| Digital to Analog Converters (DAC) | 8 | Active | |
AD5681Tiny 12-Bit SPInanoDAC+, with ±1 LSB INL and 2ppm/°C Reference | Integrated Circuits (ICs) | 5 | Active | TheAD5683R/AD5682R/AD5681R/AD5683, members of thenanoDAC+®family, are low power, single-channel, 16-/14-/12-bit buffered voltage out digital-to-analog converters (DACs). The devices, except the AD5683, include an enabled by default internal 2.5 V reference, offering 2 ppm/°C drift. The output span can be programmed to be 0 V to VREFor 0 V to 2 × VREF. All devices operate from a single 2.7 V to 5.5 V supply and are guaranteed monotonic by design. The devices are available in a 2.00 mm × 2.00 mm, 8-lead LFCSP or a 10-lead MSOP.The internal power-on reset circuit ensures that the DAC register is written to zero scale at power-up while the internal output buffer is configured in normal mode. The AD5683R/AD5682R/AD5681R/AD5683 contain a power-down mode that reduces the current consumption of the device to 2 µA (maximum) at 5 V and provides software selectable output loads while in power-down mode.The AD5683R/AD5682R/AD5681R/AD5683 use a versatile 3-wire serial interface that operates at clock rates of up to 50 MHz. Some devices also include asynchronousRESETpin and VLOGICpin options, allowing 1.8 V compatibilityProduct HighlightsHigh Relative Accuracy (INL).AD5683R/AD5683 (16-bit): ±2 LSB maximum.Low Drift, 2.5 V On-Chip Reference.2 ppm/°C typical temperature coefficient.5 ppm/°C maximum temperature coefficient.Two Package Options.2.00 mm × 2.00 mm, 8-lead LFCSP.10-lead MSOP.ApplicationsProcess controlsData acquisition systemsDigital gain and offset adjustmentProgrammable voltage sources |
AD5681RTiny 12-Bit SPInanoDAC+, with ±1 LSB INL and 2ppm/°C Reference | Digital to Analog Converters (DAC) | 1 | Active | TheAD5683R/AD5682R/AD5681R/AD5683, members of thenanoDAC+®family, are low power, single-channel, 16-/14-/12-bit buffered voltage out digital-to-analog converters (DACs). The devices, except the AD5683, include an enabled by default internal 2.5 V reference, offering 2 ppm/°C drift. The output span can be programmed to be 0 V to VREFor 0 V to 2 × VREF. All devices operate from a single 2.7 V to 5.5 V supply and are guaranteed monotonic by design. The devices are available in a 2.00 mm × 2.00 mm, 8-lead LFCSP or a 10-lead MSOP.The internal power-on reset circuit ensures that the DAC register is written to zero scale at power-up while the internal output buffer is configured in normal mode. The AD5683R/AD5682R/AD5681R/AD5683 contain a power-down mode that reduces the current consumption of the device to 2 µA (maximum) at 5 V and provides software selectable output loads while in power-down mode.The AD5683R/AD5682R/AD5681R/AD5683 use a versatile 3-wire serial interface that operates at clock rates of up to 50 MHz. Some devices also include asynchronousRESETpin and VLOGICpin options, allowing 1.8 V compatibilityProduct HighlightsHigh Relative Accuracy (INL).AD5683R/AD5683 (16-bit): ±2 LSB maximum.Low Drift, 2.5 V On-Chip Reference.2 ppm/°C typical temperature coefficient.5 ppm/°C maximum temperature coefficient.Two Package Options.2.00 mm × 2.00 mm, 8-lead LFCSP.10-lead MSOP.ApplicationsProcess controlsData acquisition systemsDigital gain and offset adjustmentProgrammable voltage sources |
| Digital to Analog Converters (DAC) | 2 | Active | |
| Development Boards, Kits, Programmers | 2 | Active | |
| Data Acquisition | 11 | Active | |
