The LTC4215/LTC4215-2 Hot Swap™controllers allow a board to be safely inserted and removed from a live backplane. Using an external N-channel pass transistor, board supply voltage and inrush current are ramped up at an adjustable rate. An I2C interface and onboard ADC allow for monitoring of load current, voltage and fault status.The device features adjustable foldback current limit and a soft-start pin that sets the dI/dt of the inrush current. An I2C interface may configure the part to latch-off or automatically restart after the LTC4215 detects a current limit fault.The controller has additional features to interrupt the host when a fault has occurred, notify when output power is good, detect insertion of a load card, and power-up either automatically upon insertion or wait for an I2C command to turn on.The LTC4215 has a 20μs circuit breaker filter for applications that require a fast fault response time and it defaults to latch-off after an overcurrent fault. The LTC4215-2 has an extended 420μs circuit breaker filter for applications where supply transients may exceed 20μs and it defaults to restart automatically after an overcurrent fault.Circuit Breaker TimeoutGeneral Purpose OutputsLTC421520μs1LTC4215-120μs3LTC4215-2420μs1LTC4215-3420μs3ApplicationsLive Board InsertionElectronic Circuit BreakersComputers, ServersPlatform Management

The LTC4218 is a Hot Swap controller that allows a board to be safely inserted and removed from a live backplane. An internal high side switch driver controls the gate of an external N-channel MOSFET for supply voltages from 2.9V to 26.5V. A dedicated 12V version (LTC4218-12) contains preset 12V specific thresholds, while the standard LTC4218 allows adjustable thresholds.The LTC4218 provides an accurate (5%) current limit with current foldback limiting. The current limit threshold can be adjusted dynamically using an external pin. Additional features include a current monitor output that amplifies the sense voltage for ground referenced current sensing. Overvoltage, undervoltage and power good monitoring are also provided.ApplicationsRAID SystemsATCA, AMC, μTCA SystemsServer I/O CardsIndustrial

The LTC4219 is an integrated solution for Hot Swap applications that allows a board to be safely inserted and removed from a live backplane. The part integrates a Hot Swap controller, power MOSFET and current sense resistor in a single package for small form factor applications.The LTC4219 provides separate inrush current control and a 10% accurate 5.6A current limit with foldback current limiting. The current limit threshold can be adjusted dynamically using an external pin. Additional features include a current monitor output that amplifies the sense resistor voltage for ground referenced current sensing and a MOSFET temperature monitor output. Thermal limit and power good monitoring are also provided. The power good detection level and foldback current limit profile are internally preset for 5V (LTC4219-5) and 12V (LTC4219-12) applications.ApplicationsRAID SystemsServer I/O CardsIndustrial

The LTC4222 Hot Swap™controller allows two power paths to be safely inserted and removed from a live backplane. Using external N-channel pass transistors, board supply voltages and inrush currents are ramped up at an adjustable rate. An I2C interface and on-board ADC allows for monitoring of current, voltage and fault status for each channel.The device features adjustable, analog, foldback current limit circuits and a Soft-Start circuit that sets the dI/dt of the inrush currents. An I2C interface may configure the part to latch off or automatically restart after the LTC4222 detects a fault on either channel.The controller has additional features to interrupt the host when a fault has occurred, notify when output power is good, detect insertion of a load card and power-up either automatically upon insertion or wait for an I2C command to turn on.ApplicationsLive Board InsertionElectronic Circuit BreakersComputers, ServersPlatform Management
