Connectors, Interconnects
1725740
ActivePhoenix Contact
FIXED TERMINAL BLOCKS 11P 2.54MM 90DEG
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 1725740 |
|---|---|
| Color | Green |
| Current | 6 A |
| Housing Material | Polyamide (PA), Nylon |
| Mating Orientation | Horizontal with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Pitch [x] | 2.54 mm |
| Pitch [x] | 0.1 in |
| Positions Per Level | 11 |
| Screw Thread | M1.6 |
| Torque - Screw [Max] | 1.3 Lb-In |
| Torque - Screw [Max] | 0.15 Nm |
| Torque - Screw [Min] | 0.12 Nm |
| Torque - Screw [Min] | 1 Lb-In |
| Voltage | 125 V |
| Wire Gauge [Max] | 30 AWG |
| Wire Gauge [Min] | 20 AWG |
| Wire Termination | Screw |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
MPT Series
DIN Rail Terminal Blocks Mini Feed-through 3.5mm Width,26-14AWG
