The MAX20430 is a high-efficiency, four-output DC-DC converter and windowed watchdog. OUT1 is a synchronous step-down converter that converts vehicle battery voltage to 3.3V at up to 2.5A. OUT3 boosts OUT1 to 5V at up to 500mA, while OUT2 and OUT4 low-voltage synchronous step-down converters operate from OUT1 and provide a 0.8V to 3.9875V output voltage range at up to 3A. All outputs achieve ±1.5% output error over load, line, and temperature range.The device features 2.1MHz fixed-frequency PWM mode for all DC-DC outputs for better noise immunity and load-transient response. The 2.1MHz frequency operation allows for the use of all ceramic capacitors and minimizes external components. The programmable spread-spectrum frequency modulation minimizes radiated electromagnetic emissions. Integrated low RDSONswitches improve efficiency at heavy loads and make the layout much simpler with respect to discrete solutions.The device is offered with factory-preset output voltages. Other features include soft-start, overcurrent, and overtemperature protections.ApplicationsADAS

The MAX20431/MAX20432 are high-efficiency, four-/three-output DC-DC converters with a windowed watchdog. The OUT1 is a synchronous step-down converter that converts vehicle battery voltage to 3.3V at up to 2.5A. The OUT3 boosts the OUT1 to 5V at up to 500mA, while the OUT2/OUT4 (MAX20431) or OUT2 (MAX20432) low-voltage synchronous step-down converters operate from OUT1 and provide a 0.5V to 3.6875V output voltage range at up to 3A. All outputs achieve ±1.5% output error over load, line, and temperature range.The devices feature a 2.1MHz fixed-frequency PWM mode for all DC-DC outputs for better noise immunity and load-transient response. The 2.1MHz frequency operation allows for the use of all ceramic capacitors and minimizes the external components. The programmable spread-spectrum frequency modulation minimizes the radiated electromagnetic emissions. Integrated low RDSONswitches improve efficiency at heavy loads and make the layout much simpler with respect to discrete solutions.The devices features the MAXQ®power architecture, which provides precision transient performance and phase margin. This allows to obtain the maximum power, performance, and precision while minimizing system cost for any specific application.The devices are offered with factory-preset output voltages. Other features include soft-start, overcurrent, and overtemperature protection.APPLICATIONSAdvanced Driver-Assistance Systems (ADAS)

The MAX20438 is an ultra-high-efficiency switching regulator that delivers up to 12A load current from 0.5V to 1.2V. The IC operates from 2.5V to 5.5V, making it ideal for on-board, point-of-load (PoL) and post regulation applications. The total output error is less than ±1.0% over load, line, and temperature.The MAX20438 features adaptive on-time with a switching frequency of 2.1MHz or 4.2MHz. High-frequency operation allows for small-size, all-ceramic capacitor design.The low-resistance, on-chip switches ensure high efficiency at heavy loads while minimizing critical inductances, making the layout a much simpler task with respect to discrete solutions.The device features the MAXQ™power architecture which provides precision transient performance and phase margin. This allows obtaining the maximum power, performance, and precision from the converter over a very wide range of configurations.The output voltage is preset at the factory to allow customers to achieve ±1% output-voltage accuracy without using expensive 0.1% resistors. The device offers factory-programmable soft-start andRESETtimes.The device includes overtemperature shutdown and overcurrent limiting. The MAX20438 is designed to operate in the -40°C to +125°C ambient temperature range.APPLICATIONSSecondary Regulator for SoC/MCU SupplyPoL and Post-Regulation Applications

The MAX20444C is a 4-channel backlight driver IC with boost controller for automotive displays. The integrated current outputs can sink up to 130mA LED current each. The device accepts a wide 4.5V to 36V input voltage range and withstands direct automotive load-dump events.The internal current-mode switching DC-DC controller supports boost or SEPIC topologies and operates in the 400kHz to 2.2MHz frequency range. Integrated spread spectrum helps reduce EMI. An adaptive output-voltage-control scheme minimizes power dissipation in the LED current-sink paths.The device features I2C-controlled pulse-width-modulation (PWM) dimming and hybrid dimming. In either case, the minimum pulse width is 500ns. Phase-shifted dimming of the strings is incorporated for lower EMI.Comprehensive diagnostic information is also available through the I2C interface, while stand-alone operation is also supported.The MAX20444C is available in a 24-pin TQFN or 24-pin side-wettable TQFN (SWTQFN) package and operates over the -40°C to +125°C temperature range.ApplicationsCentral Information DisplaysInfotainment DisplaysInstrument Clusters

The MAX20444C is a 4-channel backlight driver IC with boost controller for automotive displays. The integrated current outputs can sink up to 130mA LED current each. The device accepts a wide 4.5V to 36V input voltage range and withstands direct automotive load-dump events.The internal current-mode switching DC-DC controller supports boost or SEPIC topologies and operates in the 400kHz to 2.2MHz frequency range. Integrated spread spectrum helps reduce EMI. An adaptive output-voltage-control scheme minimizes power dissipation in the LED current-sink paths.The device features I2C-controlled pulse-width-modulation (PWM) dimming and hybrid dimming. In either case, the minimum pulse width is 500ns. Phase-shifted dimming of the strings is incorporated for lower EMI.Comprehensive diagnostic information is also available through the I2C interface, while stand-alone operation is also supported.The MAX20444C is available in a 24-pin TQFN or 24-pin side-wettable TQFN (SWTQFN) package and operates over the -40°C to +125°C temperature range.ApplicationsCentral Information DisplaysInfotainment DisplaysInstrument Clusters

The MAX20446 is a 6-channel backlight driver with boost controller for automotive displays. The integrated current outputs can sink up to 130mA LED current each. The device accepts a wide 4.5V to 36V input voltage range and withstands direct automotive load-dump events.The internal current-mode switching DC-DC controller supports boost or SEPIC topologies and operates in the frequency range 400kHz to 2.2MHz. Integrated spread spectrum helps reduce EMI. An adaptive output-voltage control scheme minimizes power dissipation in the LED current-sink paths.The device features I2C-controlled pulse-width modulation (PWM) dimming and hybrid dimming. In either case the minimum pulse width is 500ns. Phase-shifted dimming of the strings is incorporated for lower EMI.Comprehensive diagnostic information is also available via the I2C interface.The MAX20446 is available in a TQFN package and operates in the -40°C to 125°C temperature range.Design Solution: Overcome the Design Challenges of New Automotive Display Backlights ›ApplicationsCentral Information DisplaysInfotainment DisplaysInstrument Clusters
