These high-power, 36 kW-rated transient voltage suppressors in a surface mount package are provided with design features to minimize thermal resistance and cumulative heating. Typical applications include lightning and automotive load dump protection. They are particularly effective at meeting the multi-stroke lightning standard RTCA DO-160, section 22 for aircraft design. This efficient low-profile package design is offered in standoff voltage selections (VWM) of 14 Volts to 400 Volts in either unidirectional or bidirectional construction.

These high-power, 36 kW-rated transient voltage suppressors in a surface mount package are provided with design features to minimize thermal resistance and cumulative heating. Typical applications include lightning and automotive load dump protection. They are particularly effective at meeting the multi-stroke lightning standard RTCA DO-160, section 22 for aircraft design. This efficient low-profile package design is offered in standoff voltage selections (VWM) of 14 Volts to 400 Volts in either unidirectional or bidirectional construction.

These 6.5 kW rated transient voltage suppressors in a surface mount package are provided with design features to minimize thermal resistance and cumulative heating. These devices have the ability to clamp dangerous high voltage, short term transients such as those produced by directed or radiated electrostatic discharge phenomena before entering sensitive component regions of a circuit design. Typical applications include lighting and automotive load dump protection. They are particularly effective at meeting the multi-stroke lightning standard RTCA DO-160, section 22 for aircraft design. This efficient low profile package design is offered in standoff voltage selections (Vwm) of 10 volt to 48 volts in either unidirectional or bidirectional construction

These 7.5 kW rated transient voltage suppressors (TVS) in a surface mount PLAD package are provided with design features to minimize thermal resistance and cumulative heating. These devices have the ability to clamp dangerous high voltage short term transients such as those produced by electrostatic discharge radiated RFI inductive load dumps and the secondary effects of lightning strikes before they reach sensitive component regions of a circuit. Typical applications include lightning and automotive load dump protection. They are particularly effective at meeting the multi-stroke lightning standard RTCA DO-160 section 22 for aircraft design. The all-metal bottom of this space-efficient low profile package provides a very low thermal impedance path for heat to escape to the mounting substrate keeping the junction temperature low. The PLAD7.5KP is offered with standoff voltages (Vwm) from 10 to 48 volts in either unidirectional or bidirectional versions. For more information on PLAD packaged products and our broad range of TVS solutions please see our website

The MPP4200 series of PIN diodes can be used in RF circuits as an on/off element, as a switch, or as a current controlled resistor in attenuators extending over the frequency range from UHF through X band. Switch applications include high-speed switches (ECM systems). TR switches channel or antenna selection switches (Telcom and WLAN applications), duplexers (radar) and digital phase shifters (phased arrays). Attenuator type applications include amplitude modulators, AGC attenuators and power. This series of devices meets RoHS requirements.

The MPS4101-012S is a single chip silicon monolithic series/shunt element. The parasitic inductance is minimized in this design resulting in wide band, low loss, high isolation performance. The back metallization on the monolithic chip is designed to be used with normal solder or epoxy die attach methods. Only pad bonds are needed to mount the monolithic device.

The MPS2R11-608 is a medium-power monolithic microwave surface mount (MMSM) series-shunt pin diode SP2T reflective switch. The technology is a packaged/device integration accomplished at the wafer level. Thermal transfer is optimized by elimination of the traditional package interface. The MPS2R11-608 is completely compatible with pick-and-place and solder-reflow manufacturing techniques. This series of diodes meets RoHS requirements according to EU Directive 2002/95/EC.

This Transient Voltage Suppressor (TVS) series for 1N6356 thru 1N6372 are JEDEC registered selections for both unidirectional and bidirectional devices. The 1N6356 thru 1N6364 are unidirectional and the 1N6365 thru 1N6372 are bi-directional where they all provide a very low specified clamping factor for minimal clamping voltages (VC) above their respective breakdown voltages (VBR) as specified herein. They are most often used in protecting sensitive components from inductive switching transients or induced secondary lightning effects as found in lower surge levels of IEC61000-4-5 . They are also very successful in protecting airborne avionics and electrical systems. Since their response time is virtually instantaneous, they can also protect from ESD and EFT per IEC61000-4-2 and IEC61000-4-4.

This Transient Voltage Suppressor (TVS) series for 1N6356 thru 1N6372 are JEDEC registered selections for both unidirectional and bidirectional devices. The 1N6356 thru 1N6364 are unidirectional and the 1N6365 thru 1N6372 are bi-directional where they all provide a very low specified clamping factor for minimal clamping voltages (VC) above their respective breakdown voltages (VBR) as specified herein. They are most often used in protecting sensitive components from inductive switching transients or induced secondary lightning effects as found in lower surge levels of IEC61000-4-5 . They are also very successful in protecting airborne avionics and electrical systems. Since their response time is virtually instantaneous, they can also protect from ESD and EFT per IEC61000-4-2 and IEC61000-4-4.

This Transient Voltage Suppressor (TVS) series for 1N6356 thru 1N6372 are JEDEC registered selections for both unidirectional and bidirectional devices. The 1N6356 thru 1N6364 are unidirectional and the 1N6365 thru 1N6372 are bi-directional where they all provide a very low specified clamping factor for minimal clamping voltages (VC) above their respective breakdown voltages (VBR) as specified herein. They are most often used in protecting sensitive components from inductive switching transients or induced secondary lightning effects as found in lower surge levels of IEC61000-4-5 . They are also very successful in protecting airborne avionics and electrical systems. Since their response time is virtually instantaneous, they can also protect from ESD and EFT per IEC61000-4-2 and IEC61000-4-4.
