The LTC4162-S is an advanced monolithic synchronous step-down switching battery charger and PowerPath™manager that seamlessly manages power distribution between input sources such as wall adapters, backplanes, solar panels, etc., and a lead-acid battery.A high resolution measurement system provides extensive telemetry information for circuit voltages, currents, battery resistance and temperature which can all be read back over the I2C port. The I2C port can also be used to configure many charging parameters including charging voltages and currents, termination algorithms and numerous system status alerts.The LTC4162-S can charge 6V, 12V, 18V and 24V lead-acid batteries with as much as 3.2A of charge current.The power path topology decouples the output voltage from the battery allowing a portable product to start up instantly under very low battery voltage conditions.The LTC4162-S is available in a thermally enhanced 28-pin 4mm × 5mm × 0.75mm QFN surface mount package.ApplicationsMedical InstrumentsUSB-C Power DeliveryIndustrial HandheldsRuggedized NotebookTablet Computers

The LTC4210 is a 6-pin SOT-23 Hot Swap™controller that allows a board to be safely inserted and removed from a live backplane. An internal high side switch driver controls the GATE of an external N-channel MOSFET for a supply voltage ranging from 2.7V to 16.5V. The LTC4210 provides the initial timing cycle and allows the GATE to be ramped up at an adjustable rate.The LTC4210 features a fast current limit loop providing active current limiting together with a circuit breaker timer. The signal at the ON pin turns the part on and off and is also used for the reset function.This part is available in two options: the LTC4210-1 for automatic retry on overcurrent fault and the LTC4210-2 for latch off on an overcurrent fault.VinRangeRetry / LatchoffLTC4210-12.7V to 16.5VRetry After FaultLTC4210-22.7V to 16.5VLatch Off After FaultLTC4210-32.7V to 7VRetry After FaultLTC4210-42.7V to 7VLatch Off After FaultApplicationsHot Board InsertionElectronic Circuit BreakerIndustrial High Side Switch/Circuit Breaker

The LTC4210 is a 6-pin SOT-23 Hot Swap™controller that allows a board to be safely inserted and removed from a live backplane. An internal high side switch driver controls the GATE of an external N-channel MOSFET for a supply voltage ranging from 2.7V to 16.5V. The LTC4210 provides the initial timing cycle and allows the GATE to be ramped up at an adjustable rate.The LTC4210 features a fast current limit loop providing active current limiting together with a circuit breaker timer. The signal at the ON pin turns the part on and off and is also used for the reset function.This part is available in two options: the LTC4210-1 for automatic retry on overcurrent fault and the LTC4210-2 for latch off on an overcurrent fault.VinRangeRetry / LatchoffLTC4210-12.7V to 16.5VRetry After FaultLTC4210-22.7V to 16.5VLatch Off After FaultLTC4210-32.7V to 7VRetry After FaultLTC4210-42.7V to 7VLatch Off After FaultApplicationsHot Board InsertionElectronic Circuit BreakerIndustrial High Side Switch/Circuit Breaker

The LTC4210-3/LTC4210-4 is a 6-pin SOT-23 Hot Swap controller that allows a board to be safely inserted and removed from a live backplane. An internal high side switch driver controls the GATE of an external N-channel MOSFET for a supply voltage ranging from 2.7V to 7V. The LTC4210 provides the initial timing cycle and allows the GATE to be ramped up at an adjustable rate.The LTC4210 features a fast current limit loop providing active current limiting together with a circuit breaker timer. The signal at the ON pin turns the part on and off and is also used for the reset function.The LTC4210-3 retries on overcurrent fault and the LTC4210-4 latches off on an overcurrent fault.Vin RangeRetry / LatchoffLTC4210-12.7V to 16.5VRetry After FaultLTC4210-22.7V to 16.5VLatch Off After FaultLTC4210-32.7V to 7VRetry After FaultLTC4210-42.7V to 7VLatch Off After FaultApplicationsHot Board InsertionElectronic Circuit BreakerIndustrial High Side Switch/Circuit Breaker
