395-124 Series
Manufacturer: EDAC Inc.
Catalog
.100" (2.54MM) PITCH CARD EDGE CONNECTOR ROHS COMPLIANT: YES
...
| Part | Number of Rows | Flange Feature | Material - Insulation | Termination | Pitch [x] | Pitch [x] | Contact Type | Termination Rows | Number of Positions/Bay/Row [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Gender | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Contact Finish | Color | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Mounting Type | Card Type | Read Out | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | M3 Threaded Insert Top Mount Opening | Polyester Thermoplastic | Solder | 2.54 mm | 0.1 in | Cantilever | 2 | 62 | -40 °C | 105 ░C | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Black | 124 | 10 Áin | 0.25 Ám | Copper Alloy | Through Hole | Non Specified - Dual Edge | Dual | |||
 EDAC Inc. | 2 | Flush Mount Side Opening Unthreaded | Polyester Thermoplastic | Solder | 2.54 mm | 0.1 in | Cantilever | 2 | 62 | -40 °C | 105 ░C | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Black | 124 | 10 Áin | 0.25 Ám | Copper Alloy | Through Hole Right Angle | Non Specified - Dual Edge | Dual | 3.25 mm | 0.128 " | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Wire Wrap | 2.54 mm | 0.1 in | Cantilever | 2 | 62 | -40 °C | 105 ░C | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Black | 124 | 10 Áin | 0.25 Ám | Copper Alloy | Through Hole | Non Specified - Dual Edge | Dual | ||||
 EDAC Inc. | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Polyester Thermoplastic | Solder | 2.54 mm | 0.1 in | Cantilever | 2 | 62 | -40 °C | 105 ░C | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Black | 124 | 10 Áin | 0.25 Ám | Copper Alloy | Through Hole | Non Specified - Dual Edge | Dual | |||
 EDAC Inc. | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Polyester Thermoplastic | Solder | 2.54 mm | 0.1 in | Cantilever | 2 | 62 | -40 °C | 105 ░C | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Black | 124 | 10 Áin | 0.25 Ám | Copper Alloy | Board Edge Straddle Mount | Non Specified - Dual Edge | Dual | |||
 EDAC Inc. | 2 | 4-40 Threaded Insert Top Mount Opening | Polyester Thermoplastic | Solder Eyelet(s) | 2.54 mm | 0.1 in | Cantilever | 2 | 62 | -40 °C | 105 ░C | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Black | 124 | 10 Áin | 0.25 Ám | Copper Alloy | Board Edge Straddle Mount | Non Specified - Dual Edge | Dual | |||
 EDAC Inc. | 2 | Floating Bobbin Top Mount Opening | Polyester Thermoplastic | Wire Wrap | 2.54 mm | 0.1 in | Cantilever | 2 | 62 | -40 °C | 105 ░C | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Black | 124 | 10 Áin | 0.25 Ám | Copper Alloy | Through Hole | Non Specified - Dual Edge | Dual | 2.95 mm | 0.116 in | |
 EDAC Inc. | 2 | M3 Threaded Insert Top Mount Opening | Polyester Thermoplastic | Solder | 2.54 mm | 0.1 in | Cantilever | 2 | 62 | -40 °C | 105 ░C | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Black | 124 | 10 Áin | 0.25 Ám | Copper Alloy | Through Hole | Non Specified - Dual Edge | Dual | |||
 EDAC Inc. | 2 | 4-40 Threaded Insert Top Mount Opening | Polyester Thermoplastic | Solder | 2.54 mm | 0.1 in | Cantilever | 2 | 62 | -40 °C | 105 ░C | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Black | 124 | 10 Áin | 0.25 Ám | Copper Alloy | Board Edge Straddle Mount | Non Specified - Dual Edge | Dual | |||
 EDAC Inc. | 2 | Floating Bobbin Flush Mount | Polyester Thermoplastic | Solder Eyelet(s) | 2.54 mm | 0.1 in | Cantilever | 2 | 62 | -40 °C | 105 ░C | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Gold | Black | 124 | 10 Áin | 0.25 Ám | Copper Alloy | Board Edge Straddle Mount | Non Specified - Dual Edge | Dual | 2.95 mm | 0.116 in | Card Extender |
