JANTXV2N2484UA-Transistor Series

NPN Silicon Low-Power 60V, 0.05A

Catalog

NPN Silicon Low-Power 60V, 0.05A

Part	Package / Case	Power - Max [Max]	Qualification	Current - Collector (Ic) (Max) [Max]	Transistor Type	DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	Grade	Supplier Device Package	Vce Saturation (Max) @ Ib, Ic	Mounting Type	Voltage - Collector Emitter Breakdown (Max)	Supplier Device Package
Microchip Technology JANS2N2484UBC	4-SMD No Lead	360 mW	MIL-PRF-19500/376	50 mA	NPN	250	Military	UB	300 mV	Surface Mount	60 V
Microchip Technology JANS2N2484UA	4-SMD No Lead	360 mW	MIL-PRF-19500/376	50 mA	NPN	250	Military	UA	300 mV	Surface Mount	60 V
Microchip Technology JANSR2N2484UB/TR
Microchip Technology JANS2N2484UB	4-SMD No Lead	360 mW	MIL-PRF-19500/376	50 mA	NPN	250	Military	UB	300 mV	Surface Mount	60 V
Microchip Technology JAN2N2484UB/TR	3-SMD No Lead	360 mW	MIL-PRF-19500/376	50 mA	NPN	225	Military	UB	300 mV	Surface Mount	60 V
Microchip Technology JAN2N2484UA/TR	4-SMD No Lead	360 mW	MIL-PRF-19500/376	50 mA	NPN	225	Military	UA	300 mV	Surface Mount	60 V
Microchip Technology JANSR2N2484UB
Microchip Technology JANTX2N2484	TO-18-3 Metal Can TO-206AA	360 mW	MIL-PRF-19500/376	50 mA	NPN	225	Military	TO-18	300 mV	Through Hole	60 V
Microchip Technology JANS2N2484	TO-18-3 Metal Can TO-206AA	360 mW	MIL-PRF-19500/376	50 mA	NPN	225	Military	TO-18	300 mV	Through Hole	60 V	TO-206AA
Microchip Technology JANTXV2N2484UA	4-SMD No Lead	360 mW	MIL-PRF-19500/376	50 mA	NPN	225	Military	UA	300 mV	Surface Mount	60 V

Catalog

NPN Silicon Low-Power 60V, 0.05A

Key Features

- The device packages for the encapsulated device types are as follows: (2N2484) (similar to TO-18), and surfacemount (UA, UB, UBC, UBN, and UBCN) .

- The dimensions and topography for JANHC and JANKC unencapsulated die are as outlined in MIL-PRF-19500/376.

Description

This specification covers the performance requirements for NPN, silicon, low-power 2N2484 transistor. Four levels of product assurance (JAN, JANTX, JANTXV and JANS) are provided for each device type as specified in MIL-PRF-19500/376. Two levels of product assurance (JANHC, JANKC) are provided for die. RHA level designators "E", "K", "U", "M", "D", "P", "L", "R", "F", "G" and "H" are appended to the device prefix to identify devices, which have passed RHA requirements.
