The MAX263/264 and MAX267/268 CMOS switched-capacitor active filters are designed for precision filtering applications. Center frequency, Q, and operating mode are all selected via pin-strapped inputs. The MAX263/264 uses no external components for a variety of bandpass, lowpass, highpass, notch and allpass filters. The MAX267/268 is dedicated to bandpass applications and includes an uncommitted op-amp. Two second-order filter sections are included in both devices.An input clock and a 5-bit programming input precisely set the filter center/corner frequency. Q is also programmed from 0.5 to 64. Separate clock inputs for each filter half operate either an external clock or a crystal.The MAX263 and 267 operate with center frequencies up to 57kHz while the MAX264 and 268 extend the f0range to 140kHz by employing lower fCLK/f0ratios. The MAX263/264 is supplied in 28 pin wide DIP and small outline packages while the MAX267/268 is supplied in 24 pin narrow DIP and wide SO packages. All devices are available in commercial, extended, and military temperature ranges.

The MAX2640/MAX2641 are low-cost, ultra-low-noise amplifiers designed for applications in the cellular, PCS, GPS, and 2.4GHz ISM frequency bands. Operating from a single +2.7V to +5.5V supply, these devices consume only 3.5mA of current while providing a low noise figure, high gain, high input IP3, and an operating frequency range that extends from 300MHz to 2500MHz.The MAX2640 is optimized for 300MHz to 1500MHz applications, with a typical performance of 15.1dB gain, input IP3 of -10dBm, and a noise figure of 0.9dB at 900MHz. The MAX2641 is optimized for 1400MHz to 2500MHz applications, with a typical performance of 14.4dB gain, an input IP3 of -4dBm, and a noise figure of 1.3dB at 1900MHz.These devices are internally biased, eliminating the need for external bias resistors and chokes. In a typical application, the only external components needed are a two-element input match, input and output blocking capacitors, and a VCCbypass capacitor.The MAX2640/MAX2641 are designed on a high-frequency, low-noise, advanced silicon-germanium process and are offered in the space-saving 6-pin SOT23 package.Applications400MHz/900MHz/2.4GHz ISM-Band RadiosCellular/PCS HandsetsCordless PhonesGPS ReceiversWireless DataWireless Local Area Networks (WLANs)

The MAX26404/MAX26405/MAX26406 ICs are tiny, low EMI emission, synchronous Silent Switcher®buck converters with integrated high-side and low-side switches. The ICs are designed to deliver up to 6A with wide-input voltages range from 3V to 36V. Voltage quality can be monitored by observing the PGOOD signal. The MAX26404/MAX26405/MAX26406 can operate in dropout by running at 99% duty cycle, which makes it ideal for automotive and industrial applications.The MAX26404/MAX26405/MAX26406 offer programmable or fixed output voltages of 5V and 3.3V. Frequency is internally fixed at 2.1MHz (or 400kHz), which allows for small external components, reduced output ripple, and guarantees no AM interference. The MAX26404/MAX26405/MAX26406 automatically enter skip mode at light loads with ultra-low quiescent current of 10μA at no load. This family of products (including the MAX26408/MAX26410) offers a pin-to-pin compatible offering from 4A to 10A in a single-phase configuration, and up to 20A in a dual-phase configuration. These devices are also optimized for dual-phase operation with very high-current sharing accuracy. These devices can be ordered with spread-spectrum frequency modulation designed to minimize EMI-radiated emissions due to the modulation frequency.The MAX26404/MAX26405/MAX26406 are available in a small 3.5mm x 3.75mm, 17-pin FC2QFN package and use very few external components.APPLICATIONSPoint-of-Load Power Supplies12V/24V Industrial ApplicationsTelecom, Servers, and Networking Equipment
