EGP30J Series

3.0A Ultra Fast Recovery Rectifier

Catalog

3.0A Ultra Fast Recovery Rectifier

Part	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Technology	Capacitance @ Vr, F	Current - Reverse Leakage @ Vr	Package / Case	Supplier Device Package	Voltage - Forward (Vf) (Max) @ If [Max]	Mounting Type	Current - Average Rectified (Io)	Speed	Reverse Recovery Time (trr)	Voltage - DC Reverse (Vr) (Max) [Max]	Voltage - Forward (Vf) (Max) @ If
ON Semiconductor EGP30C	150 °C	-65 C	Standard	95 pF	5 µA	DO-201AD Axial	DO-201AD	950 mV	Through Hole	3 A	200 mA 500 ns	50 ns
ON Semiconductor EGP30C	150 °C	-65 C	Standard	95 pF	5 µA	DO-201AD Axial	DO-201AD	950 mV	Through Hole	3 A	200 mA 500 ns	50 ns
ON Semiconductor EGP30D	150 °C	-65 C	Standard	95 pF	5 µA	DO-201AD Axial	DO-201AD	950 mV	Through Hole	3 A	200 mA 500 ns	50 ns	200 V
ON Semiconductor EGP30J	150 °C	-65 C	Standard	75 pF	5 µA	DO-201AD Axial	DO-201AD		Through Hole	3 A	200 mA 500 ns	75 ns	600 V	1.7 V

3.0A Ultra Fast Recovery Rectifier

• Glass passivated cavity-free junction

• High surge current capability

• Low leakage current

• Superfast recovery time for high efficiency

• Low forward voltage, high current capability
