74ABT16833 Series

The 'ABT16833 consist of two noninverting 8-bit to 9-bit parity bus transceivers and are designed for communication between data buses. For each transceiver, when data is transmitted from the A bus to the B bus, an odd-parity bit is generated and output on the parity I/O pin (1PARITY or 2PARITY). When data is transmitted from the B bus to the A bus, 1PARITY (or 2PARITY) is configured as an input and combined with the B-input data to generate an active-low error flag if odd parity is not detected. The error (1or 2) output is configured as an open-collector output. The B-to-A parity-error flag is clocked into 1(or 2) on the low-to-high transition of the clock (1CLK or 2CLK) input. 1(or 2) is cleared (set high) by taking the clear (1or 2) input low. The output-enable (and) inputs can be used to disable the device so that the buses are effectively isolated. When bothandare low, data is transferred from the A bus to the B bus and inverted parity is generated. Inverted parity is a forced error condition that gives the designer more system diagnostic capability. To ensure the high-impedance state during power up or power down,should be tied to VCCthrough a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver. The SN54ABT16833 is characterized for operation over the full military temperature range of -55°C to 125°C. The SN74ABT16833 is characterized for operation from -40°C to 85°C. The 'ABT16833 consist of two noninverting 8-bit to 9-bit parity bus transceivers and are designed for communication between data buses. For each transceiver, when data is transmitted from the A bus to the B bus, an odd-parity bit is generated and output on the parity I/O pin (1PARITY or 2PARITY). When data is transmitted from the B bus to the A bus, 1PARITY (or 2PARITY) is configured as an input and combined with the B-input data to generate an active-low error flag if odd parity is not detected. The error (1or 2) output is configured as an open-collector output. The B-to-A parity-error flag is clocked into 1(or 2) on the low-to-high transition of the clock (1CLK or 2CLK) input. 1(or 2) is cleared (set high) by taking the clear (1or 2) input low. The output-enable (and) inputs can be used to disable the device so that the buses are effectively isolated. When bothandare low, data is transferred from the A bus to the B bus and inverted parity is generated. Inverted parity is a forced error condition that gives the designer more system diagnostic capability. To ensure the high-impedance state during power up or power down,should be tied to VCCthrough a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver. The SN54ABT16833 is characterized for operation over the full military temperature range of -55°C to 125°C. The SN74ABT16833 is characterized for operation from -40°C to 85°C.
