RJU003 Series

Catalog

MOSFETS N-CH 30V 300MA SOT-323

Part	Vgs (Max)	Vgs(th) (Max) @ Id	Input Capacitance (Ciss) (Max) @ Vds [Max]	Supplier Device Package	Power Dissipation (Max)	Technology	Drive Voltage (Max Rds On, Min Rds On) [Max]	Drive Voltage (Max Rds On, Min Rds On) [Min]	Current - Continuous Drain (Id) @ 25°C	Package / Case	Drain to Source Voltage (Vdss)	Operating Temperature	FET Type	Mounting Type	Rds On (Max) @ Id, Vgs	Grade	Qualification
Rohm Semiconductor RJU003N03T106	12 V	1.5 V	24 pF	UMT3	200 mW	MOSFET (Metal Oxide)	2.5 V	4.5 V	300 mA	SC-70 SOT-323	30 V	150 °C	N-Channel	Surface Mount	1.1 Ohm
Rohm Semiconductor RJU003N03FRAT106	12 V	1.5 V	24 pF	UMT3	200 mW	MOSFET (Metal Oxide)	2.5 V	4.5 V	300 mA	SC-70 SOT-323	30 V	150 °C	N-Channel	Surface Mount	1.1 Ohm	Automotive	AEC-Q101
