The 1N4678-1 thru 1N4717-1 series of 0.5 watt Zener voltage regulators provides a selection from 1.8 to 43 volts in standard 5% tolerances as well as tighter tolerances. These axial leaded glass DO-35 Zeners are available with an internal metallurgical bond similar to military requirements for similar Zeners. Microchip also offers numerous other Zener products to meet higher and lower power applications.

Pairing the lowest power atomic clock (CSAC) with the spectral purity of an OCXO has enabled an exceptionally stable oscillator. The Microchip LN-CSAC acts as a frequency and timing subsystem, while providing limited size, weight, and power. It accepts a 1PPS input that may be used to synchronize the unit's 1PPS output to an external reference clock within ±100 ns accuracy or discipline its phase and frequency to within 1 ns and 1.0 × 10–12, respectively. Phase Noise—sine wave ≤–85 dBc/Hz at 1 Hz ≤–120 dBc/Hz at 10 Hz ≤–140 dBc/Hz at 100 Hz ≤–145 dBc/Hz at 1 kHz ≤–150 dBc/Hz at 10 kHz ≤–155 dBc/Hz at ≥100 kHz

The 0912GN-250V is an internally matched, COMMON SOURCE, class AB GaN on SiC HEMT transistor capable of providing over 18dB gain, 250 Watts of pulsed RF output power at 128μs pulse width, 10% duty factor across the 960 to 1215 MHz band. The transistor has internal pre-match for optimal performance. This transistor can be used for broadband avionics data link applications. It utilizes gold metallization and eutectic attach to provide highest reliability and superior ruggedness.

The popular family of Transient Voltage Suppressors M1.5KE6.8 - M1.5KE400CA, with its various upscreening options, offers an extended voltage range and provides a wide variety of commercial, high-reliability , RoHS and bidirectional options. All have the same high peak pulse power rating of 1500 W and extremely fast response time. They can protect from secondary effects of lightning per IEC 61000-4-5 and the class levels as shown below, as well as voltage transient from inductive switching and RFI. Since their response time is virtually instantaneous, they also protect from ESD and EFT per IEC 61000-4-2 and IEC 61000-4-4.

The popular family of Transient Voltage Suppressors M1.5KE6.8 - M1.5KE400CA, with its various upscreening options, offers an extended voltage range and provides a wide variety of commercial, high-reliability , RoHS and bidirectional options. All have the same high peak pulse power rating of 1500 W and extremely fast response time. They can protect from secondary effects of lightning per IEC 61000-4-5 and the class levels as shown below, as well as voltage transient from inductive switching and RFI. Since their response time is virtually instantaneous, they also protect from ESD and EFT per IEC 61000-4-2 and IEC 61000-4-4.

The popular family of Transient Voltage Suppressors M1.5KE6.8 - M1.5KE400CA, with its various upscreening options, offers an extended voltage range and provides a wide variety of commercial, high-reliability , RoHS and bidirectional options. All have the same high peak pulse power rating of 1500 W and extremely fast response time. They can protect from secondary effects of lightning per IEC 61000-4-5 and the class levels as shown below, as well as voltage transient from inductive switching and RFI. Since their response time is virtually instantaneous, they also protect from ESD and EFT per IEC 61000-4-2 and IEC 61000-4-4.

The SY100EL16VS are differential receivers with variable output swing. The devices are functionally equivalent to the EL16V devices with an input that control the amplitude of the outputs.The operational range of the EL16VS control input is from VBB (max. swing) to VCC (min. swing). Simple control of the output swing can be obtained by a variable resistor between the VBB pin and VCC with the wiper driving VCTRL.The EL16VS provides a VBB output for either single-ended use or as a DC bias for AC coupling to the device. The VBBpin should be used only as a bias for the EL16VS as its current sink/source capability is limited. Whenever used, the VBB pin should be bypassed to ground via a 0.01mF capacitor.Under open input conditions (pulled to VEE), internal input clamps will force the Q output LOW.
