Analog Devices Inc./Maxim Integrated

The Himalaya series of voltage regulator ICs, power modules, and chargers enable cooler, smaller, and simpler power supply solutions. The MAX17760 is a high-efficiency, high-voltage, Himalaya synchronous step-down DC-DC converter with integrated MOSFETs operating over an input-voltage range of 4.5V to 76V. The device can deliver up to 300mA current. Output voltage is programmable from 0.8V up to 88% of input voltage (VIN). Built-in control loop compensation eliminates the need for external components.The MAX17760 features a peak-current-mode control architecture. The device can be operated in either the forced pulse-width modulation (PWM) or pulse-frequency modulation (PFM) control schemes. Forced PWM mode provides constant frequency operation at all loads for frequency sensitive applications, while PFM mode provides superior light-load efficiency by skipping pulses. The device integrates an open drain active-low RESET output voltage monitor, adjustable input undervoltage lockout (EN/UVLO) and programmable soft-start.The feedback voltage regulation accuracy over -40°C to +125°C is +1.6% to -1.7%. The MAX17760 is available in a compact 12-pin (3mm x 3mm) TDFN package. Simulation models are available.ApplicationsIndustrial Control Power SuppliesGeneral Purpose Point-of-LoadDistributed Supply RegulationBase Station Power SuppliesWall Transformer RegulationHigh Voltage Single-Board Systems

The MAX17761, high-efficiency, high-voltage, synchronous step-down DC-DC converter with integrated MOSFETs operates over a 4.5V to 76V input. The converter can deliver up to 1A current. Output voltage is programmable from 0.8V up to 90% of VIN. The feedback voltage regulation accuracy over -40°C to +125°C is ±1.5%.The device features a peak-current-mode control architecture and can be operated in either the pulse-width modulation (PWM) or pulse-frequency modulation (PFM) control schemes.The MAX17761 is available in a 12-pin (3mm x 3mm) TDFN package. Simulation models are available.ApplicationsBasestation Power SuppliesDistributed Supply RegulationGeneral-Purpose Point-of-LoadHigh-Voltage, Single-Board SystemsIndustrial Control Power SuppliesWall Transformer Regulation

The Himalaya series of voltage regulator ICs, power modules, and chargers enable cooler, smaller, and simpler power supply solutions. The MAX17783C is a high-efficiency, high-voltage, Himalaya step-down DC-DC converter with an integrated high-side MOSFET operating over a wide input-voltage range of 6V to 60V. It can deliver up to 2.5A current, and generate output voltages from 0.9V up to 90% of VIN. The device features internal compensation.The MAX17783C device uses peak current-mode control architecture. The device operates in Low Iqmode at light loads to enable high efficiency. The MAX17783C offers a low minimum on-time that allows high switching frequencies and smaller solution sizes.The feedback-voltage regulation accuracy is ±1.6% over -40°C to +125°C. The MAX17783C is available in a compact 10-pin (3mm x 3mm) TDFN package. Simulation models are available.ApplicationsIndustrial and Commercial Power DistributionGeneral Purpose Point-of-LoadDistributed Supply RegulationBase-Station Power SuppliesWall Transformer RegulationHigh-Voltage, Single-Board SystemsSet Top BoxesAudio Power SuppliesLED Displays

The MAX178 is a complete, calibrated 12-bit A/D converter (ADC) which includes a precision voltage reference, track-and-hold, and conversion clock. Internal calibration circuitry maintains true 12-bit performance over the full operating temperature range without external adjustments. In addition, each conversion includes an auto-zero cycle which reduces zero errors to typically below 100μV.CHIP SELECT, READ, and WRITE inputs are included for easy microprocessor interfacing without additional logic. 2-byte, 12-bit conversion data is provided over an 8-bit three-state output bus. Either byte may be read first. Two converter busy flags facilitate polling of the converter's status.The MAX178's analog input range is 0V to +5V when using a +5V reference. The MAX178A's internal reference accuracy is ±0.3%, while the MAX178B is intended for use with an external reference.ApplicationsAudio and Telecom ProcessingDigital-Signal ProcessingHigh-Accuracy Process ControlHigh-Speed Data Acquisition
