The AD5694R is a low power, quad, 16-bit buffered voltage output DAC. The device includes a 2.5 V, 2 ppm/°C internal reference (enabled by default) and a gain select pin giving a full-scale output of 2.5 V (gain = 1) or 5 V (gain = 2). The device operates from a single 2.7 V to 5.5 V supply, is guaranteed monotonic by design, and exhibits less than 0.1% FSR gain error and 1.5 mV offset error performance. The device is available in a 3 mm × 3 mm LFCSP and a TSSOP package.The AD5694R also incorporates a power-on reset circuit and a RSTSEL pin that ensures that the DAC outputs power up to zero scale or midscale and remain there until a valid write takes place. Each part contains a per-channel power-down feature that reduces the current consumption of the device to 4 μA at 3 V while in power-down mode.The AD5694R uses a versatile 2-wire serial interface that operates at clock rates up to 400 kHz, and includes a VLOGICpin intended for 1.8 V/3 V/5 V logic.Product HighlightsHigh Relative Accuracy (INL).AD5696R (16-bit): ±2 LSB maximum.AD5695R (14-bit): ±1 LSB maximum.AD5694R (12-bit): ±1 LSB maximum.Low Drift 2.5 V On-Chip Reference.2 ppm/°C typical temperature coefficient.5 ppm/°C maximum temperature coefficient.Two Package Options.3 mm × 3 mm, 16-lead LFCSP.16-lead TSSOP.ApplicationsOptical transceiversBase-station power amplifiersProcess control (PLC I/O cards)Industrial automationData acquisition systems

The AD5694R is a low power, quad, 16-bit buffered voltage output DAC. The device includes a 2.5 V, 2 ppm/°C internal reference (enabled by default) and a gain select pin giving a full-scale output of 2.5 V (gain = 1) or 5 V (gain = 2). The device operates from a single 2.7 V to 5.5 V supply, is guaranteed monotonic by design, and exhibits less than 0.1% FSR gain error and 1.5 mV offset error performance. The device is available in a 3 mm × 3 mm LFCSP and a TSSOP package.The AD5694R also incorporates a power-on reset circuit and a RSTSEL pin that ensures that the DAC outputs power up to zero scale or midscale and remain there until a valid write takes place. Each part contains a per-channel power-down feature that reduces the current consumption of the device to 4 μA at 3 V while in power-down mode.The AD5694R uses a versatile 2-wire serial interface that operates at clock rates up to 400 kHz, and includes a VLOGICpin intended for 1.8 V/3 V/5 V logic.Product HighlightsHigh Relative Accuracy (INL).AD5696R (16-bit): ±2 LSB maximum.AD5695R (14-bit): ±1 LSB maximum.AD5694R (12-bit): ±1 LSB maximum.Low Drift 2.5 V On-Chip Reference.2 ppm/°C typical temperature coefficient.5 ppm/°C maximum temperature coefficient.Two Package Options.3 mm × 3 mm, 16-lead LFCSP.16-lead TSSOP.ApplicationsOptical transceiversBase-station power amplifiersProcess control (PLC I/O cards)Industrial automationData acquisition systems

The AD5695R is a low power, quad, 14-bit buffered voltage output DAC. The device includes a 2.5 V, 2 ppm/°C internal reference (enabled by default) and a gain select pin giving a full-scale output of 2.5 V (gain = 1) or 5 V (gain = 2). The device operates from a single 2.7 V to 5.5 V supply, is guaranteed monotonic by design, and exhibits less than 0.1% FSR gain error and 1.5 mV offset error performance. The device is available in a 3 mm × 3 mm LFCSP and a TSSOP package.The AD5695R also incorporates a power-on reset circuit and a RSTSEL pin that ensures that the DAC outputs power up to zero scale or midscale and remain there until a valid write takes place. Each part contains a per-channel power-down feature that reduces the current consumption of the device to 4 μA at 3 V while in power-down mode.The AD5695R uses a versatile 2-wire serial interface that operates at clock rates up to 400 kHz, and includes a VLOGICpin intended for 1.8 V/3 V/5 V logic.Product HighlightsHigh Relative Accuracy (INL).AD5696R (16-bit): ±2 LSB maximum.AD5695R (14-bit): ±1 LSB maximum.AD5694R (12-bit): ±1 LSB maximum.Low Drift 2.5 V On-Chip Reference.2 ppm/°C typical temperature coefficient.5 ppm/°C maximum temperature coefficient.Two Package Options.3 mm × 3 mm, 16-lead LFCSP.16-lead TSSOP.ApplicationsOptical transceiversBase-station power amplifiersProcess control (PLC I/O cards)Industrial automationData acquisition systems

