 5 V). High output voltage accuracy (±2%) is kept over wide temperature range, line and load variation. The L99VR01 features enable, reset, advanced thermal warning, fast output discharge and IShort control (IShort control and advanced thermal warning are available only for the L99VR01J). The regulator output current is internally limited so that the device is protected against short-circuit and overload, besides it features over temperature protection; the short current value is configurable by an external resistance in the L99VR01J version. The L99VR01 can operate both in post regulation, attached to a pre-regulated voltage or directly connected to battery. |
L99VR02JAutomotive Linear Voltage Regulator with Configurable Output Voltage having 500mA current capability | Integrated Circuits (ICs) | 1 | Active | L99VR02J is a low dropout linear voltage regulator designed for automotive applications available in PowerSSO-12 packages. The LDO delivers up to 500 mA of load current. It consumes as low as 1 μA of quiescent current when the regulator is disabled. The input is 40 V tolerant to withstand load dump, while the operating input voltage range is between 2.15 V and 28 V.
The L99VR02J can be configured, through SELx pins, to generate a fixed selectable output voltage (0.8 V; 1.2 V; 1.5 V; 1.8 V; 2.5 V; 2.8 V; 3.3 V or 5 V). High output voltage accuracy (±2%) is kept over wide temperature range, line, and load variation.
The L99VR02J features enable, reset, autonomous watchdog, advanced thermal warning, fast output discharge, and Ishortcontrol. The regulator output current is internally limited. The device is protected against short-circuit and overload, besides it features over temperature protection. The short current value is configurable by an external resistance.
The L99VR02J can operate both in post regulation, attached to a preregulated voltage or directly connected to the battery. |
L99VR02XPDual Automotive Linear Voltage Regulator with Configurable Output Voltage (2x250mA Current Capability) | Voltage Regulators - Linear, Low Drop Out (LDO) Regulators | 1 | Active | The L99VR02XP is a low dropout dual linear regulator designed for automotive applications available in a PowerSSO-36 package. The LDO delivers an output current up to 2 x 250 mA, and consumes a quiescent current as low as 1 μA (per each output) when the regulator is disabled.
The input is 40 V tolerant to withstand load dump, while the operating input voltage range is between 2.15 V and 28 V. Each of the L99VR02XP outputs can be configured, through SELx pins, to generate a fixed output voltage (0.8 V; 1.2 V; 1.5 V; 1.8 V; 2.5 V; 2.8 V; 3.3 V or 5 V). High output voltage accuracy (±2%) is kept over wide temperature range, line and load variation.
The L99VR02XP features enable, reset, autonomous watchdog, advanced thermal warning, thermal cluster, fast output discharge, automatic voltage (de)tracking and IShort control. The regulator output current is internally limited so the device is protected against short circuit and overload, besides it features over temperature protection; the short current value is configurable by an external resistance. The L99VR02XP can operate both in post regulation, attached to a pre-regulated voltage, or directly connected to the battery. |
LBP01LED bypass protection | Circuit Protection | 2 | Active | The LBP01 series are bypass switches to be connected in parallel with 1 or 2 LEDs. In case of LED failure, this allows the current to flow through the other LEDs.
It also provides an overvoltage protection against surges defined in IEC 61000-4-2 and IEC 61000-4-5
Their robust dice also protect LEDs against surge.
These devices are compatible with LEDs up to 1 A.
LBP01 are packaged either in SMB or SOT23-5L |
