American Zettler, Inc. is a leading manufacturer of electromechanical relays offering over forty relay types for HVAC, solar, EV charging, automotive, and industrial control applications.
Parts that are not part of a series
Company background and product focus
American Zettler, Inc., a division of Zettler Group North America located in Southern California, provides application engineering, sales, and distribution for a broad range of electromechanical relays. The company serves diverse commercial and industrial applications with reliable relay solutions.
American Zettler produces over forty different relay types, including:
Zettler relays are trusted across multiple industries including HVAC/R, lighting, solar, electric vehicle charging, metering, automotive, telecommunications, security systems, home appliances, test and measurement, and industrial controls.
© 2026 Zenode. All rights reserved.
Product families from American Zettler
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
| Power Relays, Over 2 Amps | 2 | Active | ||
| Power Relays, Over 2 Amps | 2 | Active | ||
| Relays | 5 | Active | ||
| Relays | 4 | Active | ||
| Power Relays, Over 2 Amps | 22 | Active | ||
| Power Relays, Over 2 Amps | 1 | Active | ||
| Power Relays, Over 2 Amps | 19 | Active | ||
| Relays | 23 | Active | ||
| Relays | 23 | Active | ||
| Power Relays, Over 2 Amps | 58 | Active |
Parts from American Zettler that are not part of a series
| Part Information | Pricing (lowest) | Coil Current | Form A Count | Contact Form | Switching Voltage AC (Max) | Termination Style | Contact Rating (Current) | Coil Voltage | Coil Insulation | Release Time | Coil Type | Relay Type | Mounting Type | Operate Time | Load - Max Switching (Apparent Power) | Contact Material | Must Release Voltage | Must Operate Voltage | Approval Agency | Operating Temperature (Min) | Operating Temperature (Max) | Seal Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 American Zettler ELECTROMECHANICAL RELAY 48VAC 5A | Sign in to see pricing | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — |
American Zettler AZ160-1AE-12D | Sign in to see pricing | 0.075 A | 1 | SPST-NO | 480 VAC | PC Pin | 60 A | 12 VAC | Class F | 10 ms | Non Latching | General Purpose | Through Hole | 20 ms | 28800 VA | Silver Tin Oxide (AgSnO) | 0.6 VAC | 9 VDC | CQC, cURus, TUV | -40 °C | 85 °C | — |
 American Zettler 60 AMP POWER RELAY | Sign in to see pricing | 0.075 A | 1 | SPST-NO | 480 VAC | PC Pin | 60 A | 12 VAC | Class F | 10 ms | Non Latching | General Purpose | Through Hole | 20 ms | 28800 VA | Silver Tin Oxide (AgSnO) | 0.6 VAC | 9 VDC | CQC, cURus, TUV | -40 °C | 85 °C | Fully, Sealed |
American Zettler AZ160-1AE-18D | Sign in to see pricing | 50 mA | 1 | SPST-NO | 480 VAC | PC Pin | 60 A | 18 VDC | Class F | 10 ms | Non Latching | General Purpose | Through Hole | 20 ms | 28800 VA | Silver Tin Oxide (AgSnO) | 0.9 VDC | 13.5 VDC | CQC, cURus, TUV | -40 °C | 85 °C | — |
American Zettler AZ160-1AE-18DE | Sign in to see pricing | 50 mA | 1 | SPST-NO | 480 VAC | PC Pin | 60 A | 18 VDC | Class F | 10 ms | Non Latching | General Purpose | Through Hole | 20 ms | 28800 VA | Silver Tin Oxide (AgSnO) | 0.9 VDC | 13.5 VDC | CQC, cURus, TUV | -40 °C | 85 °C | Fully, Sealed |
American Zettler AZ160-1AE-24D | Sign in to see pricing | 0.0375 A | 1 | SPST-NO | 480 VAC | PC Pin | 60 A | 24 VDC | Class F | 10 ms | Non Latching | General Purpose | Through Hole | 20 ms | 28800 VA | Silver Tin Oxide (AgSnO) | 1.2 V | 18 VDC | CQC, cURus, TUV | -40 °C | 85 °C | — |
American Zettler 60 AMP POWER RELAY | Sign in to see pricing | 0.0375 A | 1 | SPST-NO | 480 VAC | PC Pin | 60 A | 24 VDC | Class F | 10 ms | Non Latching | General Purpose | Through Hole | 20 ms | 28800 VA | Silver Tin Oxide (AgSnO) | 1.2 V | 18 VDC | CQC, cURus, TUV | -40 °C | 85 °C | Fully, Sealed |
American Zettler AZ160-1AE-48D | Sign in to see pricing | 18.8 mA | 1 | SPST-NO | 480 VAC | PC Pin | 60 A | 48 V | Class F | 10 ms | Non Latching | General Purpose | Through Hole | 20 ms | 28800 VA | Silver Tin Oxide (AgSnO) | 2.4 V | 36 VDC | CQC, cURus, TUV | -40 °C | 85 °C | — |
American Zettler AZ160-1AE-48DE | Sign in to see pricing | 18.8 mA | 1 | SPST-NO | 480 VAC | PC Pin | 60 A | 48 V | Class F | 10 ms | Non Latching | General Purpose | Through Hole | 20 ms | 28800 VA | Silver Tin Oxide (AgSnO) | 2.4 V | 36 VDC | CQC, cURus, TUV | -40 °C | 85 °C | Fully, Sealed |
American Zettler AZ160-1AE-5D | Sign in to see pricing | 179.9 mA | 1 | SPST-NO | 480 VAC | PC Pin | 60 A | 5 V | Class F | 10 ms | Non Latching | General Purpose | Through Hole | 20 ms | 28800 VA | Silver Tin Oxide (AgSnO) | 0.25 VDC | 3.75 VDC | CQC, cURus, TUV | -40 °C | 85 °C | — |
