Reed Semiconductor Corp. | Manufacturer Directory | Zenode.ai

R

Reed Semiconductor Corp.

Series

Product families from Reed Semiconductor Corp.

Series	Category	Parts	Status	Description

Standalone parts

Parts that are not part of a series

Standalone parts(32)

Parts from Reed Semiconductor Corp. that are not part of a series

Part Information	Pricing (lowest)	Applications	Number of Channels	Current - Supply	Programmable Features	Package Width	Package Name	Package Length	Internal Switch(s)	Features	Current - Output (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Type	Package / Case	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Function	Voltage - Input (Maximum)	Voltage - Input (Minimum)	Current - Output	Accuracy	Voltage - Input
RS31210AR Reed Semiconductor Corp. IC ELECTRONIC FUSE 10VSON	Sign in to see pricing Log in Sign up free	PCI, PCI-X	1	5 A	Current Limit	3 mm	10-VSON	3 mm	Yes	Latched Fault	5 A	125 °C	-40 °C	Surface Mount	Hot Swap Controller	10-DFN Exposed Pad, 10-VFDFN Exposed Pad	5.5 V	4.5 V	Electronic Fuse	5 V	4.3 V	5 A	15 %	—
RS31210BR Reed Semiconductor Corp. IC ELECTRONIC FUSE 10VSON	Sign in to see pricing Log in Sign up free	PCI, PCI-X	1	5 A	Current Limit	3 mm	10-VSON	3 mm	Yes	Auto Retry	5 A	125 °C	-40 °C	Surface Mount	Hot Swap Controller	10-DFN Exposed Pad, 10-VFDFN Exposed Pad	5.5 V	4.5 V	Electronic Fuse	5 V	4.3 V	5 A	15 %	—
RS31211AR Reed Semiconductor Corp. IC ELECTRONIC FUSE 8WSON	Sign in to see pricing Log in Sign up free	Motherboard	1	4 A	Current Limit	2 mm	8-WSON	2 mm	Yes	Latched Fault	4 A	125 °C	-40 °C	Surface Mount	Hot Swap Controller	8-DFN Exposed Pad, 8-WFDFN Exposed Pad	3.6 V	3 V	Electronic Fuse	—	—	4 A	7.5 %	3.3 V
RS31211BR Reed Semiconductor Corp. IC ELECTRONIC FUSE 8WSON	Sign in to see pricing Log in Sign up free	Motherboard	1	4 A	Current Limit	2 mm	8-WSON	2 mm	Yes	Auto Retry	4 A	125 °C	-40 °C	Surface Mount	Hot Swap Controller	8-DFN Exposed Pad, 8-WFDFN Exposed Pad	3.6 V	3 V	Electronic Fuse	—	—	4 A	7.5 %	3.3 V
RS31211DR Reed Semiconductor Corp. IC ELECTRONIC FUSE 8WSON	Sign in to see pricing Log in Sign up free	Motherboard	1	4 A	Current Limit	2 mm	8-WSON	2 mm	Yes	Auto Retry	4 A	125 °C	-40 °C	Surface Mount	Hot Swap Controller	8-DFN Exposed Pad, 8-WFDFN Exposed Pad	3.6 V	3 V	Electronic Fuse	—	—	4 A	7.5 %	3.3 V
RS31212AR Reed Semiconductor Corp. IC ELECTRONIC FUSE 8WSON	Sign in to see pricing Log in Sign up free	Motherboard	1	4 A	Current Limit	2 mm	8-WSON	2 mm	Yes	Latched Fault	4 A	125 °C	-40 °C	Surface Mount	Hot Swap Controller	8-DFN Exposed Pad, 8-WFDFN Exposed Pad	5.5 V	4.5 V	Electronic Fuse	—	—	4 A	7.5 %	5 V
RS31212BR Reed Semiconductor Corp. IC ELECTRONIC FUSE 8WSON	Sign in to see pricing Log in Sign up free	Motherboard	1	4 A	Current Limit	2 mm	8-WSON	2 mm	Yes	Auto Retry	4 A	125 °C	-40 °C	Surface Mount	Hot Swap Controller	8-DFN Exposed Pad, 8-WFDFN Exposed Pad	5.5 V	4.5 V	Electronic Fuse	—	—	4 A	7.5 %	5 V
RS31212DR Reed Semiconductor Corp. IC ELECTRONIC FUSE 8WSON	Sign in to see pricing Log in Sign up free	Motherboard	1	4 A	Current Limit	2 mm	8-WSON	2 mm	Yes	Auto Retry	4 A	125 °C	-40 °C	Surface Mount	Hot Swap Controller	8-DFN Exposed Pad, 8-WFDFN Exposed Pad	5.5 V	4.5 V	Electronic Fuse	—	—	4 A	7.5 %	5 V
RS31309AR Reed Semiconductor Corp. IC ELECTRONIC FUSE 8WSON	Sign in to see pricing Log in Sign up free	Motherboard	1	4 A	Current Limit	2 mm	8-WSON	2 mm	Yes	Latched Fault	4 A	125 °C	-40 °C	Surface Mount	Hot Swap Controller	8-DFN Exposed Pad, 8-WFDFN Exposed Pad	16.5 V	2.97 V	Electronic Fuse	18 V	2.8 V	4 A	7.5 %	—
RS31309BR Reed Semiconductor Corp. IC ELECTRONIC FUSE 8WSON	Sign in to see pricing Log in Sign up free	Motherboard	1	4 A	Current Limit	2 mm	8-WSON	2 mm	Yes	Auto Retry	4 A	125 °C	-40 °C	Surface Mount	Hot Swap Controller	8-DFN Exposed Pad, 8-WFDFN Exposed Pad	16.5 V	2.97 V	Electronic Fuse	18 V	2.8 V	4 A	7.5 %	—

1–10 of 32

Page 1 of 4
