ADG1634L Series

4.7 Ω RON, Quad SPDT Switch with 1.2 V and 1.8 V JEDEC Logic Compliance

Catalog

4.7 Ω RON, Quad SPDT Switch with 1.2 V and 1.8 V JEDEC Logic Compliance

Part	Mounting Type	Voltage - Supply, Dual (V±)	Operating Temperature [Max]	Operating Temperature [Min]	Current - Leakage (IS(off)) (Max) [Max]	Channel-to-Channel Matching (ΔRon)	On-State Resistance (Max) [Max]	Channel Capacitance (CS(off), CD(off)) [custom]	Channel Capacitance (CS(off), CD(off)) [custom]	-3db Bandwidth	Charge Injection	Crosstalk	Switch Circuit	Switch Time (Ton, Toff) (Max) [custom]	Switch Time (Ton, Toff) (Max) [custom]	Number of Circuits	Voltage - Supply, Single (V+) [Min]	Voltage - Supply, Single (V+) [Max]	Supplier Device Package	Multiplexer/Demultiplexer Circuit	Package / Case
Analog Devices ADG1634LYCPZ-REEL7	Surface Mount	3.3 V 8 V	125 °C	-40 °C	150 pA	120 mOhm	4.6 Ohm	32 pF	19 pF	77 MHz	-12.4 pC	-64 dB	SPDT	154 ns	195 ns	4	3.3 V	16 V	24-LFCSP (4x4)	2:1	24-VFQFN Exposed Pad CSP

Catalog

4.7 Ω RON, Quad SPDT Switch with 1.2 V and 1.8 V JEDEC Logic Compliance

Key Features

• 4.7 Ω typical on resistance for ±5 V dual supply at 25°C

• 1.2 Ω on-resistance flatness for ±5 V dual supply at 25°C

• Fully specified at ±5 V, +12 V, +5 V, and +3.3 V

• ±3.3 V to ±8 V dual-supply operation

• 3.3 V to 16 V single-supply operation

• VLsupply for low logic level compatibility

• 1.8 V JEDEC standard compliant

• 1.2 V JEDEC standard compliant

• Rail-to-rail operation

• 24-lead, 4 mm × 4 mm LFCSP

Description

The ADG1634L is a monolithic industrial CMOS (iCMOS®) analog switch comprising four independently selectable single-pole, double-throw (SPDT) switches, respectively.All channels exhibit break-before-make switching action that prevents momentary shorting when switching channels. An EN input on the ADG1634L is used to enable or disable the device. When disabled, all channels are switched off. The switch is enabled with a Logic 1 EN input, while the INx input defines the state of the SPDT switch (see Table 12 in the data sheet).The ultralow on resistance and on-resistance flatness of the switch makes it an ideal solution for data acquisition and gain switching applications, where low distortion is critical.iCMOS construction ensures ultra low power dissipation, making the device ideally suited for portable and battery-powered instruments.An external VLsupply provides flexibility for lower logic control. The ADG1634L is both 1.2 V and 1.8 V JEDEC standard compliant.APPLICATIONSCommunication systemsMedical systemsAudio signal routingVideo signal routingAutomatic test equipmentData acquisition systemsBattery-powered systemsFPGA and microcontroller systemsSample-and-hold systemsRelay replacementsPRODUCT HIGHLIGHTS8.2 Ω maximum on resistance over temperature.Minimum distortion.VLsupply for low logic level compatibility.JEDEC standard compliant for both 1.2 V and 1.8 V logic levels.Guaranteed switch off when digital inputs are floating.24-lead, 4 mm × 4 mm LFCSP.
