FDS4465_F085 Series

P-Channel 1.8V Specified PowerTrench® MOSFET -20V, -13.5A, 8.5 mΩ

Catalog

P-Channel 1.8V Specified PowerTrench® MOSFET -20V, -13.5A, 8.5 mΩ

Part	Power Dissipation (Max)	Technology	FET Type	Drive Voltage (Max Rds On, Min Rds On)	Vgs(th) (Max) @ Id	Rds On (Max) @ Id, Vgs	Vgs (Max)	Operating Temperature [Min]	Operating Temperature [Max]	Gate Charge (Qg) (Max) @ Vgs	Supplier Device Package	Drain to Source Voltage (Vdss)	Input Capacitance (Ciss) (Max) @ Vds	Current - Continuous Drain (Id) @ 25°C	Mounting Type	Package / Case	Package / Case [y]	Package / Case [x]	Vgs (Max) [Min]	Vgs (Max) [Max]	Gate Charge (Qg) (Max) @ Vgs [Max]	Qualification	Grade
ON Semiconductor FDS4410	2.5 W	MOSFET (Metal Oxide)	N-Channel	4.5 V 10 V	3 V	13.5 mOhm	20 V	-55 °C	150 °C	31 nC	8-SOIC	30 V	1340 pF	10 A	Surface Mount	8-SOIC	3.9 mm	0.154 in
ON Semiconductor FDS4480	2.5 W	MOSFET (Metal Oxide)	N-Channel	10 V	5 V	12 mOhm		-55 °C	175 ░C		8-SOIC	40 V	1686 pF	10.8 A	Surface Mount	8-SOIC	3.9 mm	0.154 in	-20 V	30 V	41 nC
ON Semiconductor FDS4465-F085	2.5 W	MOSFET (Metal Oxide)	P-Channel	1.8 V 4.5 V	1.5 V	8.5 mOhm	8 V	-55 °C	150 °C	120 nC	8-SOIC	20 V	8237 pF	13.5 A	Surface Mount	8-SOIC	3.9 mm	0.154 in				AEC-Q101	Automotive
ON Semiconductor FDS4465	2.5 W	MOSFET (Metal Oxide)	P-Channel	1.8 V 4.5 V	1.5 V	8.5 mOhm	8 V	-55 °C	175 ░C	120 nC	8-SOIC	20 V	8237 pF	13.5 A	Surface Mount	8-SOIC	3.9 mm	0.154 in

Catalog

P-Channel 1.8V Specified PowerTrench® MOSFET -20V, -13.5A, 8.5 mΩ

Key Features

• –13.5 A, –20 V. RDS(ON= 8.5 mΩ @ VGS= –4.5 V

• RDS(ON)= 10.5 mΩ @ VGS= –2.5 V

• RDS(ON)= 14 mΩ @ VGS= –1.8 V

• Fast switching speed

• High performance trench technology for extremelylow RDS(ON)

• High current and power handling capability

• Qualified to AEC Q101

• RoHS Compliant

Description

This N-Channel MOSFET has been designed specifically to improve the overall efficiency of DC/DC converters using either synchronous or conventional switching PWM controllers. It has been optimized for low gate charge, low RDS(ON)and fast switching speed.
