Product families from Insight SIP
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
Parts from Insight SIP that are not part of a series
| Part Information | Pricing (lowest) | Utilized IC / Part | Frequency | Type | Contents | Mounting Type | Current - Receiving | Package / Case | Protocol | Power - Output | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Sensitivity | Serial Interfaces | Current - Transmitting | Memory Size (Flash) | Memory Type | Memory Size (RAM) | Memory Size (SRAM) | Antenna Type | Operating Temperature (Min) | Operating Temperature (Max) | RF Family/Standard | Data Rate | Frequency (Min) | Frequency (Max) | Memory Size | Current - Transmitting (Max) | Current - Transmitting (Min) | Memory Size ({type}) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Insight SIP ISP1507-AL TEST BOARD | Sign in to see pricing | ISP1507-AL | 2.4 GHz | ANT, Bluetooth® Smart 4.x Low Energy (BLE), Transceiver | Board | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 Insight SIP ISP1507-AX EVAL KIT | Sign in to see pricing | ISP1507-AX | 2.4 GHz | ANT, Bluetooth® Smart 4.x Low Energy (BLE), Transceiver | Board, Cable | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 Insight SIP RF TXRX MOD BT TH SMD | Sign in to see pricing | nRF52832 | 2.4 GHz | — | — | Surface Mount | 6.5 mA | Module | Bluetooth v5.0 | 4 dBm | 3.6 V | 1.7 V | -96 dBm | ADC, I2C, SPI, UART | 7.1 mA | 512 kB | Flash, RAM | 64 kB | 64 kB | Integrated, Trace | -40 °C | 85 °C | Bluetooth | 1 Mbps | — | — | — | — | — | — |
 Insight SIP RF TXRX MOD BT TH SMD | Sign in to see pricing | nRF52840 | — | — | — | Surface Mount | 6.26 mA | Module | Bluetooth v5.0, Thread, Zigbee® | 8 dBm | 5.5 V | 1.7 V | -103.3 dBm | ADC, I2C, SPI, UART, USB | 16.4 mA | 1 MB | Flash, RAM | — | — | Integrated, Trace | -40 °C | 85 °C | Bluetooth | 2 Mbps | 2.402 GHz | 2.48 GHz | 256 kB | — | — | — |
 Insight SIP ISP1807-LR TEST BOARD | Sign in to see pricing | ISP1807-LR-RS | 2.4 GHz | 802.15.4 (Matter, ANT, Bluetooth® 5.x (BLE), Thread, Transceiver, Zigbee®) | Board | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 Insight SIP RF TXRX MOD BT /ANT CHIP SMD | Sign in to see pricing | nRF52833 | — | — | — | Surface Mount | 6 mA | 62-SMD Module | ANT®, Bluetooth v5.1, Thread, Zigbee® | 8 dBm | 3.6 V | 1.7 V | -104 dBm | ADC, GPIO, I2C, PDM, SPI, UART, USB | — | 512 kB | Flash, SRAM | — | 128 kB | Chip, Integrated | -40 °C | 105 °C | 802.15.4, Bluetooth/ANT | 2 Mbps | 2.36 GHz | 2.5 GHz | — | 6.1 mA | 3.5 mA | — |
 Insight SIP BT 5.1 TEST BOARD | Sign in to see pricing | ISP1907 | 2.4 GHz | Bluetooth® 5.x (BLE), Transceiver | Board | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 Insight SIP BLUETOOTH DEVELOPMENT TOOLS - 802.15.1 BLUETOOTH 5.1 DIRECTION FINDING EVALUATION KIT | Sign in to see pricing | ISP1907 | 2.4 GHz | Bluetooth® 5.x (BLE), Transceiver | Board | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 Insight SIP EVALUATION BOARD FOR ISP2053 | Sign in to see pricing | ISP2053 | 2.4 GHz | 802.15.4 (Thread, ANT, Bluetooth® 5.x (BLE), Transceiver, Zigbee®) | Board | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
Insight SIP RF TXRX MOD BT/ANT TRACE SMD | Sign in to see pricing | nRF5340 | 2.4 GHz | — | — | Surface Mount | 3.7 mA | Module | Bluetooth v5.2, Thread, Zigbee® | 3 dBm | 5.5 V | 1.7 V | -104 dBm | ADC, GPIO, I2C, I2S, PDM, PWM, SPI, UART, USB | — | 1 MB | Flash, RAM, SRAM | 512 kB | 512 kB | Integrated Trace | -40 °C | 105 °C | 802.15.4, Bluetooth/ANT | 2 Mbps | — | — | — | 5.3 mA | 4.1 mA | 512 kB |
