Product families from Raytac
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
Parts from Raytac that are not part of a series
| Part Information | Pricing (lowest) | RF Family/Standard | Serial Interfaces | Current - Transmitting | Utilized IC / Part | Data Rate | Operating Temperature (Min) | Operating Temperature (Max) | Package / Case | Antenna Type | Protocol | Memory Size (Flash) | Memory Type | Memory Size ({type}) | Memory Size (RAM) | Memory Size (SRAM) | Current - Receiving | Frequency | Modulation | Mounting Type | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Power - Output | Sensitivity | Current - Receiving (Min) | Current - Receiving (Max) | Current - Transmitting (Min) | Current - Transmitting (Max) | Memory Size | Type | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Raytac NORDIC NRF7002+NRF5340 WIFI+BLE | Sign in to see pricing | 802.15.4, Bluetooth, WiFi | SPI | 260 mA | nRF5340, nRF7002 | 86 Mbps | -40 °C | 105 °C | 61-SMD Module | Chip, Integrated | 802.11a, 802.11ac, 802.11ax, 802.11b, 802.11g, 802.11n, Bluetooth v5.4 | 1 MB | Flash, RAM, SRAM | 512 kB | 512 kB | 512 kB | 56 mA | 2.4 GHz, 2.4GHz, 5GHz, 5 GHz | 8-DPSK, CCK, DQPSK, HT20, HT40, MCS0, MSC7, OFDM | Surface Mount | 1.7 V | 5.5 V | 20 dBm | -98 dBm | — | — | — | — | — | — | — |
 Raytac NORDIC NRF7002+NRF5340 WIFI+BLE | Sign in to see pricing | 802.15.4, Bluetooth, WiFi | SPI | 260 mA | nRF5340, nRF7002 | 86 Mbps | -40 °C | 105 °C | 61-SMD Module | PCB Trace | 802.11a, 802.11ac, 802.11ax, 802.11b, 802.11g, 802.11n, Bluetooth v5.4 | 1 MB | Flash, RAM, SRAM | 512 kB | 512 kB | 512 kB | 56 mA | 2.4 GHz, 2.4GHz, 5GHz, 5 GHz | 8-DPSK, CCK, DQPSK, HT20, HT40, MCS0, MSC7, OFDM | Surface Mount | 1.7 V | 5.5 V | 20 dBm | -98 dBm | — | — | — | — | — | — | — |
 Raytac NORDIC NRF7002+NRF5340 WIFI+BLE | Sign in to see pricing | 802.15.4, Bluetooth, WiFi | SPI | 260 mA | nRF5340, nRF7002 | 86 Mbps | -40 °C | 85 °C | 61-SMD Module | Antenna Not Included, U.FL | 802.11a, 802.11ac, 802.11ax, 802.11b, 802.11g, 802.11n, Bluetooth v5.4 | 1 MB | Flash, RAM, SRAM | 512 kB | 512 kB | 512 kB | 56 mA | 2.4 GHz, 2.4GHz, 5GHz, 5 GHz | 8-DPSK, CCK, DQPSK, HT20, HT40, MCS0, MSC7, OFDM | Surface Mount | 1.7 V | 5.5 V | 20 dBm | -98 dBm | — | — | — | — | — | — | — |
 Raytac NORDIC NRF54L15 MODULE WITH CHIP | Sign in to see pricing | 802.15.4, Bluetooth | ADC, I2C, I2S, NFC, PWM, QSPI, SPI, UART | — | nRF54L15 | 4 MHz | -40 °C | 105 °C | 61-SMD Module, Module | Chip, Integrated | Bluetooth v6.0, Matter, Thread, Zigbee® | 1.5 MB | Flash, RAM | — | — | — | — | 2.4 GHz | — | Surface Mount | 1.7 V | 3.6 V | 8 dBm | -101 dBm | 3.3 mA | 3.6 mA | 5 mA | 8.3 mA | 256 kB | — | — |
 Raytac EVAL BOARD FOR NRF54L15 | Sign in to see pricing | — | — | — | nRF54L15 | — | — | — | — | Chip Antenna(s) On-Board | — | — | — | — | — | — | — | 2.4 GHz | — | — | — | — | — | — | — | — | — | — | — | 802.15.4 (Matter, Bluetooth® 6.x (BLE), NFC, Thread, Transceiver, Zigbee®) | Board, Cable |
 Raytac NORDIC NRF54L15 MODULE | Sign in to see pricing | 802.15.4, Bluetooth | ADC, I2C, I2S, NFC, PWM, QSPI, SPI, UART | — | nRF54L15 | 4 MHz | -40 °C | 105 °C | 61-SMD Module, Module | PCB Trace | Bluetooth v6.0, Matter, Thread, Zigbee® | 1.5 MB | Flash, RAM | — | — | — | — | 2.4 GHz | — | Surface Mount | 1.7 V | 3.6 V | 8 dBm | -101 dBm | 3.3 mA | 3.6 mA | 5 mA | 8.3 mA | 256 kB | — | — |
 Raytac NORDIC NRF54L15 MODULE | Sign in to see pricing | 802.15.4, Bluetooth | ADC, I2C, I2S, NFC, PWM, QSPI, SPI, UART | — | nRF54L15 | 4 MHz | -40 °C | 105 °C | 61-SMD Module, Module | Antenna Not Included, U.FL | Bluetooth v6.0, Matter, Thread, Zigbee® | 1.5 MB | Flash, RAM | — | — | — | — | 2.4 GHz | — | Surface Mount | 1.7 V | 3.6 V | 8 dBm | -101 dBm | 3.3 mA | 3.6 mA | 5 mA | 8.3 mA | 256 kB | — | — |
 Raytac NRF7002 MODULE(WIFI MAC LOADED) | Sign in to see pricing | 802.15.4, Bluetooth, WiFi | SPI | 260 mA | nRF7002 | 86 Mbps | -40 °C | 105 °C | 61-SMD Module | Chip, Integrated | ax, g, IEEE 802.11 b, n | — | — | — | — | — | 56 mA | 2.4 GHz, 2.4GHz, 5GHz, 5 GHz | 64-QAM | Surface Mount | — | — | 20 dBm | -98 dBm | — | — | — | — | — | — | — |
 Raytac NORDIC WIFI+BLE DEMO BOARDS (WIF | Sign in to see pricing | — | — | — | AN7002Q, MDBT53, nRF5340, nRF7002 | — | — | — | — | PCB Trace Antenna(s) On-Board | — | — | — | — | — | — | — | 2.4 GHz, 2.4GHz, 5GHz, 5 GHz | — | — | — | — | — | — | — | — | — | — | — | 802.11 a/b/g/n/ac/ax (Wi-Fi, 802.15.4 (Thread, ANT+, Bluetooth® 5.x (BLE), Transceiver, WiFi, WLAN), Zigbee®) | Board, Cable |
 Raytac NRF7002 MODULE(WIFI MAC LOADED) | Sign in to see pricing | 802.15.4, Bluetooth, WiFi | SPI | 260 mA | nRF7002 | 86 Mbps | -40 °C | 105 °C | 61-SMD Module | PCB Trace | 802.11a, 802.11ac, 802.11ax, 802.11b, 802.11g, 802.11n | — | — | — | — | — | 56 mA | 2.4 GHz, 2.4GHz, 5GHz, 5 GHz | DSSS | Surface Mount | 2.9 V | 4.5 V | 20 dBm | -98 dBm | — | — | — | — | — | — | — |
