BYR29 Series

Catalog

DIODE GEN PURP 800V 8A TO220AC

Part	Supplier Device Package	Operating Temperature - Junction [Max]	Technology	Package / Case	Speed	Mounting Type	Current - Average Rectified (Io)	Current - Reverse Leakage @ Vr	Reverse Recovery Time (trr)	Voltage - DC Reverse (Vr) (Max) [Max]	Voltage - Forward (Vf) (Max) @ If
WeEn Semiconductors BYR29-800,127	TO-220AC	150 °C	Standard	TO-220-2	200 mA 500 ns	Through Hole	8 A	10 µA	75 ns	800 V	1.5 V
WeEn Semiconductors BYR29X-800PQ	TO-220FP	175 ░C	Standard	TO-220-2 Full Pack Isolated Tab	200 mA 500 ns	Through Hole	8 A	10 µA	55 ns	800 V	1.7 V
WeEn Semiconductors BYR29X-800,127	TO-220FP	150 °C	Standard	TO-220-2 Full Pack Isolated Tab	200 mA 500 ns	Through Hole	8 A	10 µA	75 ns	800 V	1.7 V
WeEn Semiconductors BYR29X-600,127	TO-220FP	150 °C	Standard	TO-220-2 Full Pack Isolated Tab	200 mA 500 ns	Through Hole	8 A	10 µA	75 ns	600 V	1.7 V
WeEn Semiconductors BYR29-600,127	TO-220AC	150 °C	Standard	TO-220-2	200 mA 500 ns	Through Hole	8 A	10 µA	75 ns	600 V	1.5 V
