ISP1507 Series
Manufacturer: Insight SIP
Beta
⌘K
BLUETOOTH DEVELOPMENT TOOLS - 802.15.1 TEST BOARD OF ISP1507-AX
| Part | Frequency | Contents | Utilized IC / Part | Type | Data Rate | Mounting Type | Operating Temperature (Min) | Operating Temperature (Max) | Current - Transmitting | Power - Output | Package / Case | Serial Interfaces | Sensitivity | Protocol | Memory Size | Memory Type | Memory Size (Flash) | Current - Receiving | RF Family/Standard | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Antenna Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Insight SIP | 2.4 GHz | Board | ISP1507-AX | ANT Bluetooth® Smart 4.x Low Energy (BLE) Transceiver | ||||||||||||||||||
 Insight SIP | 2.4 GHz | Board Cable | ISP1507-AL | ANT Bluetooth® Smart 4.x Low Energy (BLE) Transceiver | ||||||||||||||||||
 Insight SIP | 2.4 GHz | nRF52810 | 2 Mbps | Surface Mount | -40 °C | 85 °C | 4.6 mA | 4 dBm | Module | ADC I2C SPI UART | -96 dBm | Bluetooth v5.0 | 24 kB | Flash RAM | 192 kB | 4.6 mA | Bluetooth | 3.6 V | 1.7 V | Integrated Trace |
