E2206S Series
Manufacturer: Prysmian Group
Beta
⌘K
CABLE 6COND 18AWG BLUE SHLD
| Part | Number of Conductors | Shield Material | Features | Jacket (Insulation) Material | Conductor Strand [custom] | Conductor Strand [custom] | Jacket Color | Conductor Insulation | Shield Coverage | Shield Type | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Length | Length | Usage | Conductor Material | Voltage | Wire Gauge | Cable Type | Operating Temperature [Max] | Operating Temperature [Min] | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Prysmian Group | 6 | Flexfoil® | Drain Wire | Plenum Poly-Vinyl Chloride (PVC) | 26 AWG | 7 | Blue | Poly-Vinyl Chloride (PVC) | 100 % | Foil | 0.203 mm | 0.008 in | 0.23 in | 5.84 mm | 304.8 m | 1000 ft | Alarm Security Sound | Copper Bare | 300 VDC | 18 AWG | Multi-Conductor | 75 ░C | 0 °C | ||
 Prysmian Group | 6 | Flexfoil® | Drain Wire | Plenum Poly-Vinyl Chloride (PVC) | 26 AWG | 7 | Natural | Poly-Vinyl Chloride (PVC) | 100 % | Foil | 0.203 mm | 0.008 in | 0.23 in | 5.84 mm | Alarm Security Sound | Copper Bare | 300 VDC | 18 AWG | Multi-Conductor | 75 ░C | 0 °C | ||||
 Prysmian Group | 6 | Flexfoil® | Drain Wire | Plenum Poly-Vinyl Chloride (PVC) | 26 AWG | 7 | Natural | Poly-Vinyl Chloride (PVC) | 100 % | Foil | 0.203 mm | 0.008 in | 0.23 in | 5.84 mm | 15.24 m 152.4 m 304.8 m | 50 ft 500 ft 1000 ft | Alarm Security Sound | Copper Bare | 300 VDC | 18 AWG | Multi-Conductor | 75 ░C | 0 °C | 100 ft | 30.5 m |
Prysmian Group | 6 | Drain Wire | Plenum Poly-Vinyl Chloride (PVC) | 26 AWG | 7 | Natural | Poly-Vinyl Chloride (PVC) | Foil | 0.203 mm | 0.008 in | 0.23 in | 5.84 mm | 15.24 m 152.4 m 304.8 m | 50 ft 500 ft 1000 ft | Alarm Security Sound | Copper Bare | 300 VDC | 18 AWG | Multi-Conductor | 75 ░C | 0 °C | 100 ft | 30.5 m | ||
Prysmian Group | 6 | Drain Wire | Plenum Poly-Vinyl Chloride (PVC) | 26 AWG | 7 | Blue | Poly-Vinyl Chloride (PVC) | Foil | 0.203 mm | 0.008 in | 0.23 in | 5.84 mm | 304.8 m | 1000 ft | Alarm Security Sound | Copper Bare | 300 VDC | 18 AWG | Multi-Conductor | 75 ░C | 0 °C | ||||
Prysmian Group | 6 | Drain Wire | Plenum Poly-Vinyl Chloride (PVC) | 26 AWG | 7 | White | Poly-Vinyl Chloride (PVC) | Foil | 0.25 mm | 0.0098 " | 0.23 in | 5.84 mm | 15.24 m 304.8 m | 50 ft 1000 ft | Alarm Safety | Copper Bare | 300 VDC | 18 AWG | Multi-Conductor | 75 ░C | 0 °C | 25 ft 100 ft | 7.62 m 30.5 m | ||
Prysmian Group | 6 | Flexfoil® | Drain Wire | Plenum Poly-Vinyl Chloride (PVC) | 26 AWG | 7 | White | Poly-Vinyl Chloride (PVC) | 100 % | Foil | 0.25 mm | 0.0098 " | 0.23 in | 5.84 mm | 15.24 m 304.8 m | 50 ft 1000 ft | Alarm Safety | Copper Bare | 300 VDC | 18 AWG | Multi-Conductor | 75 ░C | 0 °C | 25 ft 100 ft | 7.62 m 30.5 m |
