| Development Boards, Kits, Programmers | 1 | Obsolete | |
HSP051-2W3YAutomotive 2-line ESD protection for high speed lines | TVS Diodes | 1 | Active | The HSP051-2W3Y is an ESD array designed for high-speed differential lines protection.
The ultralow capacitance variation ensures negligible influence on signal-skew. |
| Circuit Protection | 1 | LTB | |
HSP051-4M54-line ESD protection for high-speed lines | Transient Voltage Suppressors (TVS) | 1 | LTB | The HSP051-4M5 and HSP053-4M5 are a 4-channel ESD array with a rail to rail architecture designed specifically for the protection of high speed differential lines.
The device is packaged in μQFN 1.3 mm x 0.8 mm with a 500 μm pitch. |
| Circuit Protection | 1 | Active | The HSP051-4N10 is a 4-channel ESD array with a rail to rail architecture designed specifically for the protection of high speed differential lines.
The ultralow variation of the capacitance ensures very low influence on signal-skew. The large bandwidth makes it compatible with HDMI 2.0 4K/2K (= 5.94 Gbps) and USB 3.1 (= 10 Gbps)
The device is packaged in μQFN 1.9 mm x 1 mm with a 400 μm pitch. |
HSP053-4M54-line ESD protection for high-speed lines | TVS Diodes | 1 | Active | The HSP051-4M5 and HSP053-4M5 are a 4-channel ESD array with a rail to rail architecture designed specifically for the protection of high speed differential lines.
The device is packaged in μQFN 1.3 mm x 0.8 mm with a 500 μm pitch. |
| Circuit Protection | 1 | Obsolete | |
| TVS Diodes | 3 | Active | |
HSP061-4M10YAutomotive 4-line ESD protection for high speed lines | Circuit Protection | 1 | LTB | The HSP061-4M10Y is a 4-line ultra-low capacitance TVS designed to protect high-speed interfaces with differential lines in automotive applications.
Electro-static discharge (ESD) capability is compliant with ISO 10605, and IEC 61000-4-2, which are system level ESD standards and then with the ESD component level standards with low energy such as human body model (HBM), and charge device model (CDM). The surge capability is compliant with ISO 7637-3.
The large bandwidth is compatible with USB 5Gbps, USB 10Gbps, HDMI2.1 - 12Gbps, FPD-Link III 4 - 16Gbps, GMSL 3 - 12Gbps, 1000BASE-T1, APIX3 6Gbps.
The Y suffix in the part number indicates an AEC-Q101 qualified device for automotive applications.
The device is packaged in a 10-pin QFN of 2.5 mm x 1.0 mm with a nominal height of 0.51 mm. |
HSP062-22-line ESD protection for high speed lines | Circuit Protection | 1 | Obsolete | The HSP062-2 is a 2-channel ESD array with a rail to rail architecture designed specifically for the protection of high speed differential lines.
The ultralow variation of the capacitance ensures very low influence on signal-skew. The large bandwidth makes it compatible with 5 Gbps.
The device is packaged in μQFN-6L (1.45 x 1.0 mm) with a 500 μm pitch. |