AD5684Quad, 12-BitnanoDAC+ with 2 ppm/°C On-Chip Reference and SPI Interface | Development Boards, Kits, Programmers | 10 | Active | The AD5686/AD5684, a member of thenanoDAC+™ family, is a low power, quad, 16-/12-bit buffered voltage output DAC. The device includes a gain select pin giving a full-scale output of 2.5 V (gain = 1) or 5 V (gain = 2). All devices operate from a single 2.7 V to 5.5 V supply, is guaranteed monotonic by design, and exhibits less than 0.1% FSR gain error and 1.5 mV offset error performance. The devices are available in a 3 mm × 3 mm LFCSP and a TSSOP package.The AD5686/AD5684 also incorporate a power-on reset circuit and a RSTSEL pin that ensures that the DAC outputs power up to zero scale or midscale and remain at that level until a valid write takes place. Each part contains a per-channel power-down feature that reduces the current consumption of the device to 4 μA at 3 V while in power-down mode.The AD5686/AD5684 employ a versatile SPI interface that operates at clock rates up to 50 MHz, and all devices contain a VLOGICpin intended for 1.8 V/3 V/5 V logic.Product HighlightsHigh Relative Accuracy (INL): ±2 LSB maximumExcellent DC Performance.Total unadjusted error: ±0.1% of FSR maximumOffset error: ±1.5 mV maximumGain error: ±0.1% of FSR maximumTwo Package Options: 3 mm × 3 mm, 16-lead LFCSP and 16-lead TSSOPApplicationsDigital gain and offset adjustmentProgrammable attenuatorsProcess control (PLC I/O cards)Industrial automationData acquisition systems |
AD5684RQuad, 12-BitnanoDAC+ with 2 ppm/°C On-Chip Reference and SPI Interface | Digital to Analog Converters (DAC) | 1 | Active | The AD5684RnanoDAC+™ is a quad, 12-bit, rail-to-rail, voltage output DAC. The device includes a 2.5V, 2ppm/˚C internal reference (enabled by default) and a gain select pin giving a full-scale output of 2.5V (gain=1) or 5V (gain=2). The device operates from a single 2.7 V to 5.5 V supply, is guaranteed monotonic by design and exhibits less than 0.1% FSR gain error and 1.5mV offset error performance. The device is available in a 3mm X 3mm LFCSP and a TSSOP package.The AD5684R also incorporates a power-on-reset circuit and a RSTSEL pin that ensures the DAC outputs power up to zero-scale or midscale, and remain there until a valid write takes place. Each device contains a per-channel power-down feature that reduces the current consumption of the device to 4 uA at 3 V while in power-down mode.The AD5684R employs a versatile SPI interface that operates at clock rates up to 50 MHz and includes a VLOGICpin intended for 1.8V/3V/5V logic.PRODUCT HIGHLIGHTSHigh relative accuracy: AD5684R (12-bit): ±1LSB INL maxLow drift on-chip reference: 2.5V, 2ppm/°C temperature driftTwo package options: 3mm × 3mm 16-lead LFCSP or 16-lead TSSOPAPPLICATIONSOptical transceiversBase-station power amplifiersProcess control (PLC I/O cards)Industrial automationData acquisition systems |
AD5685RQuad, 14-BitnanoDAC+ with 2 ppm/°C On-Chip Reference and SPI Interface | Digital to Analog Converters (DAC) | 5 | Active | The AD5685RnanoDAC+™ is a quad, 14-bit, rail-to-rail, voltage output DAC. The device includes a 2.5V, 2ppm/˚C internal reference (enabled by default) and a gain select pin giving a full-scale output of 2.5V (gain=1) or 5V (gain=2).The device operates from a single 2.7 V to 5.5 V supply, is guaranteed monotonic by design and exhibits less than 0.1% FSR gain error and 1.5mV offset error performance. The device is available in a 3mm X 3mm LFCSP and a TSSOP package.The AD5685R also incorporates a power-on-reset circuit and a RSTSEL pin that ensures the DAC outputs power up to zero-scale or midscale, and remain there until a valid write takes place. Each device contains a per-channel power-down feature that reduces the current consumption of the device to 4 uA at 3 V while in power-down mode.The AD5685R employs a versatile SPI interface that operates at clock rates up to 50 MHz and includes a VLOGICpin intended for 1.8V/3V/5V logic.PRODUCT HIGHLIGHTSHigh Relative Accuracy: AD5685R (14-bit): ±1LSB INL maxLow drift on-chip reference: 2.5V, 2ppm/°C temperature driftTwo package options: 3mm × 3mm 16-lead LFCSP or 16-lead TSSOPAPPLICATIONSOptical transceiversBase-station power amplifiersProcess control (PLC I/O cards)Industrial automationData acquisition systems |
| Evaluation Boards | 12 | Active | |
