SCS230 Series

1200V, 30A, 3-pin THD, Silicon-carbide (SiC) SBD

Manufacturer: Rohm Semiconductor

Catalog

1200V, 30A, 3-pin THD, Silicon-carbide (SiC) SBD

Description

AI

Switching loss reduced, enabling high-speed switching . (3-pin package)

Catalog

1200V, 30A, 3-pin THD, Silicon-carbide (SiC) SBD

Part	Operating Temperature - Junction [Max]	Voltage - Forward (Vf) (Max) @ If [Max]	Current - Average Rectified (Io) (per Diode)	Reverse Recovery Time (trr)	Current - Reverse Leakage @ Vr	Technology	Speed	Voltage - DC Reverse (Vr) (Max) [Max]	Mounting Type	Diode Configuration	Package / Case	Supplier Device Package	Operating Temperature - Junction	Voltage - Forward (Vf) (Max) @ If	Grade	Qualification
Rohm Semiconductor SCS230KE2HRC11	175 ░C	1.6 V	15 A	0 ns	300 µA	SiC (Silicon Carbide) Schottky	500 mA	1.2 kV	Through Hole	1 Pair Common Cathode	TO-247-3	TO-247
Rohm Semiconductor SCS230KE2GC11		1.6 V	15 A	0 ns	300 µA	SiC (Silicon Carbide) Schottky	500 mA	1.2 kV	Through Hole	1 Pair Common Cathode	TO-247-3	TO-247N	175 °C
Rohm Semiconductor SCS230AE2GC11			15 A	0 ns	300 µA	SiC (Silicon Carbide) Schottky	500 mA	650 V	Through Hole	1 Pair Common Cathode	TO-247-3	TO-247N	175 °C	1.55 V
Rohm Semiconductor SCS230AE2HRC	175 ░C		15 A		300 µA	SiC (Silicon Carbide) Schottky	500 mA	650 V	Through Hole	1 Pair Common Cathode	TO-247-3	TO-247		1.55 V	Automotive	AEC-Q101
