AM5TW Series

Manufacturer: aimtec

Catalog

DC DC CONVERTER +/-9V 5W

Part	Voltage - Input (Max) [Max]	Power (Watts)	Number of Outputs	Mounting Type	Voltage - Output 2	Approval Agency	Voltage - Input (Min) [Min]	Voltage - Isolation	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Current - Output (Max)	Current - Output (Max)	Voltage - Output 1	Type	Package / Case	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Applications	Voltage - Output 1 [Min]	Voltage - Output 1 [Max]	Efficiency	Current - Output (Max) [Max]	Voltage - Output 1 [Max] [custom]	Voltage - Output 1 [Min] [custom]
aimtec AM5TW-2409DZ	36 V	5 W	2	Through Hole	-9 V	CE	9 V	1.5 kV	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	278 mA	278 mA	9 V	Isolated Module	12 Leads	24-DIP Module	85 °C	-40 C	ITE (Commercial)
aimtec AM5TW-2407D-RZ	36 V	5 W	2	Through Hole	-7.2 V	CE	9 V	1.5 kV	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	347 mA	347 mA		Isolated Module		24-DIP Module	85 °C	-40 C	ITE (Commercial)	-7.2 V	7.2 V	80 %
aimtec AM5TW-2407SH35Z	36 V	5 W	1	Through Hole		CE	9 V	3.5 kV	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in			7.2 V	Isolated Module		24-DIP Module	85 °C	-40 C	ITE (Commercial)			78 %	690 mA
aimtec AM5TW-2415D-RZ	36 V	5 W	2	Through Hole	-15 V	CE	9 V	1.5 kV	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	167 mA			Isolated Module		24-DIP Module	85 °C	-40 C	ITE (Commercial)			83 %		15 V	-15 V
aimtec AM5TW-2405S-RZ	36 V	5 W	1	Through Hole		CE	9 V	1.5 kV	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in			5 V	Isolated Module		24-DIP Module	85 °C	-40 C	ITE (Commercial)			80 %	1 A
aimtec AM5TW-2405SH35-VZ	36 V	5 W	1	Through Hole			9 V	3.5 kV	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in			5 V	Isolated Module		24-DIP Module	85 °C	-40 C	ITE (Commercial)			73 %	1 A
aimtec AM5TW-2405SZ	36 V	5 W	1	Through Hole		CE	9 V	1.5 kV	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in			5 V	Isolated Module		24-DIP Module	85 °C	-40 C	ITE (Commercial)			80 %	1 A
