BYC10 Series

Catalog

DIODE ARRAY GP 600V 10A TO220AB

Part	Mounting Type	Reverse Recovery Time (trr)	Current - Reverse Leakage @ Vr	Diode Configuration	Operating Temperature - Junction [Max]	Current - Average Rectified (Io) (per Diode)	Speed	Supplier Device Package	Technology	Package / Case	Voltage - Forward (Vf) (Max) @ If	Voltage - DC Reverse (Vr) (Max) [Max]	Current - Average Rectified (Io)
WeEn Semiconductors BYC10-600CT,127	Through Hole	50 ns	100 µA	1 Pair Common Cathode	150 °C	10 A	200 mA 500 ns	TO-220AB	Standard	TO-220-3	2.9 V	600 V
WeEn Semiconductors BYC10X-600,127	Through Hole	55 ns	200 µA		150 °C		200 mA 500 ns	TO-220FP	Standard	TO-220-2 Full Pack Isolated Tab	2.9 V	500 V	10 A
WeEn Semiconductors BYC10-600,127	Through Hole	55 ns	200 µA		150 °C		200 mA 500 ns	TO-220AC	Standard	TO-220-2	2.9 V	500 V	10 A
WeEn Semiconductors BYC10D-600,127	Through Hole	18 ns	200 µA		150 °C		200 mA 500 ns	TO-220AC	Standard	TO-220-2	2.5 V	500 V	10 A
WeEn Semiconductors BYC10-600PQ	Through Hole	19 ns			150 °C		200 mA 500 ns	TO-220AC	Standard	TO-220-2	1.8 V	600 V	10 A
WeEn Semiconductors BYC10X-600PQ	Through Hole	40 ns	200 µA		150 °C		200 mA 500 ns	TO-220FP	Standard	TO-220-2 Full Pack Isolated Tab	2.9 V	600 V	10 A
WeEn Semiconductors BYC10DX-600,127	Through Hole	18 ns	200 µA		150 °C		200 mA 500 ns	TO-220FP	Standard	TO-220-2 Full Pack Isolated Tab	2.5 V	500 V	10 A
WeEn Semiconductors BYC10B-600,118	Surface Mount	55 ns	200 µA		150 °C		200 mA 500 ns	D2PAK	Standard	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	2.9 V	500 V	10 A
