Product families from Bruckewell
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
No series available
This manufacturer doesn't have any product series listed yet. Check back later or contact us if you're looking for specific parts.
Parts from Bruckewell that are not part of a series
| Part Information | Pricing (lowest) | Current - Average Rectified (Io) | Package / Case | Package Name | Package Length | Package Width | Operating Temperature - Junction (Max) | Operating Temperature - Junction (Min) | Current - Reverse Leakage | Mounting Type | Reverse Recovery Time (trr) | Technology | Voltage - DC Reverse (Vr) (Max) | Voltage - Forward (Vf) (Max) | Speed - Fast Recovery (Minimum) | Speed | Speed - Recovery Current | Qualification | Grade | Diode Pair Count | Diode Configuration | Current - Average Rectified (Io) (per Diode) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bruckewell N CHANNEL MOSFET,100V,SOT-23 | Sign in to see pricing | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 Bruckewell N CHANNEL MOSFET,50V,SOT-363 | Sign in to see pricing | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
Bruckewell P CHANNEL MOSFET,50V,SOT-363 | Sign in to see pricing | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
 Bruckewell DIODE SIL CARBIDE 650V 18A 4DFN | Sign in to see pricing | 18 A | 4-PowerTSFN | 4-DFN | 8 mm | 8 mm | 150 °C | -55 °C | 20 µA | Surface Mount | 0 ns | SiC (Silicon Carbide) Schottky | 650 V | 1.7 V, 1.7 V | 500 mA | No Recovery Time | 500 mA, 500 mA | — | — | — | — | — |
 Bruckewell DIODE SIL CARB 650V 29A TO2522L | Sign in to see pricing | 29 A | DPAK (2 Leads + Tab), SC-63, TO-252-3 | TO-252-2L | — | — | 175 °C | -55 °C | 25 µA | Surface Mount | 0 ns | SiC (Silicon Carbide) Schottky | 650 V | 1.7 V | 500 mA | No Recovery Time | 500 mA, 500 mA | AEC-Q101 | Automotive | — | — | — |
 Bruckewell SIC SCHOTTKY DIODE,1200V,10A,TO- | Sign in to see pricing | 20 A | TO-247-2 | TO-247-2 | — | — | 175 °C | -55 °C | — | Through Hole | — | SiC (Silicon Carbide) Schottky | 1200 V | 1.7 V | — | — | — | — | — | — | — | — |
 Bruckewell DIODE SIL CARB 650V 29A TO220L | Sign in to see pricing | 29 A | TO-220-2 | TO-220-2L | — | — | 175 °C | -55 °C | 25 µA | Through Hole | 0 ns | SiC (Silicon Carbide) Schottky | 650 V | 1.7 V | 500 mA | No Recovery Time | 500 mA, 500 mA | — | — | — | — | — |
 Bruckewell DIODE SIL CARBIDE 650V 30A 4DFN | Sign in to see pricing | 30 A | 4-PowerTSFN | 4-DFN | 8 mm | 8 mm | 150 °C | -55 °C | 25 µA | Surface Mount | 0 ns | SiC (Silicon Carbide) Schottky | 650 V | 1.7 V | 500 mA | No Recovery Time | 500 mA, 500 mA | — | — | — | — | — |
 Bruckewell DIODE ARR SIC 1200V 20A TO220-3L | Sign in to see pricing | — | TO-220-3 | TO-220-3L | — | — | 175 °C | -55 °C | 100 µA | Through Hole | 0 ns | SiC (Silicon Carbide) Schottky | 1200 V | 1.7 V | 500 mA | No Recovery Time | 500 mA, 500 mA | — | — | 1 pair | Common Cathode | 20 A |
 Bruckewell DIODE ARR SIC 650V 21A TO220-3L | Sign in to see pricing | — | TO-220-3 | TO-220-3L | — | — | 175 °C | -55 °C | 25 µA | Through Hole | 0 ns | SiC (Silicon Carbide) Schottky | 650 V | 1.7 V | 500 mA | No Recovery Time | 500 mA, 500 mA | — | — | 1 pair | Common Cathode | 21 A |
