Connectors, Interconnects

410-87-372-01-640101

Active

Preci-Dip

CONN SOCKET 72POS 0.1 GOLD PCB

Deep-Dive with AI

Search across all available documentation for this part.

Connectors, Interconnects

410-87-372-01-640101

Active

Preci-Dip

CONN SOCKET 72POS 0.1 GOLD PCB

Deep-Dive with AI

Specifications Series Pricing Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	410-87-372-01-640101

Connector Type	Socket
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	Flash
Contact Length - Post	0.125 in
Contact Length - Post	3.18 mm
Contact Material	Beryllium Copper
Contact Shape	Circular
Contact Type	Female Socket
Current Rating (Amps)	3 A
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	0.165 in
Insulation Height	4.2 mm
Insulation Material	Polyester, Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	72
Number of Positions Loaded	All
Number of Rows [custom]	3
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 C
Pitch - Mating	0.1 "
Pitch - Mating	2.54 mm
Row Spacing - Mating [x]	0.1 in
Row Spacing - Mating [x]	2.54 mm
Termination	Solder

410-87 Series

...

Part	Contact Material	Insulation Material	Contact Shape	Contact Finish - Mating	Contact Type	Connector Type	Contact Finish - Post	Operating Temperature [Min]	Operating Temperature [Max]	Number of Rows [custom]	Contact Finish Thickness - Mating	Fastening Type	Insulation Color	Mounting Type	Material Flammability Rating	Number of Positions	Pitch - Mating	Pitch - Mating	Current Rating (Amps)	Contact Length - Post	Contact Length - Post	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Insulation Height	Insulation Height	Termination	Number of Positions Loaded	Contact Resistance	Termination Post Length	Termination Post Length	Contact Material - Post [custom]	Contact Material - Mating	Housing Material	Type	Number of Positions or Pins (Grid) [custom]	Number of Positions or Pins (Grid)	Number of Positions or Pins (Grid) [custom]	Pitch - Post	Pitch - Post	Features
Preci-Dip 410-87-204-01-640101	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Gold	Female Socket	Socket	Tin	-55 C	125 °C	2	Flash	Push-Pull	Black	Through Hole	UL94 V-0	4	0.1 "	2.54 mm	3 A	0.125 in	3.18 mm	0.1 in	2.54 mm	0.165 in	4.2 mm	Solder	All
Preci-Dip 410-87-216-10-001101				Gold			Tin	-55 C	125 °C		Flash			Through Hole	UL94 V-0		0.1 "	2.54 mm	1 A							Solder		10 mOhm	0.125 in	3.18 mm	Brass	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Zig-Zag Left Stackable	2	16	8	0.1 in	2.54 mm
Preci-Dip 410-87-266-41-105101	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Gold	Female Socket	Socket	Tin	-55 C	125 °C	2	Flash	Push-Pull	Black	Surface Mount	UL94 V-0	66	0.1 "	2.54 mm	3 A			0.1 in	2.54 mm	0.22 in	5.6 mm	Solder	All
Preci-Dip 410-87-208-41-105191	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Gold	Female Socket	Socket	Tin	-55 C	125 °C	2	Flash	Push-Pull	Black	Surface Mount	UL94 V-0	8	0.1 "	2.54 mm	3 A			0.1 in	2.54 mm	0.22 in	5.6 mm	Solder	All													Pick and Place
Preci-Dip 410-87-372-01-640101	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Gold	Female Socket	Socket	Tin	-55 C	125 °C	3	Flash	Push-Pull	Black	Through Hole	UL94 V-0	72	0.1 "	2.54 mm	3 A	0.125 in	3.18 mm	0.1 in	2.54 mm	0.165 in	4.2 mm	Solder	All
Preci-Dip 410-87-212-41-105191	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Gold	Female Socket	Socket	Tin	-55 C	125 °C	2	Flash	Push-Pull	Black	Surface Mount	UL94 V-0	12	0.1 "	2.54 mm	3 A			0.1 in	2.54 mm	0.22 in	5.6 mm	Solder	All													Pick and Place
Preci-Dip 410-87-378-01-640101	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Gold	Female Socket	Socket	Tin	-55 C	125 °C	3	Flash	Push-Pull	Black	Through Hole	UL94 V-0	78	0.1 "	2.54 mm	3 A	0.125 in	3.18 mm	0.1 in	2.54 mm	0.165 in	4.2 mm	Solder	All
Preci-Dip 410-87-238-41-001101	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Gold	Female Socket	Socket	Tin	-55 C	125 °C	2	Flash	Push-Pull	Black	Through Hole	UL94 V-0	38	0.1 "	2.54 mm	3 A	0.125 in	3.18 mm	0.1 in	2.54 mm	0.165 in	4.2 mm	Solder	All
Preci-Dip 410-87-272-41-105101	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Gold	Female Socket	Socket	Tin	-55 C	125 °C	2	Flash	Push-Pull	Black	Surface Mount	UL94 V-0	72	0.1 "	2.54 mm	3 A			0.1 in	2.54 mm	0.22 in	5.6 mm	Solder	All
Preci-Dip 410-87-232-41-001101	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Gold	Female Socket	Socket	Tin	-55 C	125 °C	2	Flash	Push-Pull	Black	Through Hole	UL94 V-0		0.1 "	2.54 mm	3 A	0.125 in	3.18 mm	0.1 in	2.54 mm	0.165 in	4.2 mm	Solder	All

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	130	$ 5.99
	N/A	0	$ 5.27

Description

General part information

410-87 Series

72 Position Socket Connector 0.100" (2.54mm) Through Hole Gold

Documents

Technical documentation and resources

No documents available
