MCP33141D-10 Series

12-Bit, 500kSPS, Single Channel ADC

Catalog

12-Bit, 500kSPS, Single Channel ADC

Part	Ratio - S/H:ADC	Qualification	Voltage - Supply, Analog [Max]	Voltage - Supply, Analog [Min]	Configuration	Package / Case	Grade	Supplier Device Package	Sampling Rate (Per Second)	Operating Temperature [Max]	Operating Temperature [Min]	Input Type	Architecture	Voltage - Supply, Digital [Min]	Voltage - Supply, Digital [Max]	Number of Bits	Data Interface	Number of Inputs	Number of A/D Converters	Reference Type	Mounting Type	Sampling Rate (Per Second)	Package / Case [x]	Package / Case [x]
Microchip Technology MCP33141-10-E/MN	0:1	AEC-Q100	1.9 V	1.7 V	ADC	10-WFDFN Exposed Pad	Automotive	10-TDFN (3x3)	1 M	125 °C	-40 °C	Single Ended	SAR	1.7 V	5.5 V	12 bits	SPI	1	1	External	Surface Mount
Microchip Technology MCP33141D-05T-E/MS	0:1	AEC-Q100	1.9 V	1.7 V	ADC	10-MSOP 10-TFSOP	Automotive	10-MSOP		125 °C	-40 °C	Differential	SAR	1.7 V	5.5 V	12 bits	SPI	1	1	External	Surface Mount	500k	3 mm	0.118 in
Microchip Technology MCP33141D-05T-E/MN	0:1	AEC-Q100	1.9 V	1.7 V	ADC	10-WFDFN Exposed Pad	Automotive	10-TDFN (3x3)		125 °C	-40 °C	Differential	SAR	1.7 V	5.5 V	12 bits	SPI	1	1	External	Surface Mount	500k
Microchip Technology MCP33141-05-E/MN	0:1	AEC-Q100	1.9 V	1.7 V	ADC	10-WFDFN Exposed Pad	Automotive	10-TDFN (3x3)		125 °C	-40 °C	Single Ended	SAR	1.7 V	5.5 V	12 bits	SPI	1	1	External	Surface Mount	500k
Microchip Technology MCP33141D-10T-E/MS	0:1	AEC-Q100	1.9 V	1.7 V	ADC	10-MSOP 10-TFSOP	Automotive	10-MSOP	1 M	125 °C	-40 °C	Differential	SAR	1.7 V	5.5 V	12 bits	SPI	1	1	External	Surface Mount		3 mm	0.118 in
Microchip Technology MCP33141D-05-E/MS	0:1	AEC-Q100	1.9 V	1.7 V	ADC	10-MSOP 10-TFSOP	Automotive	10-MSOP		125 °C	-40 °C	Differential	SAR	1.7 V	5.5 V	12 bits	SPI	1	1	External	Surface Mount	500k	3 mm	0.118 in
Microchip Technology MCP33141-05T-E/MN	0:1	AEC-Q100	1.9 V	1.7 V	ADC	10-WFDFN Exposed Pad	Automotive	10-TDFN (3x3)		125 °C	-40 °C	Single Ended	SAR	1.7 V	5.5 V	12 bits	SPI	1	1	External	Surface Mount	500k
Microchip Technology MCP33141-10T-E/MN	0:1	AEC-Q100	1.9 V	1.7 V	ADC	10-WFDFN Exposed Pad	Automotive	10-TDFN (3x3)	1 M	125 °C	-40 °C	Single Ended	SAR	1.7 V	5.5 V	12 bits	SPI	1	1	External	Surface Mount
Microchip Technology MCP33141-05T-E/MS	0:1	AEC-Q100	1.9 V	1.7 V	ADC	10-MSOP 10-TFSOP	Automotive	10-MSOP		125 °C	-40 °C	Single Ended	SAR	1.7 V	5.5 V	12 bits	SPI	1	1	External	Surface Mount	500k	3 mm	0.118 in
Microchip Technology MCP33141-10-E/MS	0:1	AEC-Q100	1.9 V	1.7 V	ADC	10-MSOP 10-TFSOP	Automotive	10-MSOP	1 M	125 °C	-40 °C	Single Ended	SAR	1.7 V	5.5 V	12 bits	SPI	1	1	External	Surface Mount		3 mm	0.118 in

Catalog

12-Bit, 500kSPS, Single Channel ADC

Key Features

• * 12-bit resolution

• * Single-ended input

• * SPI interface

• * ±0.06 LSB Typical DNL

• * ±0.09 LSB Typical INL

• * 500 ksps sample rate

• * -40 to +125°C temperature range

• * Recommended for Automotive Designs (Q100)

Description

The MCP33141D-05 12-bit Analog-to-Digital Converter (ADC) features a differential input, high performance and low power consumption in a small package, making it ideal for battery powered systems and remote data acquisition applications. The MCP33141D-05 features a successive approximation register (SAR) architecture and an industry-standard SPI serial interface, allowing 12-bit ADC capability to be added to any PIC® microcontroller. The MCP33141D-05 features 500k samples/second, 1 input channel, low power consumption (1.5µA typical standby current, 0.33mA typical active current), and is available in 10 pin MSOP and 10 pin TDFN. Applications for the MCP33141D-05 include high-precision data acquisition, medical instrumentation, motor control applications, electric vehicle battery management systems, battery operated applications, switch-mode power supply applications. MCP33141D-05 is fully automotive qualified (AEC-Q100) and specified for operation between -40 and 125 degrees Celsius. This ADC is designed to operate in both high-temperature and electromagnetic environments and to meet the rigorous and harsh demands of the automotive and industrial environment.