The AD5696R is a low power, quad, 16-bit buffered voltage output DAC. The device includes a 2.5 V, 2 ppm/°C internal reference (enabled by default) and a gain select pin giving a full-scale output of 2.5 V (gain = 1) or 5 V (gain = 2). The device operates from a single 2.7 V to 5.5 V supply, is guaranteed monotonic by design, and exhibits less than 0.1% FSR gain error and 1.5 mV offset error performance. The device is available in a 3 mm × 3 mm LFCSP and a TSSOP package.The AD5696R also incorporates a power-on reset circuit and a RSTSEL pin that ensures that the DAC outputs power up to zero scale or midscale and remain there until a valid write takes place. Each part contains a per-channel power-down feature that reduces the current consumption of the device to 4 μA at 3 V while in power-down mode.The AD5696R uses a versatile 2-wire serial interface that operates at clock rates up to 400 kHz, and includes a VLOGICpin intended for 1.8 V/3 V/5 V logic.Product HighlightsHigh Relative Accuracy (INL).AD5696R (16-bit): ±2 LSB maximum.AD5695R (14-bit): ±1 LSB maximum.AD5694R (12-bit): ±1 LSB maximum.Low Drift 2.5 V On-Chip Reference.2 ppm/°C typical temperature coefficient.5 ppm/°C maximum temperature coefficient.Two Package Options.3 mm × 3 mm, 16-lead LFCSP.16-lead TSSOP.ApplicationsOptical transceiversBase-station power amplifiersProcess control (PLC I/O cards)Industrial automationData acquisition systems

The AD5700/AD5700-1are single-chip solutions, designed and specified to operate as a HART®FSK half-duplex modem, complying with the HART physical layer requirements. The AD5700/AD5700-1 integrate all of the necessary filtering, signal detection, modulating, demodulating and signal generation functions, thus requiring few external components. The 0.5% precision internal oscillator on the AD5700-1 greatly reduces the board space requirements, making it ideal for line-powered applications in both master and slave configurations. The maximum supply current consumption is 115µA, making theAD5700/AD5700-1 an optimal choice for low power loop-powered applications. Transmit waveforms are phase continuous 1200 Hz and 2200 Hz sinusoids. The AD5700/AD5700-1 contain accurate carrier detect circuitry and use a standard UART interface.ApplicationsField transmittersHART multiplexersPLC and DCS analog I/O modulesHART network connectivity

TheAD5700/AD5700-1 are single-chip solutions, designed and specified to operate as a HART®FSK half-duplex modem, complying with the HART physical layer requirements. The AD5700/AD5700-1 integrate all of the necessary filtering, signal detection, modulating, demodulating and signal generation functions, thus requiring few external components. The 0.5% precision internal oscillator on the AD5700-1 greatly reduces the board space requirements, making it ideal for line-powered applications in both master and slave configurations. The maximum supply current consumption is 115µA, making theAD5700/AD5700-1 an optimal choice for low power loop-powered applications. Transmit waveforms are phase continuous 1200 Hz and 2200 Hz sinusoids. The AD5700/AD5700-1 contain accurate carrier detect circuitry and use a standard UART interface.ApplicationsField transmittersHART multiplexersPLC and DCS analog I/O modulesHART network connectivity

The AD571 is an 10-bit successive approximation A/D converter consisting of a DAC, voltage reference, clock, comparator, successive approximation register and output buffers--all fabricated on a single chip. No external components are required to perform a full accuracy 10-bit conversion in 40 µs.Operating on supplies of +5 V to +15 V and -15 V, the AD571 will accepts analog inputs of 0 V to +10 V unipolar of ±5 V bipolar, externally selectable. When the BLANK andCONVERTinput is driven low, the three state outputs will be open and a conversion will commence. Upon completion of the theDATAREADYline goes low and the data pears at the output. Pulling the BLANK andCONVERTinput high blanks the outputs and readies the device for the next version. The AD571 executes a true 10-bit conversion with no missing codes in 40 µs maximum.The AD571 is available in two versions for the 0°C to +70°C temperature range, the AD571J and K. The AD571S guarantees 10-bit accuracy and no missing codes from −55°C to +125°C.PRODUCT HIGHLIGHTSThe AD571 is a complete 10-bit A/D converter. No external components are required to perform a conversion. Full-scale calibration accuracy of ± 0.3% is achieved without external trims.The AD571 is a single chip device employing the most advanced IC processing techniques. Thus, the user has at his disposal a truly precision component with the reliability and low cost inherent in monolithic construction.The AD571 accepts either unipolar (0 V to +10 V) or bipolar (–5 V to +5 V) analog inputs by grounding or opening a single pin.The device offers true 10-bit accuracy and exhibits no missing codes over its entire operating temperature range.Operation is guaranteed with –15 V and +5 V or +15 V supplies. The device will also operate with a –12 V supply.
