09340100 Series

Manufacturer: HARTING

Catalog

HAN HVE BASE PANEL 4 PEGS THERMOPLASTIC ROHS COMPLIANT: NA

Part	Style	Connector Type	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Lock Location	Features	Thread Size	Operating Temperature [Max]	Operating Temperature [Min]	Size	Housing Material	Housing Finish	Ingress Protection	Housing Color
HARTING 09340100302	Bottom Entry	Base - Panel Mount	1.138 "	43.4 mm	140 mm	28.9 mm	1.709 "	5.512 "	Locking Clip (2) on Hood	Cover
HARTING 09340100502	Side Entry	Hood	2.461 "	43 mm	120 mm	62.5 mm	1.693 "	4.724 in	Locking Clip (2) on Hood		PG21
HARTING 09340100501	Side Entry	Hood	2.461 "	43 mm	120 mm	62.5 mm	1.693 "	4.724 in	Locking Clip (2) on Base Bottom		PG21
HARTING 09340100301	Bottom Entry	Base - Panel Mount	1.138 "	43.4 mm	140 mm	28.9 mm	1.709 "	5.512 "	Locking Clip (2) on Base Bottom			125 °C	-40 C	24 B	Aluminum Die Cast	Powder Coated	IP65 - Dust Tight Water Resistant	Gray
HARTING 09340100401	Top Entry	Hood	2.165 "	43 mm	120 mm	55 mm	1.693 "	4.724 in	Locking Clip (2) on Hood		PG29
HARTING 09340100304	Bottom Entry	Base - Panel Mount	1.138 "	43.4 mm	140 mm	28.9 mm	1.709 "	5.512 "	Locking Clip (1) on Base Bottom	Cover
HARTING 09340100404	Top Entry	Hood	2.165 "	43 mm	120 mm	55 mm	1.693 "	4.724 in	Locking Clip (1) on Base Bottom		PG29
HARTING 09340100701	Bottom Entry Top or Bottom Entry	Hood - Coupling	2.26 in	43 mm	120 mm	57.4 mm	1.693 "	4.724 in	Locking Clip (2) on Hood Top	Cable to Cable	PG29
HARTING 09340100402	Top Entry	Hood	2.165 "	43 mm	120 mm	55 mm	1.693 "	4.724 in	Locking Clip (2) on Hood		PG29			24 B
HARTING 09340100202	Side Entry	Base - Box Mount	2.205 "	57 mm	144 mm	56 mm	2.244 "	5.669 in	Locking Clip (2) on Hood		PG21
