| Power Supply Controllers, Monitors | 8 | Active | |
| Drivers, Receivers, Transceivers | 2 | Obsolete | |
| Interface | 2 | Obsolete | |
MAX3451±15kV ESD-Protected USB Transceivers | Interface | 2 | Active | The MAX3450E/MAX3451E/MAX3452E USB-compliant transceivers interface low-voltage ASICs with USB devices. The devices fully comply with USB 1.1 and USB 2.0 when operating at full (12Mbps) and low (1.5Mbps) speeds. The MAX3450E/MAX3451E/ MAX3452E operate with VLas low as +1.65V, ensuring compatibility with low-voltage ASICs.The MAX3450E/MAX3451E/MAX3452E feature a logic-selectable suspend mode that reduces current consumption to less than 40µA. Integrated ±15kV ESD protection protects the USB D+ and D- bidirectional bus connections. The MAX3450E is pin compatible with Micrel's MIC2550A. The MAX3451E features an internal 1.5kΩ USB pullup resistor and an enumeration function that allows devices to logically disconnect while plugged in. The MAX3452E provides a push-pull bus-detect (BD) output that asserts high when VBUSis greater than +4.0V.The MAX3450E/MAX3451E/MAX3452E operate over the -40°C to +85°C extended temperature range and are available in 14-pin TSSOP and 3mm x 3mm 16-pin thin QFN packages.ApplicationsCell PhonesData CradlesMP3 PlayersPC PeripheralsPDAs |
| Integrated Circuits (ICs) | 1 | Obsolete | |
| Interface | 2 | Obsolete | |
| Integrated Circuits (ICs) | 2 | Active | |
MAX3454E±15kV ESD-Protected USB Transceivers | Drivers, Receivers, Transceivers | 4 | Active | The MAX3453E–MAX3456E ±15kV ESD-protected USB-compliant transceivers interface low-voltage ASICs with USB devices. The devices fully comply with USB 1.1 and USB 2.0 when operating at full (12Mbps) and low (1.5Mbps) speeds. The MAX3453E–MAX3456E operate with VLas low as +1.65V, ensuring compatibility with low-voltage ASICs.The MAX3453E–MAX3456E feature a logic-selectable suspend mode that reduces current consumption to less than 40µA. Integrated ±15kV ESD protection protects the USB D+ and D- bidirectional bus connections.The MAX3453E supports only full-speed (12Mbps) operation. The MAX3453E/MAX3454E feature an internal 1.5kΩ USB pullup resistor and an enumeration function that allows devices to logically disconnect while plugged in. The MAX3453E/MAX3455E provide a push-pull bus-detect (BD) output that asserts high when VBUS> +4.0V.The MAX3453E–MAX3456E operate over the extended temperature range (-40°C to +85°C) and are available in 14-pin TSSOP and 16-pin (3mm x 3mm) thin QFN packages.ApplicationsCellular TelephonesData CradlesMP3 PlayersPC PeripheralsPDAs |
| Power Management (PMIC) | 2 | Active | |
| Development Boards, Kits, Programmers | 3 | Active | |
