The MAX14738/MAX14739 overvoltage protection devices feature a low 76mΩ (typ) on-resistance (RON) internal FET and protect low-voltage systems against voltage faults up to +36V. When the input voltage exceeds the overvoltage threshold, the internal FET is turned off to prevent damage to the protected components.The overvoltage protection threshold can be adjusted with optional external resistors to any voltage between 4V and 20V. With the OVLO input set below the external OVLO select voltage, the devices automatically choose the accurate internal trip thresholds. The internal overvoltage thresholds (OVLO) are preset to 6.8V (typ) (MAX14738) or 10V (typ) (MAX14739). The devices are also protected against overcurrent events by an internal thermal shutdown.The MAX14738/MAX14739 are offered in a small, 6-bump 1.3mm x 0.9mm wafer-level package (WLP) with an exposed pad and operate over the -40°C to +85°C extended temperature range.ApplicationsMobile Internet DevicesSmartphonesTablet PCs

The MAX14740/MAX14742/MAX20320 compact 6A smart power-path selector with reset control features a low 11mΩ (typ) RON internal FET and provides the system power from two separate power sources. The devices feature reset and disconnect functions to provide system power, reset, and disconnect based on multiple inputs, including active-low MR1, active-low MR2, and TAIN.The devices feature two individual enable inputs to control each power path. The MAX14740 enable function is provided through I2C control, while those of the MAX14741/MAX14742/MAX20320 are performed by GPIO control. Each enable input controls the corresponding path as an independent switch. However, when both paths are enabled, the device can either autoselect the input source or have both inputs connected to the output. When autoselect is chosen, the internal comparator controls the path based on the voltage at the input nodes. The devices also feature an ultra-low supply current, even during an operating state or off state, providing longer battery life.The devices are available in 20-bump (1.6mm × 2.1mm) wafer-level packages (WLPs) and operate over the -40°C to +85°C extended temperature range.ApplicationsCamerasGame ConsoleSmart PhonesTablet PCs

The MAX14740/MAX14742/MAX20320 compact 6A smart power-path selector with reset control features a low 11mΩ (typ) RON internal FET and provides the system power from two separate power sources. The devices feature reset and disconnect functions to provide system power, reset, and disconnect based on multiple inputs, including active-low MR1, active-low MR2, and TAIN.The devices feature two individual enable inputs to control each power path. The MAX14740 enable function is provided through I2C control, while those of the MAX14741/MAX14742/MAX20320 are performed by GPIO control. Each enable input controls the corresponding path as an independent switch. However, when both paths are enabled, the device can either autoselect the input source or have both inputs connected to the output. When autoselect is chosen, the internal comparator controls the path based on the voltage at the input nodes. The devices also feature an ultra-low supply current, even during an operating state or off state, providing longer battery life.The devices are available in 20-bump (1.6mm × 2.1mm) wafer-level packages (WLPs) and operate over the -40°C to +85°C extended temperature range.ApplicationsCamerasGame ConsoleSmart PhonesTablet PCs

The MAX14746/MAX14747 are a series of USB charger detectors with an integrated Smart Power Selector™ linear charger solutions that provide a single-chip solution for charging and charger detection.The MAX14746/MAX14747 charger detectors are compliant to USB Battery Charger Detection Rev 1.2* and capable of detecting multiple USB battery-charging methods, including Standard Downstream Ports (SDP), Charging Downstream Ports (CDP), and Dedicated Charger Ports (DCP). The devices also detect common proprietary charge adapters, including those from Apple.The MAX14746/MAX14747 battery chargers feature Smart Power Selector operation, allowing operation with dead or no battery present. The devices limits USB VBUScurrent based on the detect charger source type. If the charger power source is unable to supply the entire system load, the smart-power control circuit supplements the system load with current from the battery.The devices protect against overvoltage faults up to 28V.This series of USB charger detectors are available with several options, with slight variations in, for example, power-up states. These variations are noted throughout this data sheet.There are five options available with slight variations in, for example, power-up states. The devices are available in a 25-ball, 0.4mm pitch wafer-level package (WLP), and are specified over the -40°C to +85°C extended temperature range.ApplicationsPortable Consumer DevicesPortable Digital CamerasPortable Digital Video CamerasPortable Industrial Devices
