Power Supplies - Board Mount

AM3TIW-2415D-RZ

Active

DC DC CONVERTER +/-15V 3W

Search across all available documentation for this part.

Power Supplies - Board Mount

Active

DC DC CONVERTER +/-15V 3W

Technical Specifications

Parameters and characteristics for this part

Part	Type	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Isolation	Approval Agency	Voltage - Input (Min)	Size / Dimension Height	Size / Dimension Length	Size / Dimension Width	Power (Watts)	Package Leads	Package Name	Voltage - Input (Max)	Efficiency	Current - Output (Max)	Mounting Type	Number of Outputs	Voltage - Output 1	Applications	Voltage - Output 2	Voltage - Output 1 (Min)	Voltage - Output 1 (Max)	Package / Case	Current - Output (Max) Options
aimtec AM3TI-2405S-RZ	Isolated Module	85 °C	-40 °C	1500 Vrns	CE cURus	18 V	0.4 in	1.25 in	0.8 in	3 W	7 Leads	24-DIP Module	36 V	77 %	600 mA	Through Hole	1	5 V	ITE (Commercial)
aimtec AM3TIW-2415D-RZ	Isolated Module	85 °C	-40 °C	1500 Vrns	CE cURus	9 V	0.4 in	1.25 in	0.8 in	3 W			36 V	81 %		Through Hole	2		ITE (Commercial)	-15 V	-15 V	15 V	24-DIP Module	100mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$	Updated

Digikey	N/A	4	$ 17.40	1m+
	Tube	1	$ 12.41	1m+
		5	$ 11.70
		10	$ 11.41
		25	$ 11.03
		50	$ 10.76
		100	$ 10.49
		250	$ 10.14
		500	$ 9.89
TME	N/A	1	$ 17.28	<1d
		10	$ 16.33

3D models and CAD resources for this part

General part information

Isolated Module DC DC Converter 2 Output -15 ~ 15V -15V 100mA, 100mA 9V - 36V Input
